- Page 1 B8866 IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. www.fi sher-price.co.uk...
-
Page 2: Consumer Information
Consumer Information IMPORTANT! Place the high chair on a level, stable surface away from electrical flexes. Be sure to keep electrical flexes out of child's reach. WARNING • Please read these instructions before assembly and use of this product. • Adult assembly is required. Prevent serious injury or death from falls •... - Page 3 Parts Seat Back 2 Frames Seat Bottom 2 Bases Footrest 2 Seat Bottom Tubes Hinge Rod Food Tray Base Tray Teether Toy Note: Tighten or loosen all screws with a Phillips screwdriver. Do not over-tighten the screws. #8 x 1,9 cm Screws – 8 #10 x 2,2 cm Black Screw –...
- Page 4 Assembly IMPORTANT! Before assembly and each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Mattel for replacement parts and instructions if needed. Never substitute parts. Footrest Seat Bottom •...
- Page 5 Assembly Insert Screws Here Hinge Hinge Rod • Insert two #10 x 2,2 cm black screws through the footrest and into the seat bottom. Tighten the screws. This may require • Turn the seat assembly face down. extra force. • Insert the hinge rod through the hinge on the seat back and seat bottom, as shown.
- Page 6 Assembly Frame Leg Seat Height Adjusters Position 4 Frame Decorated Side Press Lever Frame Back Legs • While pressing the levers on the seat height adjusters, lift them to position 4 on the frame front legs, as shown. Seat Assembly Base Screw Retainers Sockets...
- Page 7 Assembly Push Push Screw Retainers Seat Bottom Tube Ends Base • Insert the frame front legs onto the remaining base. • Push each seat height adjuster to be sure they are completely on the • Fit a screw retainer over a hole in the front leg. seat bottom tubes.
- Page 8 Assembly Seat Seat Height Height Adjuster Adjuster Elastic Loops Seat Bottom Hole Hole Tube Ends • Push each seat height adjuster to be sure they are completely on the seat bottom tubes. • Insert a #8 x 1,9 cm screw through each seat height adjuster and the ends of the seat bottom tube.
- Page 9 Assembly Slot Crotch Belt Bottom Slots • Insert the crotch belt through the slot in the pad. Make sure the crotch belt is not twisted. • Lift the top of the pad. • Thread the waist/shoulder belts through the bottom slots in the Shoulder Portion back of the seat pad.
- Page 10 Assembly Pad Strap Upper Shoulder Handle Belt Slots Shoulder Portion Elastic Elastic Loop Loop Belt Ends • From behind the seat, be sure the shoulder portion of the waist/shoulder belts are secure in the seat back slots. • Fit the pad strap through the handle and press it to the fastener on the back of the seat.
- Page 11 Secure Child Anchored Anchored WARNING Prevent serious injury or death from falls or sliding out. The child should at all Free End times wear a safety harness correctly fitted Free End Buckle and adjusted. The tray is not designed to hold the child in the chair.
- Page 12 Secure Child Shoulder Portion To change shoulder belt slots: • From the front of the high chair, pull the shoulder portion • From the back of the high chair, push the shoulder portion of the waist/shoulder belts out and then fit them back of the waist/shoulder belts through the seat back slots.
- Page 13 Using the Trays WARNING Prevent serious injury or death from falls or sliding out. The child should at all times wear a safety harness correctly fitted and adjusted. The tray is not designed to hold the child in the chair. Base Tray •...
- Page 14 Using the Trays Using the Teether Toy Teether Toy Food Tray Base Tray Slot • Insert and “snap” the teether toy tab into either slot in the tray. Hint: To remove the teether toy, press the tab and lift the toy. •...
-
Page 15: Adjusting The Seat
Adjusting the Seat Hint: Adjust the seat height to any of seven positions! WARNING Seat Height Prevent serious injury or death from Adjuster falls or sliding out. It is recommended that only children capable of sitting upright unassisted use the high chair in the upright position. - Page 16 • Pull the frame release latches forward and push the rear legs toward the front legs. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, New York 14052, U.S.A. ©2006 Mattel, Inc. All Rights Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
