Summary of Contents for MB QUART MM-1
- Page 2 Enjoy the “direct wire” benefits of the MM-1 and the outstanding sound quality it provides. FEATURES...
- Page 3 4. Turn the MM-1 volume to minimum 5. Turn the iPod / MP3 player volume to maximum. 6. Turn the Radio / CD player on (note: radio must be on to use MM-1) 7. Adjust the MM-1 volume to your preferred listening level.
-
Page 4: Installation Instructions
1. Using a small flat blade screw driver, connect 3 different color wires (one each) to the green power connector on the back of the MM-1 module labeled “- REM +”. We recommend you choose red for +, black for - & blue for REM. -
Page 5: Wiring Diagram
WIRING DIAGRAM BACK OF CONTROL HEAD FRONT OF CONTROL HEAD MAXXSONICS MAXXSONICS INPUT MM-1 MM-1 36” rj45 cable to connect the control head to the control module. MM-1 MM-1 INPUT FRONT CONTROL MODULE BACK INPUT OUTPUT MM-1 LEVEL - REM + 6V - 0.2V... - Page 6 DIMENSIONS 5.5” 4.75” 5.5” 4.9” 6.75” 1.9” 2.25” 1” 1.25” 1.75” 1” 2.75”...
- Page 7 Maxxsonics Limited Warranty As the manufacturer of Maxxsonics, Autotek, MB Quart, Crunch and Hifonics car audio products, Maxxsonics USA Inc. Warrants to the original consumer purchaser the amplifier to be free from defects in material and workmanship for one (1) Year from date of purchase.
