Page 2: Table Of Contents
® Table of Contents Contents Page Assembly ......................................2 Batteries ......................................4 Quick Start ..................................8 ™ Basic Adjustments ..................................14 1. Target Volume ..................................18 2. Audio Threshold .................................. 18 3. Tone (Audio Frequency) ..............................19 4. Audio Disc................................... 19 5. -
Page 3: Assembly
Chapter 1 DFX Assembly ™ Assembly Twist and insert each end of WASHERS handle (provided) through BETWEEN top of shipping carton into EACH LOOP LOOP OR SEARCH second fl ap. EAR & CLEVIS COIL (CARRY CARTON) CABLE RETAINERS DISPLAY 1/ PRESET PROGRAMS... -
Page 4: Assembly Instructions
Chapter 1 DFX Assembly ™ Assembly Instructions 1. Remove all parts from shipping carton and readjust clevis/lower rod length with the spring clip check the assembly page to make sure all parts are buttons so that the search coil can be held near the present. -
Page 5: Batteries
Chapter 2 DFX Batteries ™ Batteries Standard Battery Holder BLUE DECAL 1. The standard battery holder (blue decal) holds eight “AA” cell batteries. Alkalines are recom- mended for use with this battery holder. ARROW DOWN 2. Non-alkaline batteries can be used in this holder. -
Page 6: Standard Battery Holder
Chapter 2 DFX ™ Batteries Using the Rechargeable Battery Standard Battery Holder 1. Slide open the battery holder lid (decal side of GREEN BATTERY battery holder) by applying gentle upward DECAL CHAR- pressure on the tab of the door so that it unlocks. - Page 7 Chapter 2 DFX Batteries ™ Charging 1. There is no harm charg- ing overnight using the OVERNIGHT charge setting regardless of the battery's current condition. However, before charging with the QUICK charge setting, determine battery condition by inserting bat- tery into the instrument and turning the instrument ON.
- Page 8 Chapter 2 DFX™ Batteries Battery Life & Memory Volatile memory temporarily holds any program by up to 50%, depending on battery type. changes or settings not yet saved in a Custom Pro- gram. Short-term or volatile memory is retained so Rechargeable batteries gradually deteriorate.
-
Page 9: Dfx ™ Quick Start
Quick Start ™ Quick Start ™ Quick Start Instructions ™ After you have assembled the DFX and inserted the ™ battery pack, follow these simple steps to start treasure hunting! With the TRIGGER in the center position, press the ON/OFF control and an automatic sequence will begin. - Page 10 "beeps" and you lower the search coil to the ™ distance above the ground that you will be search- Now that you're sweeping the loop smoothly over ing. Press ENTER to have the DFX "cancel/track ™ the ground, you will notice that the detector starts out"...
- Page 11 Chapter 3 DFX Quick Start ™ Live Search Screen - what is it telling me? A. Sweep the loop over the target several times VISUAL POSSIBLE TARGET IDENTITIES and look at the SignaGraph . The SignaGraph® ® DISCRIMINATION ("ICONS") INDICATION-V.D.I. NUMBER automatically clears itself (FADE RATE) so that it ("TARGET REFERENCE NUMBER")
- Page 12 Chapter 3 DFX Quick Start ™ Live Search Screen Samples Nickel, or Penny or a possible ring. dime. If the Sometimes a screw cap and small (or half) penny ICON pull tab will are displayed, produce this the target indication...
-
Page 13: Pinpointing The Target
Lifting the loop Pinpointing takes practice. The standard loop pro- slightly above the ground, releasing and re- vided with the DFX™ is a high-powered, 9.5 inch squeezing the TRIGGER and again "X" ing the design. This harmonically tuned loop's strongest target will aid pinpointing. - Page 14 Chapter 3 DFX Quick Start ™ Ready to Dig Factory Preset Programs Permission - Prior to searching and digging you Reached from the MAIN MENU, the factory PRE- must have permission to search private property, SET PROGRAMS give a quick start for: from the owner or caretaker.
-
Page 15: Basic Adjustments
Chapter 4 DFX Basic Adjustments ™ Basic Adjustments Basic Adjustments - what do they do? 1. TARGET VOLUME - How loud a target beeps when detected. 2. AUDIO THRESHOLD - The slight hum or background sound heard continuously during searching. - Page 16 Chapter 4 DFX Basic Adjustments ™ More Basics "Hot Key" Shortcuts All the MENU items are tied together so that the "HOT KEYS" will save time as they allow easy ARROW up and down controls scroll through every access, from the search mode, to the most needed adjustment screen.
- Page 17 Chapter 4 DFX Basic Adjustments ™ Custom EEPROM Programs Saving Basic and Pro Option adjustments for future use. Save custom settings in any one of four EEPROM program positions. They will remain permanently USE THE ARROW KEYS TO SCROLL THE...
- Page 18 Chapter 4 DFX Basic Adjustments ™ 4. To NAME, use the ARROW controls to select 4. To NAME, 4. To NAME, 4. To NAME, as described above. The old program can only be the fi rst symbol, number, or letter of the name and erased when a new program is stored in that posi- press ENTER.
-
Page 19: Target Volume
Chapter 4 DFX ™ Basic Adjustments 1. Target Volume 48 - 63 How loud a target beeps when detected. Select TARGET VOLUME with the ARROW controls and press ENTER. The current volume level sounds continuously. The number designating the current level is shown on the right side of the Tip - Select the loudest display. -
Page 20: Tone (Audio Frequency)
Chapter 4 DFX Basic Adjustments ™ 3. Tone (Audio Frequency) Selects the frequency or pitch of the sound the detector produces. Select TONE (AUDIO FREQ.) with the ARROW controls and press ENTER. The current TONE will sound continuously. The number designat-... -
Page 21: Silent Search
Chapter 4 DFX Basic Adjustments ™ 5. Silent Search The ability of the detector to be operated without the threshold or background hum that is normally heard continuously during operation. The instrument is silent until a target is detected. Select SILENT SEARCH with the ARROW... -
Page 22: Mixed Mode
Chapter 4 DFX Basic Adjustments ™ 6. Mixed Mode A unique hybrid operating mode. It is an all- metal (DC non-motion, non-discriminate) mode, working simultaneously with a discriminate (AC motion discrimination) mode. It is two modes, one detecting everything and another discriminating, operating at the same time. -
Page 23: Sensitivity
Chapter 4 DFX Basic Adjustments ™ 7. A.C. Sensitivity Used to select the appropriate sensitivity (degree that the instrument is responsive to signals) while being used in the discriminate modes (those which require movement of the loop). Select A.C. SENSITIVITY with the ARROW... -
Page 24: Backlight
Chapter 4 DFX Basic Adjustments ™ 9. Backlight Used in dark conditions to light the display, improving visibility. Select BACKLIGHT with the ARROW controls and press ENTER. Use the ARROW controls to select the desired BACKLIGHT level. The Tip - Use only when needed, and only as bright BACKLIGHT level will be visible on the display. -
Page 25: Viewing Angle
Chapter 4 DFX ™ Basic Adjustments 10. Viewing Angle Adjusts the display for visibility in low or high temperature conditions. Select VIEWING ANGLE with the ARROW con- trols and press ENTER, use the ARROW controls to make changes. The current level is shown on Tip - In cold temperatures the right side of the display. -
Page 26: Pro Options
Differences at 3 kHz and 15 kHz skew the well known traditional (6.59 kHz) V.D.I. chart/numbers painted on the top of the DFX control box. Normalization recalculates signals for this traditional V.D.I. - Page 27 Chapter 5 DFX Pro Options ™ Pro Options Basics of Pro Options The PRO OPTIONS are used to make the more MAIN MENU Screen intricate adjustments available on this model. The PRO OPTIONS are divided into fi ve major cat- egories of menus, structured similar to the Basic Adjustments.
-
Page 28: Audio
Chapter 5 DFX Pro Options ™ (Audio section) 1. Ratchet Pinpointing Pinpointing feature, automatically detunes for easy target-center locating. ON - Automatically aids in pinpointing. When the TRIGGER is squeezed and held for pinpointing, RATCHET PINPOINTING will shrink the size of... -
Page 29: Speed
Chapter 5 DFX Pro Options ™ (Audio section) 2. S.A.T. Speed Self-Adjusting Threshold (auto-tune) smooths the THRESHOLD, OFF (0), or ON (1-10). Without S.A.T. SPEED (a setting of 0), changes in the ground (and the passage of time) will tend to produce changes in the THRESHOLD sound. -
Page 30: Tone I.d
Chapter 5 DFX Pro Options ™ (Audio section) 3. Tone I.D. Assigns each V.D.I. number its own distinct tone or pitch. Target ranges can easily be identifi ed by their sound. The higher the V.D.I. number, the higher the pitch of their sound. Reject targets still break up or "cutout". -
Page 31: Modulation
Chapter 5 DFX Pro Options ™ (Audio section) 5. Modulation Allows motion modes to produce different volume levels based on target depth. Modulation is used in the discriminate or motion modes. When ON, it allows the depth of the target to dictate the volume of the response. -
Page 32: Autotrac
Chapter 5 DFX Pro Options ™ (G.E.B./Trac section) 6. AutoTrac ® AUTOTRAC allows the instrument to automati- ® cally readjust the Ground Balance setting during searching. This readjustment allows for natural occurring changes in the ground mineral of an area. By maintaining an accurate Ground Balance, detection depth and stability are enhanced. -
Page 33: Trac Speed
Chapter 5 DFX Pro Options ™ (G.E.B./Trac section) 8. Trac Speed Dictates when AUTOTRAC adjusts Ground Bal- ® ance. Trac Speed allows adjustment of the amount of ground mineral change required to cause Auto- tracking to occur. At slower speeds (lower num- Tips - It is desirable to bers) it takes a signifi... -
Page 34: Trac Offset
Chapter 5 DFX Pro Options ™ (G.E.B./Trac section) 9. Trac Offset Allows AUTOTRAC to track ground minerals ® either positive or negative in relationship to the correct setting (under, or over kill). TRAC OFFSET allows the AUTOTRAC feature ® to track the ground slightly more or less than what... -
Page 35: Coarse G.e.b
Chapter 5 DFX Pro Options ™ (G.E.B./Trac section) 11. Coarse G.E.B. (Manual Ground Balance) allows viewing the cur- rent automatic Ground Balance setting (Air/Ground Balance) and/or manual overriding of the automatic Ground Balance. COARSE & FINE G.E.B. (Ground Exclusion Tips - Use for controlled Balance, or ground rejection) allows manual over- reactions to specifi... -
Page 36: Fine G.e.b
Chapter 5 DFX Pro Options ™ (G.E.B./Trac section) 12. Fine G.E.B. FINE G.E.B. is used to make smaller adjustments to the Ground Balance range on either side of the COARSE setting. The FINE setting combines with the COARSE setting to determine the actual ground rejection level. -
Page 37: Discrimination
Chapter 5 DFX Pro Options ™ (Discrimination section) 13. Disc. Edit Allows for changing which targets V.D.I. or refer- ence numbers are ACCEPTed (detected), or RE- detected), or RE- detected JECTed, (discriminated out) within the current Program you are using. - Page 38 Chapter 5 DFX Pro Options ™ types of targets it cannot readily identify. There- need to accept and dig. fore, if positive +95 is ACCEPTed, questionable targets may be dug that indicate this number and The detector sees metals electronically; thus some can produce some interesting recoveries.
-
Page 39: Block Edit
Chapter 5 DFX Pro Options ™ (Discrimination section) 14. BLOCK Edit Speeds major EDIT changes by dragging ACCEPT or REJECT with ARROW controls. Allows major EDIT changes to be completed quickly. EDIT is for individual V.D.I. number changes and/or viewing of the current settings. -
Page 40: Learn Accept/Reject
Chapter 5 DFX Pro Options ™ (Discrimination section) 15-16. Learn Accept/Reject Specifi c target samples can be used to show or teach the discriminator what metal targets you desire to ACCEPT or REJECT. Select LEARN ACCEPT or LEARN REJECT with the ARROW controls and press ENTER to turn LEARN ON. -
Page 41: Recovery Speed
Chapter 5 DFX Pro Options ™ (Discrimination section) 17. Recovery Speed Speeds target responses, so several targets that are close together can each respond. When a metal is detected, it takes a fraction of a second for the detector to process the signal before it can respond to another metal target nearby. -
Page 42: Bottlecap Reject
Chapter 5 DFX Pro Options ™ (Discrimination section) 18. Bottlecap Reject Adjusts how strongly the instrument rejects or breaks up on iron. Most starting programs use the minimum setting. As larger numbers are selected, more bias rejection against iron occurs. -
Page 43: Hot Rock Reject
Chapter 5 DFX Pro Options ™ (Discrimination section) 19. Hot Rock Reject Hot rocks (rocks higher or different in mineraliza- tion than the surrounding ground) respond as +95 on the V.D.I. scale. Unfortunately in some ground conditions very deep, small, or unusual real metal targets may also indicate +95. -
Page 44: Sweep Speed
Another area well suited to faster loop sweep The SWEEP SPEED of the DFX is adjustable in all speeds are large areas that settings except a GROUND FILTER setting of 2. have few metal items near A GROUND FILTER setting of 2 has a fi... -
Page 45: Ground Filtering
(High Pass Filters or Differentiators) GROUND FILTERING is adjustable with the DFX. The fi rst two primary fi lters are contained within the hardware (electrical parts). The remain- Tips - Metal detectors are ing fi lters are contained within the computer soft- often described or cat- ware allowing full user adjustment. -
Page 46: Display
Chapter 5 DFX Pro Options ™ (Display section) 22. Visual Disc. When ON, REJECTed V.D.I. numbers and their REJECTed V.D.I. numbers and their REJECT associated ICONS are prevented from appearing on the display. When OFF, all V.D.I. numbers and associated ICONS appear. -
Page 47: Sensitivity
Chapter 5 DFX Pro Options ™ (Display section) 24. V.D.I. Sensitivity Controls how strong a target must respond to pro- duce a display indication, and controls a third digit (fraction) of the V.D.I. number. V.D.I. Sensitivity controls the intensity (strength) of the target signal needed to activate the display Tips - Lower V.D.I. -
Page 48: Phase
Chapter 5 DFX ™ Pro Options (Display section) 25. D.C. Phase Measurement of the ground mineralization, or measuring the phase (V.D.I. reference number) of a specifi c metal target during pinpointing. When D.C. PHASE is ON, and the TRIGGER squeezed and released, normal searching begins. -
Page 49: Accumulate
Chapter 5 DFX Pro Options ™ (Display section) 26. Accumulate ON combines SignaGraph information over mul- ® tiple loop passes, OFF shows SignaGraph informa- ® tion only from the last sweep of the loop. Accumulate allows the SignaGraph to continually ®... -
Page 50: Fade
Chapter 5 DFX Pro Options ™ (Display section) 28. Fade Clears or fades noncurrent SignaGraph informa- ® tion (bars). FADE allows past information to automatically clear or fade from the SignaGraph . Without Fade, ® or with too slow of a FADE rate, the SignaGraph ®... -
Page 51: Preamp Gain
Chapter 5 DFX ™ Pro Options (Preamp Gain section) 29. Preamp Gain Selects the intensity of the signal received from the loop. PREAMP GAIN (called Signal Balance on some models) is used to promote stability and perfor- mance. Like a sensitivity control, too much PRE-... -
Page 52: Multi Frequency Method
Chapter 5 DFX Pro Options ™ Multi Frequency Method Only one of the four available multifrequency methods, BEST DATA, CORRELATE, 1 kHz, (Multi Frequency Method section) and 15 kHz, can be "ON" at any one given 30. 2 Frequency (Best Data) 30. -
Page 53: Normalization
Chapter 5 DFX Pro Options ™ (Multi Frequency Method section) 32. V.D.I. Normalization Normalization OFF chart for 3 kHz expands the high (copper/silver) end of the scale and com- Normalization OFF chart for 3 kHz expands the high (copper/silver) end of the scale and com- presses the low (foil/nickel) end of the scale. -
Page 54: Eeprom Programs
Chapter 5 DFX EEPROM Programs ™ Factory Pre-Loaded Custom EEPROM Programs To use a custom EEPROM Program Simply; Whiteʼs has pre-loaded each of the four custom 1. Turn the detector ON and wait for the EEPROM Program positions for you. These pro- Main Menu. - Page 55 Chapter 5 DFX EEPROM Programs ™ Pre-Loaded EEPROM Programs AC Sensitivity 65 EEPROM DP-SILVER (Deep Silver) 1 Frequency (3 kHz) A good general purpose program where the Re-save any changes if future use majority of the trash is iron and small/ is desired.
-
Page 56: Program Settings Chart
Preset Program Settings JEWELRY COIN & COIN RELIC PROSPECT JEWELRY & BEACH BASIC ADJUSTMENTS: TARGET VOLUME 48 - 63 AUDIO THRESHOLD 0 - 42 TONE (AUDIO FREQ.) 0 - 255 AUDIO DISC. ON/OFF SILENT SEARCH ON/OFF MIXED-MODE ON/OFF A.C. SENSITIVITY 1 - 85 D.C. - Page 57 Custom EEPROM Program Settings EEPROM EEPROM EEPROM EEPROM NOTES DP-SILVER HI-TRASH DEMO HI-PRO BASIC ADJUSTMENTS: TARGET VOLUME 48 - 63 AUDIO THRESHOLD 0 - 42 TONE (AUDIO FREQ.) 0 - 255 AUDIO DISC. ON/OFF SILENT SEARCH ON/OFF MIXED-MODE ON/OFF A.C. SENSITIVITY 1 - 85 D.C.
-
Page 58: Glossary
Glossary Glossary Glossary All-Metal: Any mode or control setting allowing total acceptance of all metal types, iron, aluminum, tin, nickel, gold, brass, lead, copper, silver etc. Audio ID: Circuitry which produces different audio tones (pitch) for different target's conductivity. Black Sand: One of the most extreme components of non-conductive, negative ground minerals. Mag- netic. -
Page 59: Warranty
Owner Info WHITE'S ELECTRONICS INC. LIMITED WARRANTY STATEMENT If within two years (24 months) from the original date of purchase, your White's detector fails due to defects in either material or workmanship, White's will repair or replace at its option, all necessary parts without charge for parts or labor. -
Page 60: Service
White's Service Centers White's Authorized Service Centers Centreville Electronics White's Electronics 10063 Wellington Rd. Electronic Exploration 1011 Pleasant Valley Rd. Manassas, Va. 20110 575 West Harrison Sweet Home, OR 97386 (888) 645-0202 Lombard, IL 60148 (541) 367 6121 (703) 367-7999 (800) 392-3223 Fax (541) 367 6629 (703) 367-0868 FAX...
