Stradis SDM025 User Manual

Mpeg-2 4:2:2 decoder

Table of Contents

Quick Links

SDM025, SDM026, SDM250 and SDM275

MPEG-2 4:2:2 Decoder

User Guide

Table of Contents ........................................................................................................................................1

Patent Notice ...............................................................................................................................................3

General Description.....................................................................................................................................4

Features.......................................................................................................................................................4

Applications .................................................................................................................................................4

Block Diagram .............................................................................................................................................5

Specifications (SDM275) .............................................................................................................................5

Ordering Information....................................................................................................................................6

Hardware Installation...................................................................................................................................7

Onboard Jumpers and Connectors (SDM275)............................................................................................8

Back Panel Connectors ...............................................................................................................................9

Installing the Device Drivers and the MPEG-2 File Player Application .......................................................9

Installing the Device Drivers and the MPEG-2 File Player Application .....................................................10

Using the MPEG-2 File Player Application for Windows...........................................................................12

Control Panel Buttons:...............................................................................................................................12

Menu Commands: .....................................................................................................................................13

Multiple Decoders in a Single Computer ...................................................................................................22

Play List .....................................................................................................................................................23

Sample MPEG Files ..................................................................................................................................23

Software License Agreement ....................................................................................................................24

Table of Contents

Need help?

Do you have a question about the SDM025 and is the answer not in the manual?

Questions and answers

Summary of Contents for Stradis SDM025

Page 1: Table Of Contents
SDM025, SDM026, SDM250 and SDM275 MPEG-2 4:2:2 Decoder User Guide Table of Contents Table of Contents ............................1 Patent Notice ...............................3 General Description.............................4 Features...............................4 Applications ..............................4 Block Diagram .............................5 Specifications (SDM275) ..........................5 Ordering Information............................6 Hardware Installation...........................7 Onboard Jumpers and Connectors (SDM275)....................8 Back Panel Connectors ..........................9...
Page 2 Trademarks: Microsoft, Windows, and Windows NT are registered trademarks of Microsoft Corporation. Pentium is a registered trademark of Intel. Tini Q-G and Switchcraft are registered trademarks of Switchcraft, Inc. Stradis is a registered trademark of Stradis, Inc. Because of technical progress, specifications are subject to change without notice...
Page 3: Patent Notice
Patent Notice Notice: Use of this product is expressly prohibited without a license under the following applicable patents. For more information, contact: Baryn S. Futa Phone: 1-303-331-1880 Manager and C.E.O. Fax: 1-303-331-1879 MPEG LA, LCC e-mail: bfuta@mpegla.com 250 Steele Street, Suite 300 U.R.L.: www.mpegla.com Denver, CO 80206 This is the list of patents covered by the MPEG-2 Patent Portfolio License as of September 30, 1998.
Page 4: General Description
Stradis Decoders can even display the output on a VGA monitor; a special burst transfer mode minimizes bus overhead and produces outstanding video.
Page 5: Block Diagram
Block Diagram Specifications (SDM275) MPEG Streams ISO/IEC 13818 and ISO/IEC 11172 compliant. Parses all streams: MPEG-1 Elementary and System Streams and MPEG-2 Elementary, Packetized Elementary (PES), Transport and Program Streams. MPEG Video Decodes full 4:2:2 profile or MP@ML (4:2:0) up to 50 Mbits per second. MPEG Audio Decodes MPEG-1 layers 1 and 2, two channels, ISO/IEC 11172-3.
Page 6: Ordering Information
PC bracket with 2 BNC connectors for sync-in and digital audio out SAC005 Sync daisy chain cable when using multiple decoders in one chassis Note: Specifications of these cables and accessories are available from Stradis for those customers who wish to make them themselves.
Page 7: Hardware Installation
5. Remove the metal cover from the back of the computer adjacent to the slot to be used. Do not lose the screw. 6. Align the Stradis MPEG-2 Decoder Card with the PCI slot and press it down into the connector. The card must be completely seated into the connector.
Page 8: Onboard Jumpers And Connectors (Sdm275)
Onboard Jumpers and Connectors (SDM275) JP3 75 Ohm Terminator JP5 Sync JP6 Sync J2 CDROM Audio Input J9 Composite Video Output Input Output J3 CDROM Audio Output JP2 Digital Audio Output JP5 and JP6 are used for sync-in or sync pass-through. JP3 can switch a 75-ohm terminator in or out.
Page 9: Back Panel Connectors
Back Panel Connectors Left & right balanced analog audio and AES-3 Outputs, Switchcraft Tiny Q-G® TRA6M, Mates with: Switchcraft TA6FL Tini Q-G® straight female cord plug Unbalanced stereo audio output, 3.5mm (1/8 inch) jack S-Video, Mini-DIN4 connector Composite Video Output, RS-170A, BNC White: Serial Digital Video Output, SMPTE 259M, BNC (SDM275) Black: External Sync input, BNC (SDM250)
Page 10: Installing The Device Drivers And The Mpeg-2 File Player Application
Note: The password is printed on the CD. Follow the instructions on the screen to complete the installation. If you are installing this software release on a system that had a Stradis device driver version 0.95 or earlier installed, the installation program will ask you to manually remove it using Device Manager.
Page 11 Note: The password is printed on the CD. Follow the instructions on the screen to complete the installation. If you are installing this software release on a system that had a Stradis device driver version 0.95 or earlier installed, the installation program will ask you to manually remove it using Device Manager.
Page 12: Using The Mpeg-2 File Player Application For Windows
Using the MPEG-2 File Player Application for Windows The MPEG-2 File Player Application (SMPEGDEC.EXE) is provided for testing and evaluation purposes only. If your Stradis decoder is part of a third-party system, follow the instructions provided by your system provider.
Page 13: Menu Commands
Menu Commands: File Open… Opens the "Open" dialog box. Also can open a Play List. See Play List, page 23. Close Closes the MPEG file that is currently open, but does not exit the application. Open Preferences Opens the "Open Preferences" dialog box. When the "Search For All Streams"...
Page 14 The Pids contained in the file (in the case of a Transport Stream) or the Stream IDs (in the case of a Program or System Stream) will be displayed in the "Select Stream" dialog box. The specific audio and video stream may be selected.
Page 15 Next File When using a Play List, stop playing the current file and immediately skip to the next file on the Play List. Only active when there is a "next file" available. Play [Ctrl-P] Same as the Play button. Begin playing the open MPEG file or the Play List. Loop Same as the Loop button.
Page 16 Keep Aspect Ratio Checking this keeps the computer’s display in 4:3 height to width aspect ratio when manually resizing the window. When unchecked the window can be manually sized into non-standard aspect ratios. Window Size Full Screen [Ctrl-F Scales the video to display full screen on the computer display. Does not affect the video output.
Page 17 View SMPTE Code Displays SMPTE Time Code. A time-code is encoded in each I-frame, typically at the beginning of each GOP. During playback, the time code is extracted from each I-frame. The time code is interpolated between I-frames. View STC Displays the System Time Clock.
Page 18 16:9 When 16:9 is selected, no action is taken regardless of the stream type. Volume Control… Opens the "Volume Control" dialog box. Controls the decoded audio output only. Does not affect CD-ROM "pass-through" audio. The volume and balance settings are written into the Windows registry and are remembered from session to session.
Page 19 Offset Time Code Displays the System Time Clock. GenLock Checking this locks the output video sync to the incoming video sync. Sync Mode (Active only when no file is open.) System Clock Uses the Presentation Time Stamps to synchronize video and audio. The audio decoder compares the audio PTS, when encountered, with the STC, and corrects the audio if the difference between the two is more than five milliseconds.
Page 20 On-Screen Display… Opens the "OSD Properties" dialog box, used to superimpose a Windows bit- map over video. Entering the X & Y coordinates of the upper left corner controls the position of the graphic on the screen. Note that undesirable results may occur if the X &...
Page 21 The stored image can be either a standard Windows® BMP 24 bit RGB color image or a Stradis proprietary YUV format that is 720 x 480 pixels (when NTSC is selected) or 720 x 576 pixels (when PAL is selected).
Page 22: Multiple Decoders In A Single Computer
Display the software revision number and copyright information. Multiple Decoders in a Single Computer To use multiple Stradis MPEG-2 Decoders simultaneously in one computer, multiple instances of the decoder application (Smpegdec.exe) must be run. This can be done by adding the program argument -X where X is the decoder board number (1 through N).
Page 23: Play List
Sample MPEG Files Sample MPEG bitstreams may have been provided on the Stradis MPEG-2 Decoder Installation CD-ROM in the subdirectory “MPEG Files”. Such files were gathered from different sources and were encoded on a variety of encoders with varying quality. If present, these files are provided for research and demonstration purposes only.
Page 24: Software License Agreement
Stradis reserves any rights not expressly granted to Licensee and retains title and full ownership rights under the copyright laws of the United States or any other jurisdiction or under any federal, state, or foreign laws. Stradis is not obligated to provide and Licensee acquires no right of any kind with respect to any source code for the Software.
Page 25 Licensee any bankruptcy, receivership, reorganization, or other like proceeding under any present or future debtor relief law. No portion of the fees paid to Stradis for Software shall be returnable or refundable upon termination of this Agreement, whether such termination is by Licensee or by Stradis.
Page 26 Licensee and Stradis. However, the limitations of liability and disclaimer of warranties in this Agreement shall apply to Stradis with respect to such services except to the extent provided otherwise in a separate written agreement approved by Stradis between Licensee and Stradis.
