Summary of Contents for Thermo-Dynamics Boiler THERMOTRON OTF
-
Page 1: Installation Instructions
THERMOTRON Thermo-Dynami c s R O U T E 6 1 • P . O . B O X 3 2 5 • S C H U Y L K I L L H A V E N , P A 1 7 9 7 2 • ( 5 7 0 ) 3 8 5 - 0 7 3 1 • F A X ( 5 7 0 ) 3 8 5 - 5 3 0 4 www.thermodynamicsboiler.com Operation Maintenance... -
Page 2: Table Of Contents
Contents General Information ......................1 Service Policy ........................1 Installation Instructions ....................2 Filling Instructions ......................2 Winterizing ........................3 Start-Up and Operation ....................3 Piping/Connection Diagrams ..................4 Assembly Diagrams ......................5 Trouble Shooting ......................6 Care and Maintenance ....................6 Pool Coil Diagram ......................7 Wiring Diagrams ......................8 Parts List ........................9 Specifications ......................10 Home Owner Information ..................11 Set-Up and Service Records ..................12... -
Page 3: General Information
Thank you for purchasing the Thermo-Dynamics pool heater. Again, it is our intent to provide you with a high quality trouble free product that will be part of your family for many years to come. Please consider Thermo-Dynamics Boiler Company in the future for all of your home heating needs. -
Page 4: Installation Instructions
Section I. Installation Instructions Control of combustion draft. component to obtaining optimum (B) ITF Series (Indoor Units) (1) Locating The Heater: Before uncrating the unit prepare performance (see piping diagram on (a) General: the location. It should be placed upon page 4). -
Page 5: Winterizing
(1) Do not turn on electrical S e c t i o n I I I B Equipment Adjustments: power to heater until boiler is properly Equipment Required: filled with water. S t a r t U p a n d (1) CO Analyzer (absorption (2) * Connect the male end of a... -
Page 8: Trouble Shooting
burner should shut down. Turn con- (b) Dirty fan/air handling parts. to the prescribed conditions trol to highest setting; burner should (c) Improper burner adjustment u n d e r “ b u r n e r a d j u s t m e n t s , ” operate. -
Page 11: Parts List
P arts L ist OTF/ITF 510/1600 Beckett AF Burner Parts List - #540500 (Designate heater and burner model numbers on all orders.) Description Item No. Part Number Motor 1/7 HP 3450 RPM - PSC 675141 Fan 4-1/2 Dia. x 3-7/16 675130 Flexible Coupling 675160... -
Page 12: Specifications
Specifications Model - OTF - ITF 1010 1600 Gross Input 140,000 210,000 280,000 350,000 Gross Output - BTU/Hr. 109,200 163,800 218,400 273,000 Flue Pipe Dia. 6" 6" 8" 8 ” Firing Rate - GPH 1.00 1.50 2.00 2.50 Width OTF-ITF 22"... -
Page 13: Home Owner Information
H o m e Ow n e r I n f o r m a t i o n : The Service Company: Name Address Phone No. SERVICE INFORMATION: To avoid unnecessary expense and inconvenience your pool heater should be cleaned and serviced at least annu- ally by a qualified service man. -
Page 14: Set-Up And Service Records
OTF/ITF Pool Heater Beckett AF Burner Service Set Up Records nitial Set Up 1. Date 2. Model Number 3. Firing Rate 4. Pump Pressure 5. CO 6 . “ 0 ” S m o k e 7. Gross Stack 8. Draft Over Fire 9. - Page 15 Part Number 595821 250 - 6/03 MIP-6426...
