Summary of Contents for Heatzone REA-TD
- Page 1 How to Use Your Heater How to install and use your REA-TD electric thermal radiator REA-TD electric thermal radiator...
- Page 2 A brief forward First of all, we would like to thank you for having bought an EV product; we hope that will give you years of reliable heating. Before installing the heater, please read the following instructions carefully. EV is not responsible for any damage or problems resulting from incorrect installation.
-
Page 3: Table Of Contents
1.1 Turning on 1.2 The control panel 2. Some useful tips 2.1 Remote control IC-04 IR Installation 1. Before installing 2. Hanging the heater 3. Connecting the radiator to your electricity supply 3.1 REA-TD electric scheme 4. Technical characteristics Cuarantee... - Page 4 How to Use Your radiators...
- Page 5 How to Use Your Radiators 1. The control panel...
-
Page 6: How To Use Your Heater
1.1 Turning on Once hung and connected to the electricity supply, the radiator is ready to use. In addition to the control panel, REA-TD electric thermal radiator has a safety switch, on the right-hand side. For the heater to work this switch must be turned to “I”. -
Page 7: Some Useful Tips
To make using your radiator as easy as possible, you can now buy the IC-04 IR, as an additional extra. It means you can set your radiator via this remote control. The REA-TD has an infrared receiver inbuilt. Once you have the matching remote control, the IC-04 IR, you can: ·... -
Page 8: Before Installing
How to Use Your Radiator... -
Page 9: Installation
Installation 1. Notes Whilst the installation of this heater is incredibly straightforward, please ensure you read the following carefully as EV will not be liable for any damage or problems arising from incorrect installation. Unwrap your heater and clear the packaging away. The packaging has been specifi - cally chosen to allow you to recycle it. -
Page 10: Wall Mounting
Installation 2. Wall mounting The radiator comes complete with an installation kit, comprising the following: · Screws · Brackets (See diagram 15 on page 1 1) · Hooks (diagram 16 on page 1 1) · Cardboard guide, (remove from the top of the box the radiator comes in) Please follow the illustrated steps below to hang and install your radiator: A. -
Page 11: Connecting The Radiator To Your Electricity Supply
Installation (15) (16) [10] [1 1] [12]... - Page 12 · Any problem arising from not following the instructions above will invalidate your guarantee · When wiring up, please follow the diagrams below, paying particular attention to the colors of wires. B1: Selt-resetting termal cut-out 3.1 REA-TD Wiring electrical scheme rea-td ESQUEMA ELECTRICO TAR -ED Live...
-
Page 13: Technical Characteristics
Installation 3. Technical Characteristics Technical data 375-TD 500-TD 625-TD 750-TD 875-TD 1000-TD 1 125-TD 1250-TD 1375-TD 1500-TD Nominal output (W) 1.000 1.125 1.250 1.375 1.500 Absorbed intensity (A) Nominal tension/Frec. (Hz) — 220 / 240 V - 50 Hz — Output capacity (Kc/h) 1.075 1.182... - Page 14 Installation Notes...
- Page 15 In the fi nal case of resorting to legislation, both parties will be under the jurisdistion of courts in Lugo. Should you prefer, you can fi ll out your guarantee form at www.evconfort.com or e-mail your details to comercial@evconfort.com Reicor Ireland & UK Ltd for Heatzone 40 Woodvale Drive Clonsilla Dublin 15...
-
Page 16: Cuarantee
Electromecánicos Viveiro S.A. C.I.F. A2719391 1 Landrove s/n 27866 Viveiro ( LUGO) comercial@evconfort.com...
