R
O
DRINKING WATER SYSTEM
.
.
MODEL T.F.C.-300
INSTALLATION, OPERATION & SERVICE MANUAL
IMPORTANT NOTICES:
This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's responsibility to, and
the manufacturer strongly recommends that the user, periodically test the product water to verify the system is performing satisfactorily.
DO NOT USE WITH WATER THAT IS MICROBIOLOGICALLY UNSAFE OR OF UNKNOWN QUALITY, WITHOUT
ADEQUATE DISINFECTION BEFORE OR AFTER THE SYSTEM.
Advertisement
Table of Contents
Related Manuals for R.O. DRINKING WATER SYSTEM T.F.C.-300
Summary of Contents for R.O. DRINKING WATER SYSTEM T.F.C.-300
- Page 1 DRINKING WATER SYSTEM MODEL T.F.C.-300 INSTALLATION, OPERATION & SERVICE MANUAL IMPORTANT NOTICES: This reverse osmosis system contains replaceable treatment components critical for effective performance. It is the user's responsibility to, and the manufacturer strongly recommends that the user, periodically test the product water to verify the system is performing satisfactorily.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Page SECTION I. INTRODUCTION ................... 3 SECTION II. SPECIFICATIONS ..................5 SECTION III. INSTALLATION STEPS ................. 6 A. Faucet Installation ..................6 B. Feed Water Saddle Valve Installation ............7 C. Drain Clamp Installation ................7 D. R.O. Manifold Assembly Installation ............8 Position the Drinking Water Holding Tank and Make the Final Hose Connections ............. -
Page 3: Introduction
SECTION I. INTRODUCTION product water (the Permeate). The excess minerals Your new Reverse Osmosis (R.O.) Drinking Water are rinsed to drain (the Reject Water). System uses a combination of filtration technologies The membrane is specially constructed, fully to reduce unwanted contaminants in a water supply. aromatic polyamide film and is classified as a Thin The following steps combine to give you the best in Film Composite (T.F.C.). - Page 4 OPTIONAL T.F.C.–300 BASEMENT INSTALLATION DIAGRAM ����������� ������ �������������������������� ���������������������� ����������������������� ������������������� �������� ������� ����������� ������������� ������������� ��������������� ����� ���� ������������� ������������������������������� ��������������������������������� ����������������������������� ��������� ������ �������� ����������� ����������� ���� ������������� ������������ ���������� �������������� ����� ����������������� ���������� �������������� ����� ������������� ������������ ���������������������...
-
Page 5: Specifications
SECTION II. SPECIFICATIONS TABLE A – QUALIFIED SYSTEM PERFORMANCE Because the performance of an R.O. Membrane is highly dependent upon pressure, temperature, pH and TDS, the following should be used for comparison purposes only. U.S. Metric Membrane Production 40-60 gpd 151-227 lpd Membrane TDS Reduction 93% minimum... -
Page 6: Installation Steps
SECTION III. INSTALLATION STEPS tile is penetrated, then use the carbide tipped All plumbing should be done in accordance with state metal cutter. and local plumbing codes. Formica counter tops may be drilled with a NOTE: Some codes may require installation by a good 1¼"... -
Page 7: Feed Water Saddle Valve Installation
•Rotate the Spout and Body into position. fully clockwise (inward). A small amount of Align the Split Washer and the Spacer to water may escape from the outlet until it is allow access to the Hose Barbs, and tighten fully pierced. the Hex Nut while holding the faucet in When you feel the Valve Handle firmly alignment with a padded Crescent wrench. -
Page 8: Manifold Assembly Installation
3/8" DRAIN CLAMP ASSEMBLY Drain Pipe 1/4" Nut Drain Clamp Front Plate 1/4" Screw Drain Clamp Back Plate Black Drain Tubing Figure 4 Firmly press one end of the tubing over the The close proximity of a dishwasher or a trash "... -
Page 9: Position The Drinking Water Holding Tank And Make The Final Hose Connections
the black plug from the fitting labelled “Drain” 1. Sanitizing the system. Use a drip pan to aid on the manifold and insert the tubing. The clean–up. end of the Black Drain Tubing that should be NOTE: The system should be sanitized inserted into the “Drain”... -
Page 10: Operation And Maintentance
•Insert the Membrane up into the manifold. function. Other uses for the water are flowers, (The O–rings should be up toward the pets and rinsing glassware. manifold.) Check the Housing O–ring for With each use it is recommended that you proper position in its groove, engage and turn the tap for at least 10 seconds prior to firmly tighten the Housing hand tight only. - Page 11 •Use a good quality unscented 5¼% liquid chlorine household bleach. •Add one capful of bleach (this is 2 tsp. or 10 ml) to the Sediment/Carbon Filter Housing and temporarily install the Housing without the Sediment/Carbon Prefilter. Check the Housing O–ring for proper position in its groove, engage and firmly tighten the Housing hand tight only.
-
Page 12: Trouble Shooting Guide
SECTION V. TROUBLE SHOOTING GUIDE Problem Possible Cause Solution Low quantity of Product Water Feed Water Saddle Valve is plugged or Open Valve or unclog. from Holding Tank closed. Clogged Sediment/Carbon Prefilter or Replace filters. Activated Carbon Post Filter. Low water pressure Feed Water pressure must be above 40 psig. - Page 13 Problem Possible Cause Solution High Total Dissolved Solids (TDS) The Product Water and Drain Water Correct plumbing. in the Product Water lines are reversed. (continued) No drain flow, Drain Restrictor is Clear or replace Drain Restrictor. clogged. No drain flow, the drain orifice in Clear or replace Air Gap Faucet.
-
Page 14: Exploded View And Parts List
EXPLODED VIEW & PARTS LIST ���� �� ���� MADE IN USA... - Page 15 DRAWING NO. PART NO. DESCRIPTION 1...... S2009 ........Self Tapping Screw 2...... S2005PP ......... ASO Cap 3...... S2013 ........ASO Cap O–Ring 4...... S2011 ........ASO Diaphragm – Large 5...... S2007PP ......... ASO Piston 6...... S2006PP ......... ASO Piston Ring 7......
- Page 16 In addition, the membrane is only warranted if the required feed water conditions are met. The above warranty will also not apply to any part of the R.O. Drinking Water System that is damaged because of neglect, misuse, alterations, accident, misapplication, physical damage, or damage caused by fire, acts of God, freezing or hot waters or similar causes.
