- Page 1 Sidekick II Receiver Model # SK09214-2 318 MHz Installation Operation Guide 3 1 2 6 0 5 2...
- Page 2 SK09214-2 INITIAL SETUP: The Silent Call Model SK09124-2 is packaged with the following items. • AC Power Adapter supplying 16 vdc@1.12amps • SK09124-2 Quick Start Manual • SK09124-2 Instruction Manual • RJ11 Splitter • 7 Ft Telephone cable Inspect all items when removing from packaging for damage or misuse. •...
-
Page 3: Lcd Display
ALARM CLOCK FEATURE: SETTING ALARM CLOCK: • Press and release the MODE button twice. • The Green LED will light up indicating that you are in the “SET UP” mode. The display will show the present Alarm Clock Time setting. •... - Page 4 DISPLAY AND LED DESCRIPTION: When the Sidekick II Legacy Series Receiver detects an incoming signal from any of the Legacy Series trans- mitters it will notify you by displaying the appropriate ICON and illuminating the appropriate LED. Transmitter Type: ICON: Notification: Alarm Clock Bell Icon, Strobe fl...
-
Page 5: Transmission Range
VIBRATOR DESCRIPTION: If you are using the optional Bed Vibrator and your Sidekick II Legacy Series Receiver detects an incoming signal from any of the Legacy Series transmitters, along with the above Notifi cations, the bed vibrator will also pulse in a specifi c pattern for each transmitter. Alarm Clock Two Short Pulses and One Long •... - Page 6 UNITECH 12VDC 1500maH Ni-MH back-up battery. Replacement batteries can be ordered online at www.SilentCall.com or by calling 800-572-5227. The Sidekick II Legacy Series receiver Model #BU-10 has been tested to provide back-up for 24 hours in Stand By mode and 15 minutes in full operational mode, (with both the strobe and vibrator operating).
- Page 7 • Remove battery access cover screw and cover. • Remove Battery by gently disconnecting plug on SK09214-2 main board located in battery compartment. • Gently connect new battery to two pin jack on SK09214-2 main board located in battery compartment. Inspect connector is correctly seated and secure.
-
Page 8: Specifications
0.4A. Output: 16.0 VDC 1.12A, 18 Watts Max. Battery Backup: 12 VDC, Unitech 1500 mAH Ni-MH Battery. P/N BU-10 Order Online @ www.silentcall.com or call 800-572-5227. WARNING: Use only Battery specifi ed in marking. Use of a different battery will have a detrimental effect on alarm oper- ation.
