Summary of Contents for Gentner Digital-6
- Page 1 The most common problems with the Digital-6: Reset the presets if the batteries die. Please see the following pages to re-setup your Digital-6...
- Page 2 Digital-6 User’s Guide Tuning Changing Preset Selection: The Digital-6’s six presets come factory set to frequencies across the Assistive Listening Band selected for best overall performance: Preset Factory Setting Frequency Channel 2 72.1 MHz Channel 10 72.5 MHz Channel 19 72.95 MHz...
- Page 3 Digital-6 User’s Guide Step 1 Remove the battery cover from the back of the receiver. Step 2 Remove the two Phillips case screws and remove the back panel. Digital-6 (back) Battery Cover...
- Page 4 Digital-6 User’s Guide Tuning Step 3 Turn the preset selector wheel to the desired preset (1-6). Step 4 Using a small, flathead screwdriver, turn the channel setting rotary switches to the desired channel number. The left-hand switch indicates the “ones” place. The right-hand switch indicates the “tens”...
- Page 5 Digital-6 User’s Guide Channel Setting Rotary Switches PB Board Preset Memory Selector Button Note Before changing batteries, wait one minute after turning off the receiver. This allows the CPU to switch from active mode to standby mode. Otherwise memory will be lost and the presets will return to the factory settings.
- Page 6 Digital-6 User’s Guide Frequency Chart Channel *Frequency Channel *Frequency 72.05 74.65 72.10 74.70 72.15 74.75 72.20 75.25 72.25 75.30 72.30 75.35 72.35 75.40 72.40 75.45 72.45 75.50 72.50 75.55 72.55 75.60 72.60 75.65 72.65 75.70 72.70 75.75 72.75 75.80 72.80 75.85...
