- Page 1 HEAD OFFICE : VIA BIBAN 56 ( Z.I. ) 31030 CARBONERA TREVISO - ITALIA TEL. ++39 0422 445363 FAX ++39 0422 398646 EMAIL = info@bpstecnologie.com PLEASE NOTE : THE INSTRUCTIONS GIVEN HEREIN APPLY ONLY TO THE COUNTRY MARKED ON THE PLATE STUCK ON THE APPLIANCE.
- Page 2 TECHNICAL FEATURES MODEL NO. PRESTIGE 2 PRESTIGE 4 CERTIFICATION NO. 1312BP4187 NOMINAL THERMAL INPUT NOMINAL THERMAL OUTPUT µ % THERMAL EFFICIENCY METHANE 0.22 0.42 0.42 G20 (9.45 kW) CONSUMPTION METHANE 0.22 0.45 G25 (8.12 kW) at + 15°C PROPANE 0.24 0.31...
-
Page 3: G L O B A L V I E W
P R E S T I G E G L O B A L V I E W Pict.1... - Page 4 P R E S T I G E 4 G L O B A L V I E W Pict.2...
- Page 5 HOW TO INSTALL PRESTIGE 2 and PRESTIGE 4 ”L” SIZE “L” SIZE Minimum = 300 mm Minimum = 50 mm Maximum = 800 mm Maximum = 300 mm SUPPLIED PIPE L = 500 mm OPTION PIPE L = 800 mm...
- Page 6 HOW TO INSTALL PRESTIGE 2 and PRESTIGE 4 - WALL INSTALLATION - - WALL INSTALLATION - 90° HORIZONTAL SMOKES EXHAUST & 90° HORIZONTAL SMOKES EXHAUST & COMBUSTION AIR INSIDE THE WALL COMBUSTION AIR CROSSING TWO WALLS Pict.4 The heaters of the “PRESTIGE” series are independent forced air convectors, fitted with atmospheric burner and fan, expressly designed for room heating.
-
Page 7: Installation
• Please carefully read all the instructions given in this booklet, as these are very useful for both safe installation and proper use & maintenance. • Installation to be carried out always strictly complying with the current standards of the country where the device is going to be used, as well as following the instructions given by the maker, of course. - Page 8 Now assemble the shell, fix the side screws. Connect the heater to the gas supply, by adopting a detecting tap Connect the heater to the power mains. Check the ground connection. POWER CONNECTION This convector has been duly manufactured in compliance with the CEE 73/23 rule. Connection to be made by means of a H05 RR-F, 3 pole cable, section must be minimum 0,75 sq.
- Page 9 Ø of injectors in Ø of injectors in 1.3 r 1.85 r 0.8 r 0.7r 1.1r No. of injectors No. of injectors Pressure to the Pressure to the injectors injectors in mbar in mbar GAS LINE INSTALLATION DIAGRAM The diagrams here below show both those parts being supplied along with the appliance and those to be supplied by the installer.
- Page 10 No intervention is required. However we recommend to do as follows : 1. METHANE APPLIANCES (G20) (G25) By a manometer on the “PV” point (Pict.6) compare the pressure value to the value stated on the label. Should there be found a difference exceeding ±2 mbar, remove protection from "RP"...
- Page 11 Bring green switch “4” to 1 position (Pict.7) Please note : the blockage red light will stay on for about 20 seconds before the burner’s start, however this doesn’t mean that there is a blockage but it just depends on the electronic board. Should the blockage light stay on longer, take current off for just a few seconds and then give current again.
- Page 12 Fuses must be in order. There must be enough gas available. Gas pressure and capacity values must be exactly as stated in the Technical Data here above. Here below please find the following troubleshooting list, where we explain also the reasons and remedies to restore the correct performance of the heater.
- Page 13 The burner gets off The thermal power of the heater is not Replace heater by another one during normal enough powerful to heat the whole having suitable thermal power. working even place. when temperature getting below scheduled figure Gas consumption lower than Adjust it The heater works recommended in the technical data...
- Page 14 LEGENDA 17. SHELL 10. GAS 3/8” NIPPLE 18. BAFFLE 1. ROOM THERMOSTAT 11. FAN 19. TERMINAL PANEL 2. SWITCH 12. ROOM THERMOSTAT 20. ELECTRONIC BOARD 3. BLOCKAGE LIGHT BULB 21. CHIMNEY 4. ON-OFF SWITCH 13. INSIDE COMBUSTION 22. REAR PANEL 5.
- Page 15 F = Rapid Fuse 5 x 20 2A EV = Gas electro-valve MI = Inside Terminal panel BR = Atmospheric burner TM = Maximum thermostat EF = Smokes pulling fan Commento [B1]: TF = Fan thermostat MV = Fan engine TA = Room thermostat IMT = Line switch DV = 2 speed shunt switch...
- Page 16 F = Rapid Fuse 5 x 20 2A EI = Ionization electrode MI = Inside Terminal panel EV = Gas electro-valve TM = Maximum thermostat BR = Atmospheric burner Commento [B2]: TF = Fan thermostat EF = Smokes pulling fan TA = Room thermostat MV = Fan engine IMT = Line switch...
- Page 17 Pict.10...
