See Warranty on page 14 for important information about commercial use of this product.
BUILT TO LAST
Product Manual
Please record Model No. and Serial No. for use when contacting
the manufacturer:
Model No. ______________
Serial No. ______________
For Information About This Product, call 1-800-330-0712
Contents
Frequently Asked Questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety and Warning Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Assembly and Pre-Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4 - 5
Startup, Operation, Shutdown, and Storage . . . . . . . . . . . . . . . . . . . . . . . . 6 - 10
Maintenance and Technical Information . . . . . . . . . . . . . . . . . . . . . . . . . . 10 - 11
Troubleshooting Chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 - 13
Service Record and Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Carefully read and understand these instructions before
REMINDER: Keep your dated proof of purchase for warranty purposes! Attach it to this manual or file it for safekeeping.
© 2003 Campbell Hausfeld/Scott Fetzer
Gasoline Powered
Horizontal Pressure
Washers
Purchase date ____________________
Purchase place ____________________

operating your pressure washer.

For parts, product & service information
visit www.chpower.com
PW2120, PW2420, PW2458, PW2705
Page
IN462400AV 8/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PW2120 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Campbell Hausfeld PW2120

Summary of Contents for Campbell Hausfeld PW2120

  • Page 1: Operating Your Pressure Washer

    See Warranty on page 14 for important information about commercial use of this product. Gasoline Powered Horizontal Pressure Washers BUILT TO LAST Product Manual PW2120, PW2420, PW2458, PW2705 Please record Model No. and Serial No. for use when contacting the manufacturer: Model No. ______________ Purchase date ____________________ Serial No. ______________...
