Video Flyer 7"
(Model: VF-070M)
1
Introduction
The 7" VideoFlyer is a self-contained digital video viewing monitor for looping video display with a
touchscreen (option) video. The unit comprises of a 7" colour TFT LCD panel with speaker built-in
(Enclosed version). The video can be stored and played back from a plug-in and play
CompactFlash Card.
IMPORTANT USAGE NOTE
This equipment is for use by developers and integrators, the manufacturer accepts no
liability for damage or injury caused by the use of this product. It is the responsibility of
the developer, integrators or other user of this product to:
•
Ensure that all necessary and appropriate safety measures are taken.
•
Obtain suitable regulatory approvals as may be required.
•
Check power settings to all component parts before connection.
DISCLAIMER
There is no implied or expressed warranty regarding this material.
User Guide
- 1 -
V1.0
Advertisement
Table of Contents
Summary of Contents for digitalview Video Flyer 7” VF-070M
- Page 1 Video Flyer 7” User Guide V1.0 (Model: VF-070M) Introduction The 7” VideoFlyer is a self-contained digital video viewing monitor for looping video display with a touchscreen (option) video. The unit comprises of a 7” colour TFT LCD panel with speaker built-in (Enclosed version).
-
Page 2: System Designs
System Designs 7” VideoFlyer (VF-070M) CF Card slot Power / Status LED Remote Ext. On/Off switch Speaker Speaker Power in (DC 12V) COM port L1 (Button 8) + power up - Config mode L1 (Button 8) - Select L2 (Button 7) - + / Save and exit L3 (Button 6) - - / Save and exit 7”... -
Page 3: Touch Screen Operation
Touch Screen Operation (only applicable in touch screen option) 1. Touchscreen touch segments The VideoFlyer’s button control can be performed via touchscreen for panel sizes of 7” (Fig. 1) Button 4 Button 1 Button 7 Button 2 Button 5 Button 8 Button 3 Button 6 Fig.1... - Page 4 Instructions CAUTION: Never connect or disconnect parts of the system when the system is powered up as this may cause serious damage. 1) Setting Up • Connect the provided external power supply unit. • All the features described in the following points can be set by the DV Studio software. See DV Studio User Guide for more details.
- Page 5 Simple play mode • In simple play mode, the user just copies all video files (.mpg) or JPEG files (.jpg) onto the Compact Flash card. The VideoFlyer will play these files in alphabetical sequence. • For JPEG files, the play time is determined by the last digit of the filename. (For example: APPLE5.mpg, where “5”...
- Page 6 Dimension View Area = 154 x 86.6mm Overall Dimension: 211mm(L) x 122.5mm(W) x 45.5mm(D) View Area = 154mm x 86.6mm M3-Thread typ 4 VideoFlyer 7” (VF-070M) - 6 -...
- Page 7 168.4 43.1 Welding Edge 24.1 Welding Edge View Area 168.4 Overall Dimension: 168.4mm (L) x 102.4mm (W) x 43.1mm (D) View Area = 154mm x 86.6mm VideoFlyer 7” Openframe (VF-070M-OF) - 7 -...
-
Page 8: Specification
Specification Playback video format 1. MPEG-1 video (Video-CD), MPEG-2 video (DVD), MPEG-4 2. MPEG still picture, MP3 audio, JPEG picture Video storage CompactFlash memory cards (Type I/II) LCD display Color TFT Screen size 7” (Diagonal) Screen active area 154(H) x 86.6(V) mm Panel resolution 480(W) x 3(RGB) x 234(H) Brightness... -
Page 9: Warranty
WARRANTY The products are warranted against defects in workmanship and material for a period of one (1) year from the date of purchase provided no modifications are made to it and it is operated under normal conditions and in compliance with the instruction manual. -
Page 10: Contact Details
ASIA: Digital View Ltd floor, Tai Tung Building 8 Fleming Road Wanchai Hong Kong Tel: (852) 2861 3615 Fax: (852) 2520 2987 sales@digitalview.com Sales: EUROPE: Digital View Ltd 6 Marylebone Passage London W1W 8EX Tel: (44) (0)20 7631 2150 Fax: (44) (0)20 7631 2156 sales@digitalview.com...
