M
622
ODEL
L
C
D
IQUID
OFFEE
ISPENSER
For use with shelf stable liquid coffee
GENERAL DESCRIPTION
This model 622 - two flavor dispenser is designed for use with liquid concen-
trate of various ratios (80:1-5:1). The model 622 uses peristaltic pumps to
deliver the coffee concentrate and vend valves that deliver the water. The dis-
pense ratio is 1 to 1.5 ounces per second. The dispensers efficient hot water
tank produces portion sizes up to 60 ounces from cold water lines. If high vol-
umes are needed, a hot water line connection can be made, or the dispenser
can be connected to 240v.
SPECIFICATIONS
DIMENSIONS:
Overall 9
" W x 26"D x 28
"H
CONSTRUCTION:
All Stainless Steel Cabinetry
ELECTRICAL:
115 V 50/60 HZ 12 amps or 208/240 V 50/60 HZ
12 amps @ 240V
PLUMBING:
1/4" Waterline Filters
WATER RESERVOIR:
1 3/4 Gallons
Producers of dependable dispensing equipment
for the food and beverage industries.
KARMA dispensers are covered by one or more U.S. patents and applications and corresponding foreign patents and applications.
MODEL 622
DISPENSE SPOUTS:
2 independent mechanism for product
1 spout for hot water (center)
OPERATION:
Timed for each flavor
DISPENSE RATE:
1.5 ounces per second
PRODUCT COMPARTMENT SIZE:
8"H x 8"W x 9"D
SHIPPING WEIGHT:
68 lbs.
P.O. Box 433
Watertown, WI 53094 USA
920-261-1424
800-558-9565
Fax 920-261-3302
800-257-6806
Internet Web Page
http://www.karma-inc.com
E-mail - karma@karma-inc.com
Advertisement
Table of Contents
Related Manuals for Karma 622
Summary of Contents for Karma 622
-
Page 1: Specifications
800-558-9565 Fax 920-261-3302 Producers of dependable dispensing equipment 800-257-6806 for the food and beverage industries. Internet Web Page http://www.karma-inc.com KARMA dispensers are covered by one or more U.S. patents and applications and corresponding foreign patents and applications. E-mail - karma@karma-inc.com... -
Page 2: Table Of Contents
CAUTION: THE HOT WATER IN WATER DO NOT ATTEMPT TO REPAIR, ADJUST TANK CAN CAUSE SEVERE BURNS. WHEN OR REPLACE COMPONENTS WITHOUT UNPLUGGING ELECTRICAL CORD. SERVICING OR CLEANING DO NOT TIP OR MOVE MACHINE CAUSING WATER TO SPILL. CAUTION: WATER PIPE CONNECTIONS AND FIXTURES DIRECTLY CONNECTED TO A PORTABLE WATER SUPPLY SHALL BE SIZED, INSTALLED AND MAINTAINED ACCORDING TO FEDERAL, STATE, AND LOCAL LAWS. -
Page 3: Installation
- NOTES - INSTALLATION 1. Connect a 1/4” waterline from a filtered source that provides a minimum flow rate of 1 GPM. 2. The electrical connection on the 115 V model requires a minimum 15 amp outlet for the line cord to be plugged into. 3. -
Page 4: Start Up
NOTE: YOUR MODEL 622 IS SHIPPED WITH PUMP ROTORS IN THE UNLOCKED POSITION. PRIOR TO PRIMING, LOCK BOTH PUMP ROTORS (See Figure 2). -
Page 5: Timer Adjustments
DISCLAIMS ALL IMPLIED WARRANTIES INCLUDING THE IMPLIED WARRANTY OF MERCHANTABILITY AND FITNESS FOR ANY PARTICULAR PURPOSE INDICATED BY PURCHASER TO KARMA. 2. The sole obligation of KARMA hereunder shall be limited to repair or replacement, at the option of KARMA, of any Fig. 4 defec tive products expressly warranted under the terms of this Agreement. -
Page 6: Calibration
CALIBRATION OPTIONAL Fig.6 Fig.7 The calibration can be adjusted by removing the small panel on the right side of machine (See Fig. 6). Depending on the tubing size that is through the peristaltic pumps. Follow the chart located around speed dials (See Fig. 7). STANDARD The machine has been factory set to the ratio defined at time of ordering. -
Page 7: Cleaning
CLEANING ONCE DAILY: 1. Open the door and turn OFF the concentrate switch. 2. Using large vessel, dispense approximately 1 liter of water on each side. 3. Turn the concentrate switch ON and close door. 4. Clean the drip tray and the tray insert with a solution of mild dishwashing detergent and rinse with hot water. -
Page 8: Trouble Shooting
TROUBLESHOOTING / CORRECTIVE ACTION PROBABLE CAUSE CORRECTIVE ACTION PROBLEM A. Position the switches to “ON” position. A. Concentrate motor turned off. 1. Dispenser dispenses water B. Feed tubing correctly. B. Tubing fed through pump incorrectly. only - no concentrate (with C.
