- Page 1 ReaR View CameRa SyStemS © 2009-2013 Rear View Safety, Inc.
-
Page 2: Table Of Contents
contents Introduction ............Safety Information ..........Installation Guide ..........Features ............... Multiplexer Specs ..........Positioning ............Monitor Dimensions ..........Camera Dimensions ..........Camera Specs ............Monitor Specs ............LCD Parametres ............ Splitting and Installing the Embedded Monitor..Troubleshooting ............. Warranty............... -
Page 3: Introduction
introduction Please read all of the installation instructions carefully before installing the product. Improper installation will void manufacturer’s warranty. Congratulations on purchasing a Rear View Backup Camera System. With this manual you will be able to properly install and operate the unit. The Backup Camera System is intended to be installed as a supplement aid to your standard rear view mirror that already exists in your vehicle. - Page 4 If you have any questions about this product, please contact our Customer Service: IN NO EVENT SHALL SELLER OR MANUFACTURER BE LIABLE FOR Rear View Safety, Inc. ANY DIRECT OR CONSEQUENTIAL 1680 Atlantic Ave #301 DAMAGES OF ANY NATURE, OR...
- Page 5 before begin installation Before drilling please check that no cable or wiring is on the other side of the wall. Please clamp all wires securely to reduce the possibility of them being damaged while vehicle is in use. Keep all cables away from hot or moving parts and electrical noisy components.
- Page 6 installation diagram DC12V(RED) Ground (black) Port #3 (blue) Port #2 (white) Port #1 (yellow) Power Cable...
- Page 7 installation instructions Note: The folloWING INSTRuCTIoNS ARe foR TypICAl ReAR-vIeW ApplICATIoN. Camera Attach camera bracket close to rear marker lights, centered on vehicle. Attach camera to bracket using screws provided and adjust the angle. Cable Be sure to position the cable properly. The aviation camera cable uses aircraft grade connectors which means the camera cable can be exposed to all weather elements, do not run the cable over sharp edges, do not kink the cable and keep away from HOT and rotating parts.
- Page 8 installing monitor On Select Models Figure 1.1 Figure 1 .2 Figure 1.3 Figure 1.4 Connection of U Bracket Connection of Flushmount Bracket...
- Page 9 wiring camera & monitor Camera: Drill a 20mm (0.8in) diameter hole into When installing a oNe (1) camera setup, connect vehicle body near the camera and bracket. Insert camera extension cable from the rear view camera camera cable into vehicle (be careful not to kink to port # labeled “backup”...
- Page 10 installation Audio works on two ports of multiplexer and To automatically have camera and monitor turn ON when vehicle activates, simply twist positive triggers must be triggered for audio to BLUE positive trigger 12V+ to Red Power line operate. #3 Port labeled “backup” (blue trigger) 12V+ and wire to ignition power which can be #2 port labeled “DVD”...
- Page 11 camera diagram In some models, to remove gridlines from camera, cut green wire...
- Page 12 multiplexer or DVD...
-
Page 13: Positioning
positioning... -
Page 14: Monitor Dimensions
monitor dimensions Some Models mirror/ with sun shade channel normal power menu down selection image power video select down/up menu mirror/ normal image... -
Page 15: Camera Dimensions
camera dimensions... -
Page 16: Camera Specs
camera specs. Camera 1/4 Sharp® Color CCD Picture Elements 250,000 pixels Gamma Correction r=0.45 to 1.0 Image Sensor 480TV lines Lens 2.1mm View Angle 130° Sync System Internal Synchronization Infra-red distance 50 Feet (18 Infrared) Usable Illumination 0 Lux (IR On) Power Source DC 12V-24V (+/- 10%) S/N Ratio... -
Page 17: Monitor Specs
monitor specs. TFT LCD Digital Monitor Screen Size 7” Dot Resolution 800 X 3 (RGB) X480 Display Format 16:9 / 500:1 Display Brightness 400cd/m² Viewing Angle U:50/D:60 L/R:70 Video Input 3 channel Video Source 1Vp-p, 75Ω Power Supply DC 12V-24V(+/-10%) Power Consumption Operating Temperature 30°C ~ +80°... - Page 18 splitting & installing embedded monitor Installing sun shield: put shade cover on the display. Installing Installing back cover: Put the monitor with shade cover in the back cover (only for embedded monitor) Sun Shield Monitor Splitting back cover: hold monitor with two hands, and detach by Splitting fingers as indicated by the arrow (only for embedded monitor, see below)
- Page 19 troublshooting Monitor displays Blue screen & displays No Signal Verify camera cable is plugged into port labeled Do a hard reset, unplug all cables and power “Backup Camera”. cables from multiplexer (silver box) leave out for 1 minute and then re-connect them. Verify that the blue positive trigger on power harness is put to power 12v+ If the problem still persists, verify that alternate...
- Page 20 We reserve the right to repair or replace any such defective unit at our sole discretion. Rear View Safety, Inc. is not responsible for a defect in the system as a result of misuse, improper installation, damage or mis-handling of the electronic components.
- Page 21 1680 Atlantic Ave #301 Brooklyn NY 11213 800-764-1028 www.rearviewsafety.com © 2009-2013 Rear View Safety, Inc.
