- Page 1 FabiaTech Corporation IPC Solution Website: http://www.fabiatech.com Email: support@fabiatech.com Flat Panel Display FD7851 Series User’s Manual JAN 2008 Version: 1.0 Part Number: FD7851...
- Page 2 FabiaTech shall not be reliable for technical or editorial errors or omissions, which may occur in this document. FabiaTech shall not be reliable for any indirect, special, incidental or consequential damages resulting from the furnishing, performance, or use of this document.
-
Page 3: Table Of Contents
Table of Contents User’s Manual..........................i Chapter 1 Introducing the FD7851 Panel Display ..............1 Overview..........................1 Series Comparison Table .......................1 Layout............................2 Specifications..........................3 Packing List ..........................4 Chapter 2 Hardware Installation ....................5 Before Installation ........................5 Keypad (Real View) ...................6 Connecting the LCD Monitor to the PC............9 ... -
Page 5: Chapter 1 Introducing The Fd7851 Panel Display
FabiaTech Corporation Chapter 1 Introducing the FD7851 Panel Display Overview The FD7851x is a 15.0-inch TFT LCD monitor, this panel display with OSD and touch screen device (FD7851T). This user’s manual provides its outlook information and I/O outlets description. Series Comparison Table... -
Page 6: Layout
FabiaTech Corporation Layout FD7851(T) On/Off Menu DC12V Touch Panel Auto... -
Page 7: Specifications
FabiaTech Corporation Specifications FD7851 Front panel with 15.0-inch color TFT LCD panel. Supports up to XGA 1024X768 16.2M colors Build-in OSD functions with LED indicator and 5 operation keys. Touch screen –Only for FD7851T 5-wire analog resistive touch screen device with USB interface. -
Page 8: Packing List
FabiaTech Corporation Packing List Upon receiving the package, verify the following things. Should any of the mentioned happens, contact us for immediate service. • Unpack and inspect the FD7851 package for possible damage that may occur during the delivery process. -
Page 9: Chapter 2 Hardware Installation
FabiaTech Corporation Chapter 2 Hardware Installation This chapter introduces the system connectors and guides you to apply them for field application. Before Installation Before you install the system, make sure you follow the following descriptions. 1. Plug the power cable into the AC-DC Power adapter you PC/IPC and LCD monitor before connecting your LCD monitor to the computer. -
Page 10: Keypad (Real View)
FabiaTech Corporation Keypad (Real View) Your LCD monitor allows you to easily adjust the characteristics of the image being displayed. All of these adjustments are made using the control buttons on the front of the monitor. While you use these buttons to adjust the controls, an OSD shows you their numeric values as they change. - Page 11 FabiaTech Corporation No Input Signal: If horizontal and vertical input signals are not exist, the monitor displays OSD information “NO INPUT SIGNAL” 3 seconds, and then goes to power save. Accessing the menu system With the OSD off, push the Menu button to display the main OSD menu.
- Page 12 FabiaTech Corporation The clock adjustments allow you to coarse tune the image Clock quality of your monitor to your preference. The Phase adjustments allow you to fine tune the image Phase quality of your monitor to your preference. H-Position Move the image horizontally.
-
Page 13: Connecting The Lcd Monitor To The Pc
FabiaTech Corporation Connecting the LCD Monitor to the PC Connect on end of the VGA signal adaptor cable to the PC’s D-sub 15 VGA port and other end to the LCD monitor, See following figure and a side pictures. DB15... - Page 14 FabiaTech Corporation...
-
Page 15: Chapter 3 Software Installation
FabiaTech Corporation Chapter 3 Software Installation The enclosed diskette includes FD7851T touch screen driver. To install and configure you FD7851(T) system, you need to perform the following steps. USB Interface Driver Driver for WIN2000/XP Step 1: To install the Touch Screen driver, insert the CD ROM into the CD ROM device, and enter DRIVER>TouchScreen>USB>PM6500. - Page 16 FabiaTech Corporation Step 3: Then A License Agreement appears. Click “I Agree…” and “Next” Step 4: Windows XP will prompt a warning message before driver certificated. Now, Press [Continue Anyway] to continue installation.
- Page 17 FabiaTech Corporation Step 5: As the setup is completed, the system will generate the message as follows. The “InstallShield Wizard Completed” appears. Click “Finish”...
- Page 18 FabiaTech Corporation PenMount Control Panel The functions of the PenMount Control Panel are Device, Calibrate, Setting, Multiple Monitors ,Tools and About, which are explained in the following sections. Device In this window, you can find out that how many devices be detected on your system.
- Page 19 FabiaTech Corporation Advanced Calibration Advanced Calibration uses 4, 9, 16 or 25 points to effectively calibrate touch panel linearity of aged touch screens. Click this button and touch the red squares in sequence with a stylus. To skip, press ESC’.
- Page 20 FabiaTech Corporation NOTE: The older the touch screen, the more Advanced Mode calibration points you need for an accurate calibration. Use a stylus during Advanced Calibration for greater accuracy. Please follow the step as below: 3. Come back to “PenMount Control Panel” and select “Tools” then Click...
- Page 21 FabiaTech Corporation Select “Device” to calibrate, then you can start to do “Advanced Calibration”. NOTE: Recommend to use a stylus during Advanced Calibration for greater accuracy. Plot Calibration Data Check this function and a touch panel linearity comparison graph appears when you have finished Advanced Calibration.
- Page 22 FabiaTech Corporation Turn off EEPROM storage The function disable for calibration data to write in Controller. The default setting is Enable Setting Touch Mode This mode enables and disables the mouse’s ability to drag on-screen icons—useful for configuring POS terminals.
- Page 23 FabiaTech Corporation Beep on both – beep occurs when comes down and lifted up Beep Frequency – modifies sound frequency Beep Duration – modifies sound duration Cursor Stabilizer Enable the function support to prevent cursor shake. Use press and hold as right click...
- Page 24 FabiaTech Corporation Multiple Monitors Multiple Monitors supports from two to six touch screen displays for one system. The PenMount drivers for Windows 2000/XP support Multiple Monitors. This function supports from two to six touch screen displays for one system. Each monitor requires its own PenMount touch screen control board, either installed inside the display or in a central unit.
- Page 25 FabiaTech Corporation 2. When the mapping screen message appears, click “OK” 3. Touch each screen as it displays “Please touch this monitor. Press ‘S’ to skip” Following this sequence and touching each screen is called mapping the touch screens. 4. After the setting procedure is finished, maybe you need to calibrate for each...
- Page 26 FabiaTech Corporation NOTES: 1. If you used a single VGA output for multiple monitors, please do not use the Multiple Monitors function. Just follow the regular procedure for calibration on each of your desktop monitors. 2. The Rotating function is disabled if you use the Multiple Monitors function.
- Page 27 FabiaTech Corporation Screen Rotation Monitor The function support nVidia, Intel, SMI or ATI and software such as Portrait Pivot Pro rotation automatic detection. PenMount Monitor Menu Icon The PenMount monitor icon (PM) appears in the menu bar of Windows 2000/XP system when you turn on PenMount Monitor in PenMount Utilities.
- Page 28 FabiaTech Corporation PenMount Rotating Functions The PenMount driver for Windows 2000/XP supports several display rotating software packages. Windows 2000/XP support display rotating software packages such as: • Portrait’s Pivot Screen Rotation Software • ATI Display Driver Rotate Function • nVidia Display Driver Rotate Function •...
-
Page 29: Uninstall Software
FabiaTech Corporation Uninstall Software 1. Exit the PenMount monitor (PM) in the menu bar in advance. 2. Go to Settings, then Control Panel, and then click “Add/Remove program” 3. Select ”PenMount Universal Driver 1.0”. Click the “Chang/Remove” button 4. Select ‘Yes’ to remove the PenMount driver. - Page 30 FabiaTech Corporation...
-
Page 31: Chapter 4 Technical Reference
FabiaTech Corporation Chapter 4 Technical Reference This section outlines the errors that may occur when you operate the system, and also gives you the suggestions on solving the problems. Topic include: Technical Reference Trouble Shooting for LCD Display and Touch Screen... -
Page 32: Compatible Vga Timing Chart
FabiaTech Corporation Compatible VGA Timing Chart TYPE RESOLUTION H-FREQUENCY(KHz) V-FREQUENCY (Hz) 31.5 60.0 37.9 72.0 37.5 75.0 640X480 FD7851(T) 35.1 56.4 800X600 VESA 37.9 60.0 48.1 72.0 46.9 75.0 IBM-AT 48.3 60.0 1024X768 56.5 70.1 60.0 75.0 Trouble Shooting The following information informs the LCD display and touch serene driver. Please adjust your systems according to the messages below. -
Page 33: Lcd Display Is Unstable
FabiaTech Corporation LCD Display is unstable There is no display on the LCD Monitor. Workaround: Make sure the AC-DC power supply indicator on the LCD and Power LED. Make system is running on the correct display (VGA or SVGA), Adjustment KEYPAD (OSD) press “Auto”... -
Page 34: Appendix
FabiaTech Corporation Appendix Dimension FD7851/T Cut out dimension 342 x 265 mm... - Page 35 FabiaTech Corporation On/Off Menu DC12V Touch Panel Auto...
-
Page 36: Mounting Dimension
FabiaTech Corporation Mounting Dimension WALL Cut Out Dimension = 342 * 265 mm...
