Ergo Systems 2000U8 Owner's Manual

U8 timer
Hide thumbs

Advertisement

Quick Links

Download this manual
U8 Timer
MODEL NO.
2000U8
Model and serial number may be
found at the rear of the feeder base.
Please record both model and serial
number in a safe place for future use.
Where Purchased
:
Date purchased
: Month
: Day
: Year
Model No.
:
Serial #
:
Owner's Manual
This Owner's Manual contains
information for all models.
Read and keep this manual for future
reference.
This manual contains important
information on Safety, Assembly,
Operation and Maintenance.
Ergo Systems Inc. Rev # : 1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2000U8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ergo Systems 2000U8

  • Page 1 Date purchased : Month Read and keep this manual for future : Day reference. : Year This manual contains important Model No. information on Safety, Assembly, Serial # Operation and Maintenance. Ergo Systems Inc. Rev # : 1.1...

  • Page 2: Timer Programming

    TIMER PROGRAMMING This is the digital timer unit for the Autopetfeeder. The timer plugs in to the wall socket and has two outlets, one outlet is labeled as “Power” which is on the left hand side of the timer, directly connects to the power supply, and the second outlet is labeled as “Timer”...

  • Page 3: Setting The Current Time

    2.1 Setting the Current Time Press and hold the CLOCK button. While holding the CLOCK button press the WEEK button to set the day of the week. Fig 1 Press and hold the CLOCK button. Now press the HOUR button to set the hour. Fig 2 Press and hold the CLOCK button.

  • Page 4: Daylight Saving Time

    2.2 Day Light Saving Time To set day light saving time, press the HOUR and the MINUTE button simultaneously. This will make the clock to run an hour ahead. Fig 4 This introduces a circle indicating a small clock above the black dot on the display.
  • Page 5 2.3.2 Setting ON and OFF Time The pet feeder is capable of feeding different sizes and shapes of pet food. Hence, the quantity of food dispensed per minute changes. It is advised that you measure the quantity of food that your pets consume for every schedule by testing the feeder on the ON mode and pre-determining the amount of time required to feed your pet.
  • Page 6 In OFF mode, the feeder does not work. So if you choose to feed your pet manually use this function to turn off the feeder. Fig 9 N O T E To put the timer in AUTO mode always cycle from OFF mode to AUTO mode. Do not cycle from ON mode to AUTO mode as the feeder will feed continuously.
  • Page 7 2.3.4 Setting the days of Week Press PROG button to enter in to the prog mode. The display will show 1 which means that we are setting the 1 schedule ON time. Fig 10 Press the WEEK button once and the display will show all days option.
  • Page 8 Pressing WEEK button again will give you the week days option. This display will show Mon-Fri Fig 13 A scheduled program in this option will work on week days. Pressing WEEK button once again will lead to the weekend option. This display will show sat & sun. The schedule programmed in this option will work on weekends.
  • Page 9 Press WEEK button again for the alternate day option mon, wed & fri. Fig 16 Press WEEK button once more for the other alternate option day tue, thu & sat. Fig 17 Press WEEK button again to go to the three days option which is to schedule for the first three days of the week such as mon, tue &...
  • Page 10 Press WEEK button again to go to three days option which is to schedule for next three days of the week such as thu, fri & sat. Fig 19 2.4 Erasing all Schedules Press R button to erase all schedules. Fig 20 NOTE: If you don’t press a button while in program mode you will be taken back to CLOCK mode.
  • Page 11 2.5.2 Press WEEK button once and the display will show Mon-Sun. This is the recommended program for all days of week Fig 22 2.5.3 Press the HOUR button till the display shows 8. Fig 23 2.5.4 Press the minute button till the display shows 00. Fig 24...
  • Page 12 2.5.5 Press the ON/AUTO/OFF button till the display shows 00 seconds. The ON time is now set to 8 a.m. Fig 25 2.5.6 Press the PROG button again and the display will show which means that we are setting the first schedule for the OFF time.
  • Page 13 2.5.8 Press the HOUR button till the display shows 8. Fig 28 2.5.9 Press the MINUTE button until display in the MINUTE shows 8.01. Fig 29 2.5.10 Press the ON/AUTO/OFF button till the display shows 30 seconds. The OFF time is now set to 8hrs 1 min & 30 sec. The feeder time will be for 1 min and 30 sec.
  • Page 14 Press the CLOCK button to exit from the PROG mode. Fig 32 U8 TIMER Now the is ready to use. Corporate Office E-Mail Toll-Free Phone. US only contact@autopetfeeder.com 1-888-ERGOSYS Ergo Systems Inc., (1-888-374-6797) 1105 S. WestWood Ave, Addison, IL 60101. Website International Phone http://www.autopetfeeder.com 1-630-543-7686 Warranty Registration http://www.autopetfeeder.com/warranty.asp...
