Page 2 6....General Operation Foreword Thank you for your purchase of this Streacom product. Every care has been taken to ensure that it meets with the highest quality and standards that we have set for ourselves. Should you have any questions that are not covered in this user guide, support can be offered via email through our website at www.streacom.com...
Page 3 Specification Valve Tube Model Power Output 2.5W + 2.5W @ 8 Ohms Frequency Response 800Mv Residual Noise < 0.6 mV AC Input Voltage 100 - 240V AC Standard IEC Jack with fuse protection (2A) Power Consumption Input Impedance 10K Ohms Output Impedance 16/8/6/4 Ohms Dimensions...
Page 4 With the amplifier unpacked, check the vacuum tubes have not been damaged and are properly installed into the sockets. You can now place the TL1 in the appropriate location near your audio source. P4 - UNPACK AND POSITION...
Page 5 0Ω Audio Mains Source Power Audio Source - Connect the amplifier to your audio source e.g. the line out from your HTPC Power - Finally connect the amplifier to the mains electricity socket, 100-240 VAC CONNECTING THE TL1 - P5...
Page 6 Do not operate or store the TL1 in damp conditions. Never operate the TL1 without speakers connected, doing so can cause permanent damage. There are no user serviceable parts inside the amplifier and it should only be opened by a qualified service engineer.
Page 7 Melbournestraat 56, 3047 BJ Rotterdam, The Netherlands www.streacom.com V1.12.02...
