INSTALLATION AND
OPERATING MANUAL
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified kit is used.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death or
property damage
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
❖
or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
❖
Do not touch any electrical switch; do not use any phone in your building.
❖
Leave your building immediately
❖
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's
❖
instructions.
If you cannot reach your gas supplier, call the fire department.
❖
Installation and service must be performed by a qualified installer, service
agency or the gas supplier.
Gas Fired Direct Vented Room Heater
Model
Inspiration
Serial Numbers: 600001 - forward
.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
Tested and listed by
0500
#:
UF-
0510
UF-
Archgard Industries
7226 Beatty Drive, Mission, B.C.
Canada, V2V-6B4
April 2014 Rev 1-01
200-0500
Advertisement
Table of Contents
Troubleshooting
Summary of Contents for Ambiance Fireplaces Inspiration UF-0500
-
Page 1: What To Do If You Smell Gas
Gas Fired Direct Vented Room Heater INSTALLATION AND OPERATING MANUAL 0500 Model 0510 Inspiration Serial Numbers: 600001 - forward This appliance may be installed in an aftermarket permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. -
Page 2: Table Of Contents
TABLE OF CONTENTS State of Massachusetts Requirements Control System Components Safety Information System Operation 29 - 32 SIT Pilot Ignition Sequence Flowchart Rating Plate Specifications SIT Burner Ignition Sequence Flowchart Lighting & Shutdown Fireplace Dimensions / Clearances 6 - 7 Relocating Valve and Module First Fire Leveling the unit... -
Page 3: State Of Massachusetts Requirements
STATE OF MASSACHUSETTS REQUIREMENTS 5.08: Modifications to NFPA-54, Chapter 10 (2) Revise 10.8.3 by adding the following additional requirements: (a) For all side wall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than seven (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied:... -
Page 4: Safety Information
SAFETY INFORMATION This appliance was listed by LABTEST Certification Inc and complies with: ANSI Z21.88-2014/CSA 2.33-2014 Vented Gas Fireplace Heaters CAN/CGA-2.17-M91 Gas-Fired Appliances for Use at High Altitudes CSA P.4.1-09 testing method for measuring annual fireplace efficiency. The installation must conform with the local codes or, in the absence of local codes, with the current National Fuel Gas Code ANSI Z223.1/ NFPA 54 or the Natural Gas and Propane Installation Code, CSA B149.1. -
Page 5: Rating Plate
RATING PLATE Made in Canada by / Fabrique au Canada par: Archgard Industries Ltd. 7116 Beatty Dr., Mission, B.C. UF 0500 NG / NATURAL MODEL / MODÈLE: LPG / PROPANE UF 0510 LISTED VENTED GAS FIREPLACE HEATER and GAS-FIRED APPLIANCES FOR USE AT HIGH ALTITUDES. RADIATEUR VENTILE, CIRCULATEUR DU TYPE VENTILATEUR. -
Page 6: Specifications
SPECIFICATIONS FIREPLACE DIMENSIONS DESCRIPTION Height Width Back Depth Opening Glass Width Width Dimensions Inches 20” 28 1/2” 17 5/8” 17 1/4” 30 3/4” 16” x 25 1/4” FIREPLACE DIMENSIONS Millimeters 508mm 724mm 448mm 438mm 768mm 406mm x 641mm CONTROLS FORWARD FRONT Fig. -
Page 7: Relocating Valve And Module
SPECIFICATIONS As an option, the gas valve and/or control module can be moved to a “rear” position. The fireplace has optional mounting holes/ studs for the valve and module to enable their movement. By moving the controls to the rear position, it enables you to install the unit into a smaller or irregular opening. CONTROLS REAR 29.75 25.25... -
Page 8: Leveling The Unit
MINIMUM OPENING DIMENSIONS TOP VIEW Min flue size required 4” (102) x 7” (178) SIDE VIEW DIMENSIONS Controls Forward Controls Back The fireplace flue damper must be fully blocked Inches Millimeters Inches Millimeters open or removed for installation of the gas fire- 20”... - Page 9 MINIMUM OPENING DIMENSIONS Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved WARNING with this appliance may result in property damage or personal injury or loss of life. This appliance is designed for use in any masonry or factory built wood-burning fireplace. It cannot be enclosed CAUTION by combustible material and used as a built-in gas fireplace.
-
Page 10: Factory Built Opening Requirements
FACTORY BUILT - (METAL) WOOD BURNING FIREPLACE REQUIREMENTS Any parts that are removed must be saved and re-installed if insert is ever removed. NOTE The damper (A) and grate (B) must be removed The smoke shelf (C), internal baffles (D), screen ( E), masonry lining or refractory (G and I), and metal or glass doors (F) may be removed. -
Page 11: Mantle Clearances
MANTLE CLEARANCES Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved WARNING with this appliance may result in property damage or personal injury. Fig. 11-A 12” Based on SMALL SURROUND 27” H 9”... -
Page 12: Gas-Line Connections / High Altitude Installation
GAS LINE CONNECTIONS GAS CONVERSION This fireplace is manufactured for use with Natural Gas. Follow the instructions included with the conversion kit if converting to LP gas, (Sold separately). Adequate clearance for proper installation and checking of the gas connections must be provided. All gas connections must be checked for gas leaks. -
Page 13: Pressure Testing
PRESSURE TESTING CHECKING INLET PRESSURE 1. Remove the surround. 2. The pressure taps are located on the gas valve front face. The inlet is marked ‘IN’. 3. Loosen the set screw inside the tap and attach a manometer using 1/4” (6 mm) rubber tube to the tap post 4. -
Page 14: Electrical Connections / Light Kit Installation
ELECTRICAL CONNECTIONS .Do not cut or remove the grounding prong from this plug. NOTE: This appliance, when installed, must be electrically grounded in accordance with local codes or, in the absence of local codes, with the National Electrical Code, ANSI / NFPA 70, or the Canadian Electrical code, CSA C22.1. -
Page 15: Wiring Diagram - Control Module
WIRING SCHEMATICS... -
Page 16: Venting
VENTING WARNING: Operation of this heater when not connected to a properly installed and maintained venting sys- tem can result in carbon monoxide (CO) poisoning and possible death. The appliance must not be connected to a chimney flue serving a separate solid fuel burning appliance. APPROVED VENT TERMINATIONS / KITS Manufacturer Vertical Termination... - Page 17 VENTING INSTRUCTIONS 999-INS-TK Instructions for use with Archgard vertical termination cap. Part # 999-INS-TK Install the termination cap being sure to provide sufficient space (around and on top) so as not to impede the flow of air, both into and out of the cap. This cap is only to be used for non combustible installations. Do not recess into the top of the chimney.
-
Page 18: Venting
VENTING VENT TERMINATIONS LOCATIONS Termination clearances*: Vent termination NOTE From opening windows: 2ft min *Measured from Side of Termination From opening doors: 2ft min Overhangs or Air intake 2ft min Archgard Termination: 999-INS-TK Fig 18-A Fig 18-B 3” 3” NOTE For elevations above roof line see chart below itch Pitch... -
Page 19: Logs And Placement
UF0500 LOG PLACEMENT LOCATOR PINS Pilot Cover DO NOT block pilot opening with embers or glass media material CAUTION Installing the fiber logs in any other position other than shown will result in flame NOTE impingement causing sooting of the logs, brick liner and ceramic glass viewing area. Log# 1 LOG 1 Align the holes of log# 1 with the two locater pins at the back of the... - Page 20 UF0500 LOG PLACEMENT…. Con’t Log# 4 LOG 4 Rest the back of Log #4 on the locator pin on the back edge of Log #3. Place the front of Log #4 onto the burner locator pin. Log# 5 LOG 5 Rest Log #5 on top of Log #1 along the rear right hand side.
- Page 21 UF0500 LOG PLACEMENT…. Con’t UF-0500 LOG 1 LOG 5 LOG 6 LOG 3 LOG 2 LOG 4 LOG 7 Final step is to add the Black Embers to the burner. Use the embers to cover any exposed burner surface not covered by logs. When placing embers around the pilot shield take care to not block the pilot open- ATTENTION ing.
-
Page 22: Contemporary Burner Set-Up
UF0510 CONTEMPORARY MEDIA & BURNER UF-0510 Glass Beads Installation The UF-0510 comes from the factory with the contemporary burner installed . This unit does not have logs, but is instead completed with colored glass beads or ceramic rocks to give your fireplace the sleek cosmopolitan look. Installation is as simple as spreading the beads you have chosen, evenly over the burner so that it is completely covered. - Page 23 UF0510 CONTEMPORARY MEDIA & BURNER Ceramic Rock Installation The ceramic rocks should be installed in three steps. First randomly place the larger size rocks so they do not completely block the burner ports or the six round secondary air Second, randomly fill in the gaps with the medium size stones so they do not directly block off the air or burner ports. They can be placed over the ports as long as they do not completely block them off.
-
Page 24: Glass Door Removal & Replacement
GLASS DOOR REMOVAL AND REPLACEMENT Do not operate appliance with the glass front cracked or broken. Replacement of the glass WARNING should be done by a licensed or qualified service person. CAUTION Do not attempt to remove the glass door when the appliance is hot Just above the door frame reach in and pull the two finger rings forward. -
Page 25: Safety Barrier Installation
SAFETY BARRIER INSTALLATION A barrier designed to reduce the risk of burns from the viewing area is provided WARNING with this appliance and shall be installed for the protection of children and other at- risk individuals The manufacturer supplied barrier is to be secured to the door frame and in place once the licensed gas fitter has completed the installation and turned over the operation of the appliance to the homeowner. -
Page 26: Surround Installation
SURROUND INSTALLATION Make sure the gas and electrical lines are properly connected to the appliance. Slide the unit into the fireplace and slide the excess flue liner material back onto the chimney. Before the appliance is fully recessed into the fireplace, attach the surround onto the appliance. ... -
Page 27: Final Installation Check
FINAL INSTALLATION CHECK Each gas fireplace is checked and tested at the factory prior to being packaged and shipped to our dealers and finally installed in your home. We recommend that before leaving this unit with the customer, the installer must ensure that the appliance is firing correctly and that the electrical system is in working order. -
Page 28: Control System Components
CONTROL SYSTEM COMPONENTS REMOTE CONTROL N/A on this unit GAS VALVE Main Valve Connection (green) Outlet pressure tap 0.885.009 Pilot connection (orange) Stepper motor Inlet pressure tap Pilot flame adjustment PILOT ASSEMBLY Pilot Hood Sensor Probe Spark Ignitor Conversion tab... -
Page 29: System Operation
SYSTEM OPERATION INITIALIZING THE SYSTEM FOR THE FIRST TIME Connect IFC Control Module to AC power supply. A single “beep” will indicate the presence of power. NOTE: This will initiate Pilot Start-up in Manual Mode. The pilot will spark repeatedly and ignite if gas has been supplied to the unit. - Page 30 SYSTEM OPERATION ROOM THERMOSTAT (via Remote) The Remote can operate as a room thermostat. The remote can be set to a desired temperature to control the comfort level in a room. To activate this function, press the THERMOSTAT Key. The LCD display will change to indicate the room thermostat is “ON”...
- Page 31 SYSTEM OPERATION LOW BATTERY DETECTION REMOTE CONTROL: Remote control battery lifespan depends on various factors including battery quality, number of ignitions, changes to room temperature set points, etc. When remote control batter- ies are low, a Battery Icon will appear on the LCD display before all battery power is lost. When bat- teries are replaced this icon will disappear.
-
Page 32: System Operation
SYSTEM OPERATION S.I.T. PROFLAME II RESET INFORMATION Reset Using Main and Auxiliary Power: Turning all the system power supplies OFF for a minimum of 2 seconds. Do not forget to disconnect the battery-back up power supply. Reset Using ON/OFF Switch: Set ON/OFF switch to OFF position. -
Page 33: Sit Pilot Ignition Sequence Flowchart
SYSTEM OPERATION SIT INTERMITTENT PILOT IGNITION SEQUENCE FLOWCHART If the appliance goes into a Lock-out mode repeatedly, please contact a Licensed WARNING Service Tech for Troubleshooting and Service... -
Page 34: Sit Burner Ignition Sequence Flowchart
SYSTEM OPERATION BURNER IGNITION SEQUENCE If the appliance goes into a Lock-out mode repeatedly, please contact a Licensed WARNING Service Tech for Troubleshooting and Service... -
Page 35: Lighting & Shutdown
LIGHTING AND SHUTDOWN FIRST FIRE When operated for the first few times, the appliance will emit some odor and fumes. This is due to the heat from the appliance evaporating the oils and solvents used in fabricating the appliance. Close off the room to the rest of the house and open all windows. Keep the room well ventilated, as smoke alarm may sound. -
Page 36: Initial Operation
LIGHTING AND SHUTDOWN (cont.) OPERATING INSTRUCTIONS INITIAL OPERATION Read safety information on previous page and front cover of this manual READ FIRST !!! before continuing Turn off all electrical power to the appliance. Cycle hand-held remote to OFF on the display. Wait five (5) minutes to clear out any gas. -
Page 37: Lighting Instructions
LIGHTING INSTRUCTIONS APPLIANCE MARKING... -
Page 38: Finalizing The Installation
FINALIZING THE INSTALLATION FLAME APPEARANCE NOT IDEAL: IDEAL: Ghosting Flame, black tips Lazy Yellow Flame Not enough primary air Excess burner media Improper venting NOT IDEAL: NOT IDEAL: Lifting Short Blue Flame Improper venting Excess primary air. Excess gas pressure Venturi open too far CHECKING AND ADJUSTING PILOT The pilot flame should have the characteristic... -
Page 39: Checking & Adjusting The Pilot
MAINTENANCE Do not conduct maintenance on the appliance while it is operating or while it is still hot. Caution INSTALLATION,INSTALLATION AND SERVICE SHOULD ONLY BE DONE BY A QUALIFIED TECHNICIAN. THE APPLIANCE SHOULD BE INSPECTED BEFORE USE AND ANNUALLY BY A QUALIFIED SERVICE PER- NOTE SON.MORE FREQUENT CLEANING MAY BE REQUIRED DUE TO EXCESSIVE LINT FROM CARPET- ING,BEDDING MATERIALS ETC. -
Page 40: Maintenance & Cleaning
ADJUSTING PRIMARY AIR NOTE: Figure 1 is to give an example of what a correct or incorrect flame pattern looks like. It is not a true represen- tation of what the UF-0500/0510 will look like in your home environment. The air shutter can be adjusted from the front of the unit while in operation. All adjustments should be made after 20 minutes of operation. -
Page 41: Troubleshooting
TROUBLESHOOTING ATTENTION TROUBLESHOOTING MUST BE PERFORMED BY A QUALIFIED SERVICE TECHNICIAN Pilot will not light /Stay lit ❖ Restore power to fireplace ❖ Replace batteries if depleted Electrical power interrupted or disconnected ❖ Use Battery Back-up Verify Gas supply is on Check shut-offs. -
Page 42: Troubleshooting
TROUBLESHOOTING Soot in firebox ❖ Improper venturi setting for primary air. Adjust to stabilize the burn ❖ Restricted air intake. Check and clear if blocked Excessive black soot on the burner and/or side walls ❖ Too much fuel. Check gas pressure ❖... -
Page 43: Frequently Asked Questions
FREQUENTLY ASKED QUESTIONS Listed below are some frequently asked questions regarding gas fireplaces. If you have questions that are not listed below, or are not answered in this manual, please contact your Authorized Dealer. Q. My glass has a condensation “fog” when the appliance is first lit. A. -
Page 44: Conversion Kit Instructions
CONVERSION KIT INSTRUCTIONS IMPORTANT This fireplace is manufactured as Natural Gas ready. If converting to LP gas, follow instructions below This conversion kit shall be installed by a qualified service agency in accordance with the manufacturers instructions and all applicable codes and requirements of the authority having jurisdiction. If the infor- mation in these instructions is not followed exactly, a fire, explosion or productions of carbon monoxide WARNING may result, causing property damage, personal injury or loss of life. -
Page 45: Conversion Kit Instructions
CONVERSION KIT INSTRUCTIONS CONT. CONVERTING THE GAS VALVE COMPLETE THE CONVERSION Turn on the gas and electrical supplies. Turn on the fireplace so the burner is on Check for leaks at all connections. Test inlet and outlet pressure. Visually check pilot flame. Flame should envelope top of the flame sensor and extend forward onto the burner. -
Page 46: Replacement Parts List
REPLACEMENT PARTS LIST (UF-0500/0510) Item # Item Description Unit 200-0500 Owner’s Manual 308-6011 SIT Pro Flame II Electronic Control Module 308-6014 SIT Pro Flame II Handheld Transmitter 308-6027 SIT 885 Gas Valve c/w Step Motor (0.885.009) 305-6002 Module Main Wiring Harness (5 wire) 305-6003 Valve Wiring Harness (4 wire) 305-0060... -
Page 47: Limited 10 Yr Warranty
LIMITED 10 YEAR WARRANTY LIMITED 10 YEAR WARRANTY This Limited 10 Year Warranty will not become effective until the Warranty Registration Form has been completed and mailed to Archgard Industries, 7116 Beatty Drive, Mission, BC, Canada, V2V 6B4. This registration form must be received within 30 days of installation. -
Page 48: Limited Lifetime Warranty
LIFETIME WARRANTY LIFETIME WARRANTY LIFETIME WARRANTY THIS LIFETIME WARRANTY COVERAGE WILL BE EXTENDED AS DESCRIBED BELOW PROVIDED ALL WARRANTY CONDITIONS AND REQUIREMENTS ARE MET AS OUTLINED IN THE 10 YEAR LIMITED WARRANTY POLICY LIFETIME WARRANTY COVERAGE LIFETIME WARRANTY IS EXTENDED AS FOLLOWS: Archgard Industries warranties to the original purchaser that the firebox, heat exchanger, fibre logs, pan burner and glass panel of this Ambiance Fireplace will not be defective in the material or workmanship under nor- mal use and service as long as you own this product.
