OPERATING INSTRUCTIONS
MODEL: GMC-3000 Crimp-n-Test
I
F
G
H
D
E
A. UTP/STP Cable Test Jack
B. Remote
C. Wiring Status Indicators
D. Test Button
E. Jumper Cables
F. RJ-45 (4 pair) Crimp Station
G. RJ-11 (1,2 or 3 pair) crimp station
H. Built-in cutting and stripping blades
I. High leverage design for easier crimping
SAFETY WARNINGS
This instruction manual contains warnings and safety rules which
must be observed by the user to ensure safe operation of the
instrument and retain it in safe condition. Therefore, read through
these operating instructions before using the instrument.
! !
WARNING – Do NoT uSE oN lIvE CIRCuITS
Note: Although the GMC-3000 is equipped with 8 position modular
plug jacks, cables with smaller 6 position and 4 position connectors
may also be tested. The user should be aware that the use of
smaller connectors will reduce the total number of jack insertions
over the life of the product.
TESTING PATCH CABlES
1. Connect the main unit to one end of the cable to be tested.
2. Connect Remote unit to plug at far end of cable.
3. Push the TEST button to perform test.
4. Read LEDs to determine cable wiring status.
TESTING INSTAllED CABlES
1. Using the jumper cable, connect the remote unit to the wall jack
or patch panel port to be tested.
2. Using the second jumper cable, connect the main unit to the
other wall jack or patch panel port to be tested.
3. Push the TEST button to perform test.
4. Read status of LEDs to determine cable wiring status.
TEST RESulTS
PASS Indicators
Shield
Green SHIELD LED indicates the Four green LEDs on pairs 1-2,
Shield on the cable is correctly
and continuously wired through All four pairs are terminated
the modular plug termination.
FAIl INDICAToRS
A flashing LED indicates that this wire pair has a fault. A flashing
LED in the FAIL section will indicate which fault was detected.
Multiple flashing LEDs indicate multiple pairs and/or multiple faults.
Best practice is to correct cable faults until cable is verified as
correct with appropriate green LEDs.
• SHoRT – A short circuit condition exists.
• MISWIRE – Indicates the improper assignment of individual wire
pairs to pins for the wiring schemes tested. Tester checks T568A,
T568B, 10Base-T, and Token Ring configurations.
• REvERSAl – Reverse wiring means the pin for
one wire in a pair is connected to the opposite
pin for the pair in the remote jack.
Tip
Marked tip (actually ring)
Roll
Ring
Marked tip (actually tip)
• SPlIT PAIRS – Split pairs occur
when the tip (positive conductor)
and ring (negative conductor) of
two twisted pairs are interchanged.
GMC-3000_ Manual_09-09.indd 1
Note: The GMC-3000 will check a
fault condition in the above
descending order before detecting
other fault conditions. The detection
and indication of the presence of
a fault is handled on a "one-per-test"
basis. Once a fault is corrected, it
is recommended the cable be
tested again for other faults.
DEBuG MoDE
The DEBUG mode identifies which cable pairs have a wiring fault.
It cycles through pairs displaying a test result for one pair at a
B
time. From the series of LED indications, the failed pair and
fault can be identified. In Debug mode, a short flash on PAIR
LED is the pair under test. A long flash on PAIR LEDs is
C
destination of test.
A
To DEBUG:
1. Press and hold TEST button until all LEDs light, then release.
2. The pair identification LEDs and the FAIL LEDs work together in
series to identify which pair is incorrect.
3. If a series of two green LEDs light for a pair then that pair is
wired correctly.
4. A green pair LED followed by a red LED in the FAIL section
identifies which pair is incorrect and identifies the fault.
5. DEBUG cycles through the pairs twice before automatically
shutting off.
6. Pushing and quickly releasing the TEST button also turns
tester off.
DEBuG Example #1 The Cable Fault is a SHORT on Pair 3-6, the
DEBUG mode LED series will be as follows:
• Pair 1-2 will flash green-green as a good pair
• Pair 3-6 will flash green on the pair LED followed by a red on the
SHORT LED
• Pair 4-5 will flash green-green as a good pair
• Pair 7-8 will flash green-green as a good pair
DEBuG Example #2 Following are some examples of potential
sequences on pair 1-2 and interpretation of various fault conditions
for that pair only:
1st
Short
Flash
1-2
1-2
1-2
1-2
1-2
1-2
1-2
Above examples are for 1-2 pair, similar lights would relate to other
pairs under test (short flash)
BATTERY REPlACEMENT
Standard Wiring
1. Remove screws from back of main handle using a #1 Philips
screwdriver. Carefully open tester.
3-6, 4-5, and 7-8.
2. Remove old batteries.
correctly.
3. Install a new 6 volt A544 1/2AA size battery or 4LR44 Button
cell batteries.
4. Close tester and replace screws. Do not over tighten.
limited lifetime Warranty limited solely to repair or
replacement; no warranty of merchantability or fitness for a
particular purpose. Product is warrantied to be free of defects
in materials and workmanship for the normal life of the product.
In no event shall Sperry Instruments be liable for incidental or
consequential damage.
Reversed
Split
1
Terminal A
Crossover cable
2nd Red Fault
long
LEDs
Fault Condition
Flash
1-2 No Red Light Good Pair
1-2 Reversal Pair Reversed 1-2 2-1
1-2 Short Pin 1 Shorted to Pin 2
1-2,3-6 Short 1 or 2 shorted to 3 or 6
7-8 Miswire Pin 1-Pin 7, Pin 2-Pin 8
Miswire,
7-8 Pin 1-Pin 8, Pin 2-Pin 7
Reversal
Wire from 1-2 twisted
1-2 Split Pair with wire from another
pair, continuity good
1
2
3
Terminal B
1
2
3
4
5
6
7
