- Page 1 AV6201A OPENGEAR ANALOG VIDEO DISTRIBUTION AMPLIFIER w/ DIFFERENTIAL INPUT, CLAMPING AND CABLE EQUALIZATION User Manual by WardBeck Systems Rev:Jan.01 2015 ...
- Page 2 WardBeck Part Number: AV6201A • Document Issue: 1 • Printed in Canada The information contained in this User Manual is subject to change without notice or obligation. Copyright © 2 015 WardBeck Systems Ltd. A ll rights reserved. Contents of this publication may not be reproduced in any form without the written permission of ...
-
Page 3: Important Safety Instructions
Important Regulatory and Safety Notices Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below so as to avoid personnel injury and to prevent product damage. Products may require specific ... - Page 4 EMC Notices US FCC Part 15 This equipment has been tested and found to comply with the limits for a class A Digital device, pursuant to ...
-
Page 5: Environmental Information
Environmental Information The equipment that you purchased required the extraction and use of natural resources for its production. It may contain hazardous substances that could impact health and the environment. To avoid the potential release of those substances into the environment and to diminish the need for the ... -
Page 6: Functional Block Diagram
Introduction Overview The AV6201A is an analog video distribution amplifier with a differential input designed for broadcast use. It can provide up to eight outputs when used with a single card rear module, and up to four outputs when used ... -
Page 7: Static Discharge
Installation and Setup Static Discharge Whenever handling the AV6201A and other related equipment, please observe all static discharge precautions as described in the following note: Static discharge can cause serious damage to sensitive semiconductor devices. Avoid ... -
Page 8: Board Installation
Board Installation Use the following procedure to install the AV6201A in an openGear OG3FRC Series frame. 1. Refer to the User Manual of the openGear OG3FRC series frame to ensure that the frame is properly installed according to instructions. 2. -
Page 9: User Controls
User Controls User Control Diagram Figure 3. CardEdge User Controls Level The level control is used to adjust the output levels of the AV6201A. This potentiometer gives precise ... -
Page 10: Jumper Settings
Jumper Settings Selects the input termination, either high impedance or 75 Ohms. Selects between a balanced and differential input configuration. Turns clamping circuit on or off. Remote Control DashBoard Control This card may be monitored by a remote computer through DashBoard the free configuration monitoring ... -
Page 11: Technical Specifications
Technical Specifications INPUT Input Impedance 75 Ohm or HiZ Input Level 1 Vpp, nominal Input Return Loss 46dB Typical, @ 3.58M PERFORMANCE Gain better than 0.05 dB @ 3.58M Differential Gain better than 0.15% @ 3.58M Differential phase better than 0.15 deg @ 3.58M S/N better than 60dB, 5MHz B.W. OUTPUT Output Impedance (8 splits) 75 Ohm Output Level ! Vpp, terminated GENERAL Power Requirements +12 V,120 mA, 7, 5V, 55mA Dimensions 3.025" high x 12.800" deep Weight approx.0.115 kg (0.252 lbs) NOTE: WardBeck Systems Ltd. reserves the right to change performance specifications without prior notice. ... -
Page 12: Warranty And Repair Policy
performance characteristics. Should you find that this openGear AV6201A has failed after your warranty period has expired, we will repair ... -
Page 13: Ordering Information
Ordering Information Standard Equipment ● AV6201A Analog Video Distribution Amplifier w/Differential Input, Clamping and Cable Equalization Distribution Amplifier Optional Equipment ● AV6201AUM Analog Video Distribution Amplifier User Manual (additional User Manual) ● T6301A Single Card Rear Module (for installation into OG3FRC frame for maximum I/O) ● T6401A Dual Card Rear Module (for installation into OG3FRC frame for maximum mono density) ● OG3FRC Digital Products Frame and Power Supply with Cooling Fans (2RU, holds up to 20 cards) Your AV6201A Analog Video Distribution Amplifier is a part of the openGear family of products. WardBeck ...
