EX-91101 Display Monitor User Manual Release Date Revision April 2005 V0.1 May 2007 V0.2 ®2005 All Rights Reserved. Published in Taiwan EX-91101 User Manual... -
Page 2: Warning
Measures may be required to correct the interference Electric Shock Hazard – Do not operate the workstation with its back cover removed. There are dangerous high voltages inside. Disclaimer This information in this document is subject to change without notice. EX-91101 User Manual... -
Page 3: Table Of Contents
1.5 Display Mode……………………………………………………………….8 Chapter 2 2.1 Front Panel Controls………….………………………………….…..…….9 2.2 OSD Controls………………………………………………………………..9 2.3 Main Menu…..……………………………………………………………..10 2.4 AD Board (TB-6020) OSD Functions……………………………………12 Figures Figure 1.1: Dimensions of EX-91101….……………………………………..6 Figure 1.4: Front View…..….………………………………………………….7 Figure 1.5: Rear View…………………..……………………………………...8 Appendix Panelmounting…..…………………………………………………………….13 EX-91101 User Manual... -
Page 4: Features
● IP65-certified plastic front panel ● Mounting: panel mount ● Input signal: analog RGB ● OSD on the rear side ● Dimensions: 317(W) x 243(H) x 43.5mm (D) ● Cutout Dimensions: 303(W) x 229mm (H) ● Gross Weight: 4.2kg EX-91101 User Manual... - Page 5 ● Operating temperature: 0 to 45℃ (32 to 113℉) ● Storage temperature: -20 to 60℃ (-4 to 140℉) ● Relative humidity: 10 to 95% @40℃, non-condensing ● Vibration: 1G peak, 10~150Hz ● Shock: 30G peak acceleration (11 msec.duration) ● EMC: CE, FCC Class A EX-91101 User Manual...
-
Page 6: Dimensions
1.3 Dimensions Figure 1.1: Dimensions of the EX-91101 EX-91101 User Manual... -
Page 7: Brief Description
1.4 Brief Description of the EX-91101 The EX-91101 features an excellent viewing ability for monitoring and control applications. It is available with resistive touch screen that is easy to use and maintain. The front panel of the display monitor is sealed with gasket for NEMA 4/IP 65 rating when it is panel-mounted in a NEMA rated cabinet or enclosure. -
Page 8: Display Mode
`Figure 1.3: Rear View of EX-91101 1.5 Display Mode Display Mode Hori. Sync (KHz) Vert. Sync. (Hz) VGA 640 x 480 SVGA 800 x 600 XGA 1024 x 768 1152 x 864 SXGA 1280 x 1024 EX-91101 User Manual... -
Page 9: Front Panel Controls
2. Select the icon that you wish to adjust with the ( or +/-) key in the menu. 3. Press (Menu) and then choose the item with the ( or +/-) key. 4. Press (Menu) and then adjust the quality with the ( or +/-) key. EX-91101 User Manual... -
Page 10: Main Menu
In the Main menu, there are the following items: Color Image Setting Position OSD Menu Language Misc Exit For Color, check out the following: Contrast Brightness Color Adjust Color Temp Back For Image setting, check out the following: Clock Phase Gamma Sharpness Back EX-91101 User Manual... - Page 11 Germany Spanish Traditional Chinese Simplified Chinese Japanese In the Misc menu, there are: Signal Source Select VGA: Analogue VGA Input Select DVI: Digital DVI-D Input Select AV: Composite Video Input Select SV: S-Video Video Input Reset Back EX-91101 User Manual...
-
Page 12: Ad Board (Tb-6020) Osd Functions
(don’t let them go) until the AC power cord is connected, and wait for 2 to 3 seconds. When “RGB” appears, repeat the above steps. 3.) Functions of OSD Keys Auto Adjust Up/Left Down/Right Power Menu/Entry Power Indicator EX-91101 User Manual... -
Page 13: Appendix
Appendix_____________________________ Panel Mounting The EX-91101 display monitor is designed to be panel-mounted as shown in Figure A. Just carefully place the unit through the hole and tighten the given 8 screws from the rear to secure the mounting. Figure A: Panelmounting of the EX-91101...
