SportNeb Express 9R-023 series Instruction Manual

Compressor Nebulizer
Instruction Manual
Part No. : 3055
.
SAVE THESE INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE.
Model No: 9R-023 series
CAUTION - U.S. Federal Law restricts this device to
sale by or on the order of a physician.
666001-6310 V1.1
This product has been tested and successfully
approved with the following standards:
EN 60601-1
EN 60601-1-2

Contents

IMPORTANT SAFEGUARD..............................1

Introduction...................................................2

Product Description.......................................3

Operation......................................................4
Cleaning........................................................5
Storage.......................................................6
Maintenance................................................7
Troubleshooting..........................................8
Specifications................................................9

1. IMPORTANT SAFEGUARDS

DANGER -
To reduce the risk of electrocution:
1. Always unplug this product immediately after using.
2. Do not use while bathing, showering, dish washing, or close
to water sources of any kind.
3. Do not place or store product where it can fall or be pulled
into a tub or sink.
4. Do not place in or drop into water or other liquid.
5. Do not reach for a product that has fallen into water. Unplug
immediately.
-
WARNING To reduce the risk of burns, electrocution, fire or
injury to persons:
1. This product should never be left unattended when plugged
in.
2. Close supervision is necessary when this product is used by,
on or near children or invalids.
3. Use this product only for its intended use as described in this
manual. Use this product only under doctor's direction. Do
not use attachments not recommended by the manufacturer.
4. Never operate this product if a) it has a damaged cord or
plug, b) it is not working properly, c) it has been dropped or
damaged, d) it has been dropped into water. Return the
product to a specified service center for examination and
repair.
5. Keep the cord away from heated surfaces.
6. Never block the air openings of this product or allow objects
to fall or be inserted into the air vent openings or place it on a
soft surface such as bed or couch, where the air openings
may be blocked.
7. Never use while sleeping or feeling drowsy.
8. Never drop or insert any object into any opening or hose.
9. Do not use in outdoors or operate where aerosol (spray)
products are being used or where oxygen is being
administered in a closed environment such as an oxygen
reservoir.
NOTE, CAUTION , SYMBOLS AND WARNING
STATEMENTS:
NOTE : Indicates information that user should pay special
attention to.
CAUTION : Indicates correct operating or maintenance
procedures in order to prevent damage to or destruction of
the equipment or other property.
WARNING : Calls attention to a potential danger that
requires correct procedures or practices in order to prevent
personal injury.
O Off, disconnection from the mains
I On, connection to the mains
～ Alternating current
IPX0 Enclosed equipment without protection against ingress
of water
Attention
Class II
"BF" symbol, indicate this product is according to the
degree of protecting against electric shock for the type
BF equipment.
Disposal of Electrical & Electronic Equipment (WEEE):
This product should be handed over to an applicable
collection point for the recycling of electrical and
electronic equipment. For more detailed information
about the recycling of this product, please contact your
local city office, household waste disposal service or the
retail store where you purchased this product.
2. Introduction

2.1 Intended Use

The SportNeb eXPRESS Compressor Nebulizer System
is intended to provide a source of compressed air for
aerosol therapy. It is used in conjunction with a jet
(pneumatic) nebulizer to produce medicated aerosols for
inhalation by pediatric and adult patients with respiratory
symptoms.
CAUTION - Indications for therapy include asthma,
chronic bronchitis, infection of the upper respiratory
tract, chronic obstructive pulmonary disease and
other respiratory disorders in accordance with a
medical doctor's prescription. Except the usage
mentioned above, please do not use this product for
any other purpose. This device can be used with
adults or pediatric patients under physician's
prescription.
2.2 Safety Precaution Instruction
When using this electrical product, especially when
children are present, one should always follow basic safety
precautions. Do not install, maintain or operate this
equipment without reading, understanding and following
the proper SportNeb eXPRESS Compressor Nebulizer
System instruction manual, otherwise injury or damage
may result. Important information is highlighted by using
the following bulletin:
DANGER：Urgent safety information for hazards that will
cause serious injury or death.
WARNING：Important safety information for hazards that
might cause serious injury or property damage.
： Information for preventing damage to the product.
CAUTION
For 120V only-
This appliance has a polarized plug (one blade is wider
than the other). To reduce the risk of electric shock, this
plug is intended to fit into a polarized outlet only one way. If
the plug does not fit fully into the outlet, reverse the plug.
If it still does not fit, contact a qualified electrician. Do not
modify the plug in any way.
3. Product Description
1. Power Switch
2. Filter Cap (disposable filter inside)
3. Air-Outlet Connector
4. Integrated Carrying Handle
5. Power Cord
6. Tubing Holder
7. Cooling Air Openings
