- Page 1 ORATOR AUDIO D860TD WIRELESS MICROPHONE SYSTEM INSTRUCTION MANUAL...
- Page 2 Control Panels System Set Up Frequency Setting Trouble Shooting Technical Data For technical assistance or service enquiries, please contact ORATOR AUDIO on: 02.9938 6866 enquiries@orator-audio.com ORATOR AUDIO PO Box 7289, Warringah Mall NSW 2100 T: 02.9938 6866 F: 02. 9938 6899 E: enquiries@orator-audio.com...
- Page 3 Australia. Power Life 8 - 10 hours The D860TD is a dual channel (2 microphones) True Diversity system for professional use, with an operating distance of up to 300m (depending on Receiver : local conditions). Wikipedia describes True Diversity as: “The professional models transmit in VHF or UHF radio frequency and have ‘true’...
- Page 4 System Components: Troubleshooting: 1. Receiver 1 .The Receiver is turned on but the indicator light is not lit? Make sure if the DC power cable is properly fiitted into the power socket & the DC cable is firmly fitted into the Receiver. 2.
- Page 5 System Controls: System Set Up: 1. Receiver: 2. Frequency Setting: Your system comes with the hand held microphone already set to match the existing frequency of the Receiver. To get a suitable frequency for your FRONT PANEL: area, a simple “trial and error” approach is usually the fastest solution. Simply follow the operating instructions to test the signal quality of the existing frequency set in the system.
- Page 6 System Controls: System Set Up: 2. Hand Held Microphone: 1. Receiver Cable Connections: The Receiver can be connected to an amplifier or mixer to process the microphone signal. 2 outputs are provided: 1 balanced (XLR) socket and 2. an unbalanced (6.3mm ~ 1/4”) socket. A 6.3mm cable is included so you can use this socket to connect your Receiver.
