- Page 1 AC POWER SOURCE 110-17 Fawcett Road, Coquitlam B.C., Canada V3K 6V2 e-mail: samlex@samlexamerica.com website: www.samlexamerica.com D C - A C I N V E R T E R S MODEL: P S E - 1 2 6 0 A OWNER'S MANUAL Version#011701 Please read this manual before operating your inverter.
- Page 2 Never parallel the 115V AC output of the inverter with the output from a generator or the electric mains. Although this inverter has a high input OVER VOLTAGE SHUT DOWN at 15V, input voltages higher than 15V will cause . Ensure the following when the battery is being charged simultaneously (the output voltage of the charging device will be fed to the inverter): Ensure that the charging voltage of the alternator has not been set about 15V.
- Page 3 This model is used in a wide range of applications including, remote homes, RV’s, power boats, sail boats, and campers. It will operate most televisions and VCR’s, personal computers, small appliances and tools such as drills, sanders, grinders, mixers and blenders. To get the most out of your power inverter, it must be installed and used properly.
- Page 4 Leave the switch in the Off position during installation. Lights when the inverter shuts down due to overloading. Turn Very little maintenance is required to keep your inverter operating properly. You should clean the inverter “Off”, remove the cause of overload and turn the inverter “On” to restart. exterior of the unit periodically with a damp cloth to prevent accumulation of dust and dirt.
- Page 5 PSE 1260A Input Voltage Range 10 - 15 VDC 1. Unpack and inspect the inverter, check to see that the power switch is in the OFF position. Output Power 2. Connect the cables to the power input terminals on the rear panel of the inverter. The red 600 Watts Continuous terminal is...
- Page 6 The power inverter should be installed in a location that meets the following requirements: -Do not allow water to drip or splash in the inverter. Poor DC wiring, poor Use proper wire battery condition. and make solid - Ambient air temperature should be between 0 C and 40 C, the cooler the better.
- Page 7 The power inverter has a lug on the rear panel “chassis ground”. This is to connect the chassis of the power inverter to the ground. The ground terminals in the AC outlets on the front panel of the inverter are also connected to the ground lug. The chassis ground lug must be connected to a grounding point, which will vary depending on where the power inverter is installed.
- Page 8 The power inverter will shut down and also produce an audible alarm if the input voltage exceeds 15V (12V version) or 30V (24V version). This protects the inverter from excessive input voltage. To operate the power inverter, turn it on using the ON/OFF switch on the front panel. The power Although the power inverter incorporates protection against over-voltage, it may still be damaged inverter is now ready to deliver AC power to your loads.
