VoiceOFF – Playback pre-recorded messages
With a powerful built in 10W amp & speaker, and IP65 case you can use it in a lot of different applications.
It can be triggered by using hard-wired alarm inputs or even via RS232 commands from other electronic equipment such as a
computer or Digital Recorder (DVR)
The VoiceOff is a new and innovative product. You can use it to playback a wide variety of sound files,
these range from messages welcoming guests or even warning off intruders. You can even have
informative messages such as telling visitors to a building site to "please wear a hard hat at all times" -
complying with health & safety is big thing this days and the voice off makes it even easier to comply!
(note – useful pre-recorded messages are available to download at the voiceOff website for a small fee).
Alternatively you can store and play music using the VoiceOff as a digital media player for indoor or
outdoor use. All the sound files are stored in the VoiceOff on a removable SD card so it's really easy to
do quality recordings away from site in a suitable recording location.
Some people even use the VoiceOff to playback sound effects such as
a dog barking or very faint police car in the distance to scare off
unwelcome visitors who have entered restricted areas they shouldn't
have.
It's really 2 products in 1 because of its 2 distinct features.
Feature 1 is its ability to playback pre-recorded MP3 sound files through its built in amplifier and speaker. These sound files
can be recorded and customised by the end-user for maximum flexibility.
Email:
support@voiceoff.com
VoiceOFF MK2 -
to either welcome, warn or inform
Programmable Audio Alarm
More voice and sound files available to download at:
Doc XVOX200
Code: VOX200 MK2
(or sounds)
www.voiceoff.com
Last Revised: 16/02/2012

Advertisement

loading
Need help?

Need help?

Do you have a question about the MK2 and is the answer not in the manual?

Questions and answers

Summary of Contents for VoiceOFF MK2

  • Page 1 Alternatively you can store and play music using the VoiceOff as a digital media player for indoor or outdoor use. All the sound files are stored in the VoiceOff on a removable SD card so it’s really easy to do quality recordings away from site in a suitable recording location.
  • Page 2 PIR detector that starts the message when someone walks in through the entrance. Or you could use the VoiceOff to warn people away. This message may say for example, “You have been detected on CCTV. Please leave the area!” Whatever you put your imagination too, the VoiceOff has an application - even now you are using the VoiceOff for another use - to playback information.
  • Page 3 Once you have recorded your messages or sounds you need to copy them to an SD card that is then inserted into the VoiceOff unit. The audio files need to be stored on the SD card in a certain way and the files need to be saved with names that allow the VoiceOff unit to know which MP3 file to play depending on which alarm input is triggered.
  • Page 4 1 is triggered, the VoiceOff looks for an MP3 file that has been named 0001.mp3. It looks for this file in the folder called SYSQ on the card. Similarly if alarm input 2 is triggered, the VoiceOff looks for an MP3 file named 0002.mp3 and so on.
  • Page 5 A terminal strip displays the following: On the VoiceOff PCB, alarm inputs 1 to 5 are labelled up A1 – A5, alarm inputs 6 - 10 are labelled B1 – B5, alarm inputs 11 – 20 are labelled C1 - D5 If you wish to replace the messages recorded on the free SD card provided with the VoiceOff unit just make your own sound files and rename them so they overwrite the corresponding files on the card.
  • Page 6: Installation Instructions

    Installation Instructions 1. The VoiceOff unit can be installed either internally or externally using four screw locations, one on each corner of the unit. 2. A free SD card is provided with the unit containing professionally recorded voice messages and sounds. They are as...
  • Page 7: Rs232 Setup

    Code: VOX200 MK2 8. You may have a special or different use for the VoiceOff that does indeed require instant termination of any message that is playing. Of course, provision is provided for this with a “RESET” terminal. You can immediately terminate a triggered recording by connecting a switch to GND (and ground A, B or C) and RESET.
  • Page 8: Volume Control

    Volume Control The VoiceOff has a volume control that is set on installation to match the site requirements. For example, if you are installing the unit to play warning messages to deter unwanted visitors to a secure parking lot, you may want the volume on maximum as you want those intruders to hear your message loud and clear.
  • Page 9 All specifications are approximate. Voiceoff.com reserves the right to change any product specifications or features without notice. Whilst every effort is made to ensure that these instructions are complete and accurate, voiceoff.com cannot be held responsible in any way for any losses, no matter how they arise, from errors or omissions in these instructions, or the performance or non-performance of the equipment that these instructions refer to.
