Thermo Top Heater Series Smart Controller
Quick Set-Up Guide
Timer
Initial Start-Up
When the Control unit is connected for the first time, a message about the Setting/Configuration of
the heater is displayed.
Press the control knob and the On/Off Button simultaneously for 3 seconds
TT ‐ Z/C/E
Select your Heater
HS
Press the Control Knob
Heater
Select the current Day
Press the Control Knob
Select the current Time - turn the Control Knob clockwise to select Hour, press the Control Knob
to confirm, then turn the Control Knob clockwise again to select the Minutes, press the Control
Knob to set.
Heating
Settings
1
Menu Name
2
Menu Symbols
3
Time Setting Activated
4
Time
5
On / Off Button
6
Control Knob
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Webasto Thermo Top Heater Series
Summary of Contents for Webasto Thermo Top Heater Series
- Page 1 Thermo Top Heater Series Smart Controller Quick Set-Up Guide Menu Name Menu Symbols Time Setting Activated Time On / Off Button Control Knob Heating Settings Timer Initial Start-Up When the Control unit is connected for the first time, a message about the Setting/Configuration of the heater is displayed.
- Page 2 If your heater was not selected correctly at Initial Start-Up a Manual Reset is required. Press the On/Off Button to go to the Main Menu Screen and follow the following steps. Select the symbol “Settings” Press the Control Knob The “Quick Start” menu is displayed Turn the Control Knob clockwise 10 times until “Reset”...
- Page 3 PHEC System Heater Smart Controller Timer Programming It is possible to program the Timer Setting 7 days in advance. The heater switches on automatically at the programmed time. Up to 3 time settings per day can be set, with a total of 21 time settings for the week.
- Page 4 Press the Control Knob to activate the programmed time “Activate” message will appear on the display Repeat the process to add timers (3 timer settings per day, 21 per week) Webasto Thermo & Comfort Australia Pty Ltd 423-427 The Boulevarde Kirrawee NSW 2232...
