PS-10/PS-12
S C
YSTEM ONNECTIONS
If you have a Dolby* Digital or
DTS ® receiver/processor with a
low-frequency-effects (LFE) or
subwoofer output:
Set LFE/Normal switch to "LFE."
If your receiver/processor does
not contain a Dolby Digital or
DTS processor but has
subwoofer outputs:
RECEIVER/PROCESSOR
L R
Set line-level/LFE switch to
"Normal."
NOTE: If your receiver/processor
has only one sub out, you may use
either the L or R input.
SUBWOOFER OR
LFE OUTPUT
LEVEL
Green: On
Max
Min
Red: Stand-By
LFE NORMAL
PHASE
0º 180º
80Hz
CROSSOVER
FREQUENCY
50Hz 150Hz
L R
LINE LEVEL IN
For LFE use L or R
LEVEL
Green: On
Max
Red: Stand-By Min
LFE NORMAL
PHASE
0º 180º
80Hz
CROSSOVER
FREQUENCY
50Hz 150Hz
L R
LINE LEVEL IN
For LFE use L or R
L
HIGH
LEVEL
IN
R
+ –
If your receiver/processor does not have
subwoofer outputs for the left and right
channels or an LFE output, connect
speaker wire from your receiver/amplifier
to your speakers and subwoofer using
two sets of speaker wire:
RECEIVER/AMPLIFIER
Front Speaker Output
BLACK =
1. LOOSEN TERMINALS
2. INSERT BARE END;
TIGHTEN TERMINALS
NO STRIPE =
This figure shows how to connect bare wires to the terminals.
7
LEVEL
Green: On
Red: Stand-By
Min
LFE
PHASE
0º
80Hz
CROSSOVER
FREQUENCY
50Hz
L R
LINE LEVEL IN
For LFE use L or R
L
HIGH
LEVEL
IN
R
+ –
+
RED =
–
– +
STRIPE =
PS-10/PS-12
Max
NORMAL
180º
150Hz
