Inctel IN-X300 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IN-X300
I
N
-
X
3
0
0
U
s
e
r
G
u
i
d
e
I
N
-
X
3
0
0
U
s
e
r
G
u
i
d
e
Inctel co,.ltd would like to thank you for purchasing this product.
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IN-X300 and is the answer not in the manual?

Questions and answers

Summary of Contents for Inctel IN-X300

  • Page 1 IN-X300 Inctel co,.ltd would like to thank you for purchasing this product. - 1 -...

  • Page 2: Table Of Contents

    Operating Systems ................................- 4 - Conceptual Diagram ................................- 4 - 2. Installation ....................................- 4 - Install the IN-X300 PCI Card ............................. - 4 - Connect Peripheral Devices..............................- 6 - Install the software drivers..............................- 6 - Install the terminal services software and register ......................

  • Page 3: Product Features

    1024x768, 800x600, 16-bit color Small, efficient and eco-friendly With a small footprint and no moving parts, the IN-X300 runs completely silent and saves energy by using only 5 watts. Its design meets strict environmental guidelines and is ROHS compliant. imum System Requirements For one IN-X300 PCI card, a host PC with at least the following: •...

  • Page 4: Operating Systems

    IN-X300 PCI Card 1. Disconnect all peripheral and power cables from the host PC. 2. Remove the system cover of the host PC. 3. Find an available PCI slot for the IN-X300 PCI card. - 4 -...
  • Page 5 IN-X300 4. Insert the IN-X300 PCI card and secure the end of the card to the chassis with a retaining screw. Note: If required, you can use the included low profile bracket. 5. Replace the cover and reconnect all peripheral and power cables.

  • Page 6: Connect Peripheral Devices

    Wizard.” Insert the Software Installation CD into the host PC's CD drive. The “Hardware Update Wizard” dialog box will ask whether it is OK to contact Windows Update to find drivers for the IN-X300 PCI card. Note: Do not install anything from Windows Update for the IN-X300 PCI card. The driver installation must be done using the IN-X300 setup application.

  • Page 7: Install The Terminal Services Software And Register

    IN-X300 “Finish” button in the next screen. The previous paragraph’s process is repeated two more times. Install the terminal services software and register Go to "My Computer", open the CD drive's icon, and start the "Install.exe" application. At the installation screen, click the "software" button.
  • Page 8 IN-X300 At the antivirus and firewall warning screen, click the "Next" button. At the software license screen, you may view the software license and print it out. When you are finished, click on the "I agree" checkbox, and then click the "Next" button.
  • Page 9 IN-X300 At the software terms of use screen, you may view the software terms of use document and print it out. When you are finished, click on the "I agree" checkbox, and then click the "Next" button. At the readme file screen, you may view the readme file and print it out. When you are finished, click the "Next"...
  • Page 10 IN-X300 At the "Choose destination location" screen, you can install to the default location, or you can choose a different location. When you are finished, click on the "Next" button. At the "Choose Password for Administrator" screen, select whether or not to use an administrator password and whether or not to install the Network Administration Console.
  • Page 11 IN-X300 it and retype it. Click on the "Next" button. Note: The Network Administration Console allows you to administer the terminal services software and the access terminals in your network. It is recommended to be installed at least once on each network to enable administration tasks.
  • Page 12 IN-X300 At the "Add new users" screen, select whether or not you would like to add new users to the system. If you click on the "Yes" button, the installation program will launch a screen to administer user accounts on the host PC. If you click the "No"...

  • Page 13: Product Registration

    IN-X300 Note: It is required to reboot the computer before using the software or the access terminals connected to the host 3. Product Registration When registering the terminal services software, all the access terminals must be connected to the host PC.
  • Page 14 IN-X300 At any time during the registration process, you can click on the "Cancel" button and the process will be cancelled at that point. At any time during the process, you can use the "Back" button to return to previous screens in the registration process to change your entries.
  • Page 15 IN-X300 At the "Choose method" window, you can select what registration function to invoke. For the online registration functions, you can select whether to register or unregister the software and associated access terminals. In the offline functions, you can select whether to register or unregister the software and associated access terminals via a file that can be emailed, cancel a pending registration, or manually input keys from the offline registration process.

  • Page 16: Online Registration

    IN-X300 If you choose online registration, follow the instructions here. If you choose offline registration, skip ahead to that section. Online Registration When you select to register or unregister online, the next screen allows you to select what serial numbers to register or unregister.
  • Page 17 IN-X300 In the "Ready to register" screen, you see the user information you entered and the serial numbers you chose to register or unregister. Confirm the information is correct and click on the "Next" button to complete the process. In the "On-line Registration process" screen, you see the registration progress. Once the online registration...

  • Page 18: Offline Registration

    IN-X300 process is complete, the window shows the results of the process, including which serial numbers were successfully registered. Click on the "Finish" button. Offline Registration When you use offline registration, you can email a data file that includes the serial numbers you want to register or unregister.
  • Page 19 IN-X300 In the next window, you see the user information you entered and the serial numbers you chose to register or unregister. Confirm the information is correct and click on the "Next" button. In the next screen, you select where to place the file that must be emailed.
  • Page 20 IN-X300 Once you create the file, you can copy it to another PC, if necessary. Email the file to cld@zgshare.com. You will receive an email reply that includes an activation key for each serial number that you selected to register or unregister.

  • Page 21: Uninstallation

    IN-X300 To cancel an offline registration or unregistration that is already in progress, select the "Off line -Cancel registration" radio button and click on the "Next" button. The next window shows the serial numbers that are known by the host PC. Select the serial numbers for which to cancel the registration or unregistration process and click on the "Next"...

  • Page 22: Using The Management Console

    Start the management console from the Windows Start menu. The application is called, "NCX-2000-XP Console”. You can also start the management console by right-clicking on the IN-X300 icon in the system tray and selecting "NCX-2000-XP Management Console". Local Settings The "Local Settings" tree allows you to see and change settings for the host PC.

  • Page 23: Sessions

    IN-X300 Sessions The "Sessions" item shows information about all the sessions currently active on the terminal services software. - 23 -...
  • Page 24 IN-X300 By clicking on a session in the left window, you see two tabs of available information. The "Application loaded" tab shows all the applications running on the selected session. The "Information" tab shows the following information about the selected session: •...
  • Page 25 IN-X300 The “Station Settings” tab shows parameters that can be set for each station. - 25 -...

  • Page 26: Information & Settings

    IN-X300 Here is a description of each parameter that can be set in this window: • Station name: The name of the station. • Automatically turn station on when system starts: If this is turned off, the station will not start when the system boots up.
  • Page 27 IN-X300 The "Product Information" tree item shows information about the installed terminal services software, such as product name, build date, version string and vendor information.” - 27 -...
  • Page 28 • Allow Shutdown/Reboot from stations: whether or not the stations are given the option to shutdown or reboot the host PC. You can set this either on or off. • IN-X300 card video mode settings: The video mode settings for the IN-X300 stations. You can set this to either 800x600 or 1024x768.
  • Page 29 IN-X300 • Disable Send Broadcast Message: whether or not the administrator has disabled broadcast messages. You can set this either on or off. • Support WTSAPI32 Interface: whether or not the terminal services software has turned on support for the WTSAPI32 application interface.

  • Page 30: Usb-Device Assignment(S)

    IN-X300 USB-Device Assignment(s) - 30 -...

  • Page 31: Troubleshooting An Error Message

    This message appears when the access terminal’s serial number and activation key are not registered. Please register the serial number and activation key. Video playback doesn’t display properly Decrease the size of the video playback window. The IN-X300 access terminals have limited video playback capability. I can’t connect to the host PC...

  • Page 32: Glossary

    You can check the installation status of the drivers here. 8. Glossary Access terminal: a network computing terminal using IN-X300. It doesn't use a CPU, VGA, or main chipsets. It only uses a programmable system on a chip and a PCI card to connect to the Host PC.

  • Page 33: Faq

    IN-X300 Firewall: a set of related programs that protect the resources of a private network from users on other networks and control what outside resources its own users have access to. (The term also implies the security policy that is used with the programs.)
  • Page 34 To enable multiple user operation, follow all the instructions in the installation section of this user guide. To enable multiple screen operation, only install the IN-X300 bus enumerator and graphics drivers. Do not install the terminal services software. Then, right-click the desktop and select “Properties.” In the “Display Properties” window, select the “Settings”...
