Controls & Connections - Infinity PS-12 Service Manual

PS-10/PS-12
C C
ONTROLS AND
Rear Panel
•
Green: On
Red: Stand-By
§
+ –
ON
POWER
CAUTION
RISK OF ELECTRIC SHOCK
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRICAL
SHOCK DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
AVERTISSEMENT:
ÉLECTRIQUE, ÉVITER D'EXPOSER CET APPAREIL A LA PLUIE OU A L'HUMIDITÉ.
PS-10/PS-12
ONNECTIONS
¡
™
LFE NORMAL
£
0º 180º
80Hz
¢
50Hz 150Hz
∞
L R
For LFE use L or R
L
HIGH
LEVEL
IN
R
¶
OFF
120V
60Hz
DO NOT OPEN
NRTL/C
CSA 22.2
UL1492
POUR PRÉVENIR LES RISQUES D'INCENDIE OU DE CHOC
¡ Subwoofer-Level Control
™ LFE/Normal Selector
£ Phase Switch
¢ Crossover Adjustment
∞ Line-Level/LFE Input
§ Speaker-Level Inputs
¶ Power Switch
• Status LED
