Page 1: User Manual
Hi-Fi Tower Speaker BTS-800 User Manual... -
Page 2: Table Of Contents
Contents Safety Information .......................1 Connection .........................3 Panels ........................4 Remote control ......................5 General operation ......................6 FM operation ......................7 Bluetooth operation ....................8 Audio / USB operation ....................9 Trouble shooting .......................10 Accessories User manual *1; Remote control *1; Power cable *2; FM antenna* 1; Audio cable* 1. Warning Please read and understand all the warnings given in the following and those marked on the unit. -
Page 3: Safety Instructions
Safety instructions Caution: To reduce the risk of electric shock do not open this device, there are not serviceable parts for customers. Please refer any maintenance or repair to qualified personnel. This sign means the existence of dangerous voltage at the inside of the unit, which states a risk of electric shock. -
Page 4: Connection
Connection Disc Player FM antenna Pair indicator Aux input PAIR USB stick Power input Main speaker Vice speaker NOTE: When turning on the speakers to play mode, or if you set the Main speaker into standby mode, the pairing indicator will flash blue for about 3 minutes, then goes off. Use only the power supplies list in the instructions. -
Page 5: Panels
Panels POWER INDICATOR DISPLAY REMOTE SENSOR NFC SENSOR VOLUME+/ NEXT PLAY/PAUSE STANDBY VOL- VOL+ VOLUME-/ PREVIOUS SOURCE COAXIAL 1 INPUT OPTICAL INPUT USB PORT COAXIAL1 FM ANTENNA COAXIAL2 OPTICAL AUDIO INPUT COAXIAL 2 INPUT AUX INPUT POWER SWITCH POWER INPUT... -
Page 6: Remote Control
Remote Control MUTE STANDBY AUX INPUT BLUETOOTH COAXIAL 2 COAXIAL 1 DISPLAY OPTICAL COAX 1 COAX 2 DISPLAY RESET ROCK JAZZ CLASS RESET SOUND FIELD VOCAL DANCE FLAT TREBLE BASS BASS+ TREBLE+ VOLUME+ PLAY/PAUSE PREVIOUS NEXT PREV NEXT VOLUME- TREBLE BASS VOL- BASS-... -
Page 7: General Operation
General operation PREPARATION Before power on this unit, please check if all the connections are right and safe. Then connect the main power. Press the POWER SWITCH to power on the unit. STANDBY MODE Press the STANDBY button to wake up the unit or turn to standby mode. SELECT MODE Press the SOURCE button on the top panel or press the AUX, FM, USB, BT, OPT,... -
Page 8: Fm Operation
FM operation 1. Vary the antenna direction to get the best reception. 2. Up to 60 stations may be preset when turning on to radio mode with good reception. 3. The FM frequency is 87.5-108.0MHz. 4. Press SOURCE button on the panel or FM button on remote control to enter FM mode. 5. -
Page 9: Bluetooth Operation
2. Press SOURCE button on the panel or press BT button on remote control to enter the Bluetooth mode. 3. Enter the Bluetooth search list on your phone, and select the device named BTS-800. 4. Some devices may ask you to select OK/YES/PAIR to pair the phone with the unit. -
Page 10: Audio / Usb Operation
Audio operation & USB operation You can connect the unit with Disc player/MP3 player/smart phone or other music device via an audio cable or optical fiber cable. Audio 1. Connect one end of 3.5mm audio cable to the Mp3 player’s line output/headphone and the other end to the AUX IN socket on the rear panel of the unit (cable not supplied). -
Page 11: Trouble Shooting
Trouble shooting & Specifications Power supply can not be turned on * Make sure that the power cord is fully inserted in the power outlet. The remote control does not work * Battery is used up. * The front end of the remote control is not aimed at the infrared reception part of the unit. No sound * Make sure that the audio cable is connected correctly and securely to the back of your unit and to the sound system.
Need help?
Do you have a question about the BTS-800 and is the answer not in the manual?
Questions and answers
How to change and set radio channels
To change and set radio channels on the Sinotec BTS-800:
1. Press the SOURCE button on the panel or the FM button on the remote control to enter FM mode.
2. Vary the antenna direction to get the best reception.
3. Use the 0-9 number buttons on the remote control to select a specific frequency or station.
4. Up to 60 stations can be preset when in radio mode with good reception.
This answer is automatically generated
hi I can't connect via Bluetooth to my bts800 - my speakers were purchased 7 years ago. It tells me that it cannot pair
To troubleshoot Bluetooth pairing issues with your Sinotec BTS-800 speakers:
1. Ensure the Bluetooth device (e.g. smartphone) is turned on and within 10 meters of the speaker.
2. Press the SOURCE button on the speaker panel or the BT button on the remote to enter Bluetooth mode.
3. On your phone, search for Bluetooth devices and select "BTS-800."
4. If prompted, confirm pairing by selecting OK/YES/PAIR or enter the code "0000."
5. If pairing fails, turn off Bluetooth on your device and unpair the BTS-800.
6. Try pairing again by repeating steps 2 to 4.
Ensure no other devices are connected and that your device supports Bluetooth pairing.
This answer is automatically generated
