THE ORIGINAL 180° FULL FOLD, INSIDE FIT,
ZERO CLEARANCE FIREPLACE DOOR
OWNER'S MANUAL
IMPORTANT
these installation instructions as detailed may result in a possible fire hazard and will
void the warranty.
For proper use and care of your fireplace, please follow the guidelines below:
❑ Always use a grate for fires.
❑ Make sure the front of the grate is at least 6" back from the door.
❑ Keep combustibles away from front of the door.
❑ Do not clean glass doors while they are hot.
❑ When burning fire, the doors and the chimney damper must be fully open and the
mesh curtain fully closed.
❑ Install and use only after consulting with local building and fire regulations, and in
accordance with the installation and operating instructions provided.
❑ Inspect and clean chimney regularly.
R A I N B O W
:
Read all instructions before starting installation.
Proudly made in USA by
1410 Johnson Lane,
Failure to follow
Advertisement
Table of Contents
Related Manuals for Hearth Craft Rainbow
Summary of Contents for Hearth Craft Rainbow
- Page 1 R A I N B O W THE ORIGINAL 180° FULL FOLD, INSIDE FIT, ZERO CLEARANCE FIREPLACE DOOR OWNER’S MANUAL IMPORTANT Read all instructions before starting installation. Failure to follow these installation instructions as detailed may result in a possible fire hazard and will void the warranty.
- Page 2 Clarksville, IN 47129 www.hearthcraft.com Rev. KJJ 07/2015 CARE & MAINTENANCE IMPORTANT INFORMATION: Please read before installing your enclosure ACID HEARTH: Newly constructed fireplaces are cleaned with acid to remove extra mortar. Unless removed, the acid will crystallize in the brick pores and emit gas which may damage the finish on the fireplace fixtures or other nearby metal objects.
- Page 3 Replacement Parts: Use only specified replacement parts available from your dealer. Do not use • substitute parts. WHAT IS IN THE BOX! ❑ Your Fireplace Door (also referred to as a Fireplace Glass Enclosure) Figure A. This Door consists of a "Frame" (Fig A-1) and a "Door-Set" (Fig. A-2). ❑...
- Page 4 STANDARD MOUNTING 1. Please note the protective film on the door. This is to prevent scratching. Do not peel off at this time. 2. Some fireboxes have a screen rail, and/or screen retaining clips, and it may be necessary to remove them.
- Page 5 6. Remove the door from the opening, and using a 3/32" drill bit, drill the firebox where you had just marked for holes #1 through # 5. 7. Carefully remove the protective film from the door frame. 8. Place the door back into the firebox opening and align the holes on the door frame, with the ones you just drilled.
- Page 6 USEFUL INFORMATION Adjusting the Door-Set Sometimes due to vibrations during transportation, or as a result of handling, the door-set may get out of adjustment. To adjust the door-set, first make sure the frame is plum in the fireplace. Once you have established that, look at the trim around the glass. This is the most likely place where an adjustment may be needed.
- Page 7 It is installed on a prefabricated fireplace made by ……….………….., Model # ……….……… The Opening Dimensions of my prefabricated firebox is: Width ………… Height .……….. The Outside Finished Dimensions of my RAINBOW is: Width ………… Height .……….. Your Notes & Remarks: ______________________________________________________...
- Page 8 This product is warranted by the manufacturer to the original retail buyer for one (1) year from date of purchase against defects in materials and workmanship. This includes any implied warranties of merchantability and fitness for a particular purpose which are also limited in duration to one (1) year from the original purchase of this product.
