4 CHANNEL HDA DVR

Q-HDA-4

User's Manual

V1.0 11 / 2014

Table of Contents

Need help?

Do you have a question about the Nitro Q-HDA-4 and is the answer not in the manual?

Questions and answers

Summary of Contents for OYN-X Nitro Q-HDA-4

Page 1 4 CHANNEL HDA DVR Q-HDA-4 User’s Manual V1.0 11 / 2014...
Page 2: Table Of Contents
16 Network Setup 17 Alarm 18 PTZ Control 19 System Setup 20 Web Monitoring 21 Special Function 22 Multi-Channel Playback 23 File Storage 24 FAQ: Troubleshooting Appendix 1: Remote controller operation Appendix 2: Mouse operation © Copyright OYN-X® All documentation rights reserved.
Page 3 Reduces power consumption and extends device life-span. Special storage format which ensures data safety.  Compression H.264 Real-time compression by each individual hard disk, which ensures that the audio and video signals have stable synchronisation. © Copyright OYN-X® All documentation rights reserved.
Page 4 Monitor recorded footage and real-time playback.  Alarm linkage Alarm activated video recording, tour, message, buzzer, e- mail, and FTP.  Communication interface RS485 interface provides a connection for the alarm input and PTZ control. © Copyright OYN-X® All documentation rights reserved.
Page 5 Also allows as interfacing with another computer with a serial port connection, to perform system maintenance & upgrades, matrix control, etc. Standard Ethernet network interface fulfills telecommuting function © Copyright OYN-X® All documentation rights reserved.
Page 6: Important Safeguards & Warnings
Be sure to use all the accessories recommended by manufacturer.  Before installation, please open the package and check all the components are included.  Contact your local retailer ASAP if something is broken in your package. © Copyright OYN-X® All documentation rights reserved.
Page 7: Front & Rear Panels
Front & Rear Panels Front Panel 2.1. IR LED remote Power to Recording receiver device indicator indicator Alarm Indicator Escape/stop Menu Select task button Button Ok/confirm Directional button Control buttons © Copyright OYN-X® All documentation rights reserved.
Page 8 9 10 Video Video Audio HDMI Inputs Output Output Video Port (BNC) (BNC) 2 x Stereo Ethernet 2 x USB Video Input Ports Port Ports Out Port (Internet) RS485 DC12V Port Input (PTZ) © Copyright OYN-X® All documentation rights reserved.
Page 9: Basic Information
Alarm output cannot be connected to a high-power load (no more than 1Amp).  When forming the output loop you must prevent high current levels from damaging the relay. Please use the contact isolator when there is a high- power load. © Copyright OYN-X® All documentation rights reserved.
Page 10: Startup
There are two methods to turn off the DVR, either the soft switch or the hard switch. Soft switch: Entering [Main menu] and choosing [Logout] in the [turn off the system] option. Hard switch: Pressing the power supply switch. © Copyright OYN-X® All documentation rights reserved.
Page 11: Login
To prevent this from happening, please revise and remember user name and password before logging back into the system. When you login, the system main menu is shown as below. © Copyright OYN-X® All documentation rights reserved.
Page 12: Logout
Main Menu Window Logout You have two options: Logout, or Reboot. You can use the desktop shortcut menu or enter the [main menu] to access the Logout Menu. © Copyright OYN-X® All documentation rights reserved.
Page 13: Main Menu
FTP upload. Alarm camera mask alarm channel, sensitivity, linkage parameters: defending Video time section, alarm output, screen hint, blind recording, screen shot , PTZ, patrol, buzz, email and FTP upload. © Copyright OYN-X® All documentation rights reserved.
Page 14 System Set main (extra) coding parameter: code configuration mode, resolving ability, frame rate, code Encode stream control, image quality type, code configuration stream value, frame between value, video/audio enable. © Copyright OYN-X® All documentation rights reserved.
Page 15 Break the connection with the already tools logged in user. Lock the account after an Online user attempted unauthorised access until next DVR reboot. Adjust upside, downside, nearside, Output adjust starboard distance, black margin vertical & horizontal. © Copyright OYN-X® All documentation rights reserved.
Page 16 Display hard disk capability and recording information time Display code stream information System Clear all log information according to the information information log video and time Edition Display edition information information Shut down Logout or reboot. © Copyright OYN-X® All documentation rights reserved.
Page 17: Preview
(shown below). The menu includes: main menu, record mode, playback, PTZ control, High Speed PTZ, Alarm Output, color Setting, Output adjust, Logout, view mode shift, spot. Shortcut menu in full analog (DVR) © Copyright OYN-X® All documentation rights reserved.
Page 18: Recording Config
First HDD is a read-write disk; the second is a redundant disc ready as a spare. Length: Set the time length of each video file. 60 minutes is default length. Prerecord: Record 1-30 seconds before the action (file length is decided by the stream). © Copyright OYN-X® All documentation rights reserved.
Page 19 - Alarm：Selecting this option will set the external alarm trigger signal in the set time section. When the alarm is set as ‘Open recording’, the ‘Detection recording’ state is on. The video file type is ‘A’. © Copyright OYN-X® All documentation rights reserved.
Page 20: Backup
【Detect】Detect the storage connected with the DVR such as hard disk or universal disk. 【Backup】Click backup button and the dialog box is popped up. You can choose the backup file according to the type, channel and time. © Copyright OYN-X® All documentation rights reserved.
Page 21 Note：During backup you can exit the page layout to carry out other functions.  【Burning】the file will be burned synchronously after you have clicked this.  【Erase】Choose the file you wish to delete and click this button to delete the file.  【Stop】Stop the backup. © Copyright OYN-X® All documentation rights reserved.
Page 22: Snapshot Storage
PreSnap: Set how many seconds of pre-recorded footage (stored in the memory) is added on to the beginning of the snapshot. You can refer to ‘6. Record Config’ section for a very similar description on how to setup the ‘Snapshot’ options. © Copyright OYN-X® All documentation rights reserved.
Page 23: Playback
Note: The hard disk that saves the video files must be set as read-write. Pic 4: Playback Key:  Back up options  File information  File searching  File backup  Operation playback time code  Playback control panel © Copyright OYN-X® All documentation rights reserved.
Page 24 Local zoom: When the system is in single-window full-screen playback mode, you can drag your curser on the screen to select a section and then left click mouse to local zoom in or out. You can right click mouse to exit. © Copyright OYN-X® All documentation rights reserved.
Page 25: Network Setup
According to the default setup, the default gateway is generally the router IP address, so enter IP address (e.g.192.168.1.10) in the web browser to be able to operate the security surveillance system from different PC terminals within the local network. © Copyright OYN-X® All documentation rights reserved.
Page 26: Alarm
【Manual】: Click the all button and the according channel is alarming no matter the channel in any state. 【Stop】: Click the stop button and the according channel stops alarming no matter the channel in any state. © Copyright OYN-X® All documentation rights reserved.
Page 27 (click the ‘Set’ button next to ‘Region’), select the areas you want, the ‘Default’ setting will make all areas motion sensitive, then right click to choose ‘Up window’. In the second section of the motion detect options, you can customise: © Copyright OYN-X® All documentation rights reserved.
Page 28 PAL22X18. Red blocks represent the motion detect defensive area. White block means the unfenced area. You can set the area as followed, Drag the mouse and draw the area. Default: all selected blocks are the detection area. Select Region © Copyright OYN-X® All documentation rights reserved.
Page 29  【PTZ Activation】Set the PTZ activation when the alarm is turned on. Note：to link PTZ, you need to go [Shortcut menu]->[PTZ control] to set preset point, cruise between points & interval time, etc. © Copyright OYN-X® All documentation rights reserved.
Page 30 No Disk Space  Network Disconnection  IP Conflict (IP address is incorrect for remote connection) If one of these system errors occurs the device will alert you with such as show message and buzzer. © Copyright OYN-X® All documentation rights reserved.
Page 31 【Enable】 Select it to make sure abnormal function workable  【Show message】 Automatically alarm cue dialog box come out of the main screen  【Buzzer】 Device will have one long nosie “di” while alarm is happening © Copyright OYN-X® All documentation rights reserved.
Page 32 Intelligent Video Analysis Intelligent analysis function: you can set in two rules: picket line and picket area. You can only use the Video Analysis function on Record Channel 1; no other channels can be used. © Copyright OYN-X® All documentation rights reserved.
Page 33 Rules: you can choose to forbid bidirectional movement, entering or leaving footage frame, or movement in 3 different directions, so that when the moving objects meet these picket area rules the alarm will be activated. © Copyright OYN-X® All documentation rights reserved.
Page 35 When video analysis alarm is triggered, there will be red box line in the preview image. The intelligent analysis function mainly includes the 2 facets detailed below Touch line detection: bidirectional touch line, single-direction touch line. Area detection: enter alarm, leave alarm. © Copyright OYN-X® All documentation rights reserved.
Page 36 (see image below).  Items stolen: object disappears within warning area, and the size of object meet the rules of minimum image distance, alarm will be triggered © Copyright OYN-X® All documentation rights reserved.
Page 38: Ptz Control
Click [main menu] > [system configuration] > [PTZ setup] to set the PTZ parameters. The PTZ functions are decided by the PTZ protocols. PTZ setup  【Speed】: Set the PTZ rotation range. Default range: 1 ~ 8. © Copyright OYN-X® All documentation rights reserved.
Page 39 PTZ to rotate orientation. Left press mouse and then rotate the mouse to adjust the zoom multiple of the camera.  【Set】: Enter the function operation menu.  【Page switch】: Switch between different pages. © Copyright OYN-X® All documentation rights reserved.
Page 40: System Setup
PTZ configure/RS485 device  RS232  Tour setup  Spot and digital 19.1 General General setup  【System time】Set the system data and time.  【Date format】Choose the data format: YMD, MDY, DMY. © Copyright OYN-X® All documentation rights reserved.
Page 41  【Auto Logout】Set the latency time in the range of 0-60. 0 means no latency time.  【Machine Name】Set the device's name.  【DST】Choose the summer time option and the pop up dialog box appears: DST (week) © Copyright OYN-X® All documentation rights reserved.
Page 42 Note: extra stream introduces a video compression technique that was applies to multi-channel simultaneous playback , Dial-up multi-channel real-time monitor working under poor bandwidth strength, or for mobile monitor, etc. Picture 4.20 Encode setup © Copyright OYN-X® All documentation rights reserved.
Page 43 【Extra stream】is used for client side monitoring & mobile monitoring.  【Channel title】select channel title and then to choose whether need enable video & audio. The resolution, frame rate, bit rate type settings is the same as main stream. © Copyright OYN-X® All documentation rights reserved.
Page 44 【DNS setup】Domain Name Server. This translates the domain name into an IP address. The IP address is offered by network provider. The address must be set and reboot then it works.  【Media port】Default: 34567.  【HTTP port】Default: 80. © Copyright OYN-X® All documentation rights reserved.
Page 45: Net Service
Otherwise image quality precedence is valid. 19.4 Net Service Choose the network service option and click the set button to configure the advanced network functions or double click the service button to configure the parameters. NetService Menu © Copyright OYN-X® All documentation rights reserved.
Page 46: Ntp Setup
Operation：After PPPoE dialing has successfully looked up the IP address in the [IP address] and obtain the current IP address. Then use this IP address to visit the DVR through user port. 【NTP setup】 © Copyright OYN-X® All documentation rights reserved.
Page 47 SSL: Decide whether using Secure Socket Layer protocol to login.  User Name: Apply the email server user name.  Password: Input the password corresponding to the user.  Sender: Set the email sender address. © Copyright OYN-X® All documentation rights reserved.
Page 48 You can delete the set IP address by √ in the options. Note：When the same IP address is in the white and black list at the same time, the black list precedence is higher. IP Filter © Copyright OYN-X® All documentation rights reserved.
Page 49: Ftp Setup
Note：The DNS setup must be configured correctly in the network setup. 【FTP setup】 FTP is available only when alarm is triggered, or alarm activates record and snapshot functions, it will upload the related record and snapshot pictures to FTP server. © Copyright OYN-X® All documentation rights reserved.
Page 50 【Dir Name】：The directory of the upload file. Note: Only Users are to upload files only have permission/clearance to do  【ARSP】 Startup DDNS server to add devices and manage it in the DDNS server © Copyright OYN-X® All documentation rights reserved.
Page 51 [User name] the user name that device can log in DDNS server  [Password] the password related to the user name.  [Refresh cycle]：Time interval between device and DDNS when synchronised. Note: Please set up server before using DDNS. © Copyright OYN-X® All documentation rights reserved.
Page 52 【Alarm Report】Tick it means to report alarm information to server.  【Log Report】Tick it, means to report log to server.  【Wireless Config】 ADSL through 3G net card, use CMS to visit and config the device © Copyright OYN-X® All documentation rights reserved.
Page 53  【Type】Dial type, default AUTO  【Wireless AP】3G access point  【Dial Number】3G Dial Number  【User Name】User name of 3G  【Password】Password of dial user  【IP Address】IP address, obtained from dial. © Copyright OYN-X® All documentation rights reserved.
Page 54 CMS to monitor and operate it using protocols. Mobile Monitor Setup  【Enable】: Select it to make sure abnormal function workable  【Port】: The mobile monitoring port, this is the port number you need to use when mapping your router. © Copyright OYN-X® All documentation rights reserved.
Page 55 【TCP】: Router will automatically distribute TCP port for the device, when monitoring via CMS.  【Mobile Port】: Router will automatically distribute Mobile Port for the device when using your smart phone to monitor the DVR. © Copyright OYN-X® All documentation rights reserved.
Page 56 【Password】：wireless network password of router；【IP address】: to set the IP address of device, default is 192.168.1.12 【subnet mask】:set subnet mask of device, default is 255.255.255.0 【gateway】：set gateway of device, default is 192.168.1.1 © Copyright OYN-X® All documentation rights reserved.
Page 57: Gui Display
Encode output：In the network surveillance and video file mode include: channel title, time display, channel display, record status, alarm status, transparency and region cover. © Copyright OYN-X® All documentation rights reserved.
Page 58 You can cover the arbitrary using mouse. (Black region is for output)  【Time display】and 【Channel display】 set the display position of channel title and time title. © Copyright OYN-X® All documentation rights reserved.
Page 59 【Protocol】choose related protocol of brand model  【Address】set with corresponding address, default is 1  【Baud rate】choose the baud rate that the related device uses, default is 115200  【Data bits】including 5-8 options，default is 8； © Copyright OYN-X® All documentation rights reserved.
Page 60 【interval】Set the patrol switch interval. The set range is 5-120 seconds.  【alarm tour】set the interval to shift alarm tour, range is 5-120 seconds, choose return when alarm ends, when alarm link to tour, system will auto shift to six-view after alarm finished. © Copyright OYN-X® All documentation rights reserved.
Page 61: Channel Management
Manage each camera’s channel status and mode. Initial channel manage screen Channel Status: This menu screen shows the status of the entire range of available channels (the information includes: Max Resolution, This Resolution, Connection Status). © Copyright OYN-X® All documentation rights reserved.
Page 63 Note：Read/Write Disk: The equipment can write or read data. Read-only Disk: The equipment can read data but can not write data. Redundant Disk: Double backup the video files in the write-read disk. © Copyright OYN-X® All documentation rights reserved.
Page 64 You can set the team as you wish. The user can appoint the purview in the group. The user management includes: group/ user. The group and user name cannot be the same. Each user only belongs to one group. © Copyright OYN-X® All documentation rights reserved.
Page 65 The blank ahead or behind the character string is invalid. The middle blank in the character string is valid. Note：The user who possesses the user control purview can modify his/her own or other users password. © Copyright OYN-X® All documentation rights reserved.
Page 66 Once you have chosen the team, the user purview is the subclass of the team. We recommend that the common user’s purview is lower than the advanced user. © Copyright OYN-X® All documentation rights reserved.
Page 67 【Add Group】Add a user group and set the purview. There are 33 different purviews: Which allows you to either shut down the equipment, real time surveillance, playback, record setting, video backup and more. © Copyright OYN-X® All documentation rights reserved.
Page 68 Add group  【Delete User】Delete the current user. Choose the user and click the delete user button.  【Delete Group】Delete the current group. Choose the group and click the delete group button. © Copyright OYN-X® All documentation rights reserved.
Page 69 To check the information of network user that connected with local device, also can tick the selected user to break up connection,（make √ at the box），then the user will be frozen after connection stopped, and will not log in until device reboot. Online user © Copyright OYN-X® All documentation rights reserved.
Page 70 The user can set the time to auto reboot and auto delete file. Auto maintain 19.9.5 Restore The system can be restored to its default settings . You can choose the items according to the menu. Restore to default © Copyright OYN-X® All documentation rights reserved.
Page 71 【Upgrade】choose USB interface.  【Upgrade file】choose the upgrade file. 19.9.7 Device Info This provides the device interface info like audio in, alarm in/out so that it can be conveniently used by the user. Device info © Copyright OYN-X® All documentation rights reserved.
Page 72 Users can export the log info and the configure file from device to connected flash stick, and also they can import related configure file from flash stick to settings, which greatly bring convenience to the customers. Import / Export interface © Copyright OYN-X® All documentation rights reserved.
Page 76 19.10.4 Version This screen displays the basic information such as hardware information, software version, issue date, serial number , NAT status and so on. Version information © Copyright OYN-X® All documentation rights reserved.
Page 77: Web Monitoring
‘admin’, there is no password to enter (leave blank). User should create a password for the admin user profile after login. ‘Pic 9’ is the interface view you will encounter after successfully logging in. © Copyright OYN-X® All documentation rights reserved.
Page 78 If the channel did not change, system will closed previous video and open the new one you choose. Note: User can choose the most appropriate image mode, when opening remote video control. © Copyright OYN-X® All documentation rights reserved.
Page 79: Special Function
In order to achieve the best quality video playback on the network that you are connected to, adjust the settings accordingly until the desired quality level of video monitoring has been achieved. Encode © Copyright OYN-X® All documentation rights reserved.
Page 81: Multi-Channel Playback
On the search condition interface, choose file type, choose channel (channels can be combined freely), choose time period, click yes; On the playback page, choose the video file, press play or double click the file to play back. © Copyright OYN-X® All documentation rights reserved.
Page 82: File Storage
DVD-RW: selected video files are burnt and stored on to CD. Network high-speed download: you can quickly download the selected files via the remote client. © Copyright OYN-X® All documentation rights reserved.
Page 83: Faq: Troubleshooting
The hardware of the DVR is damaged. System cannot detect hard disk. Possible reasons: A. The hard disk power supply line is not connected. B. The cables of the hard disk are damaged. C. The hard disk is damaged. © Copyright OYN-X® All documentation rights reserved.
Page 84 B. The hard disk is damaged. C. Update the different program with the origin program files. D. The video files to look up are covered. The recording is not on. The local video is not clear. Possible reasons: © Copyright OYN-X® All documentation rights reserved.
Page 85 11. The DVR cannot control the PTZ. Possible reasons: A. There is something wrong with the frontal PTZ. B. The setting, connection or the installation of the PTZ decoder is not correct. C. The connections are not correct. © Copyright OYN-X® All documentation rights reserved.
Page 86 Invalid password or user name. G. The CMS is not matched the DVR program version. 14. The image is not clear or there is no image in network preview state or video file playback state. Possible reasons: © Copyright OYN-X® All documentation rights reserved.
Page 87 A. The serial port of the DVR is not set correctly. B. The address is not correct. C. When multiple transformers are connected, the power supply is not large enough. Please give each transformer individual power supply. D. The distance is too far. © Copyright OYN-X® All documentation rights reserved.
Page 88 A. Front Vidicon quality is bad. The lens is too dirty. The Vidicon is in a poor backlighting installation location. B. The hard disk capability is not enough. C. The hard disk is damaged. © Copyright OYN-X® All documentation rights reserved.
Page 89 25. The snapshot at alarm function was enable, why not catch picture Possible reasons: A. HDD manage without partition for snapshot. B. Partition for snapshot is 0 C. The snapshot function is not enabled on record-> storage of related © Copyright OYN-X® All documentation rights reserved.
Page 90 28. Picture will be frozen when multi-connection and shift devices. A. Picture come out from digital channel need few seconds, shift device means to show new picture, so it needs several seconds to buffer. © Copyright OYN-X® All documentation rights reserved.
Page 91: Appendix 1: Remote Controller Operation
Back to up window Direction button Direction and OK button Playback operate Playback Basic operation Record control Enter into record menu Remote controller Input the number of DVR to control it Assistant function © Copyright OYN-X® All documentation rights reserved.
Page 92: Appendix 2: Mouse Operation
Switch the items in the combo box Page up or down in the list Move mouse Choose the widget or move the item in the widget Drag mouse Set the motion detect area Set the cover area © Copyright OYN-X® All documentation rights reserved.
Page 93 ENHANCE YOUR DVR WITH OUR WIDE RANGE OF OYN-X CAMERAS OUR PRODUCTS ARE FULLY TESTED TO WORK TOGETHER FOR COMPATABLE CAMERAS; LOOK FOR THESE COLOUR ICONS ON THE SIDE OF THE BOX: DON’T SETTLE FOR LESS ALL OUR PRODUCTS CARRY OYN-X LOGOS...
Page 94 For further information and help on any products from the OYN-X brand, please scan the QR code below to be directed to our website: WWW.OYN-X.COM © Copyright OYN-X® All documentation rights reserved.
