- Page 1 MD 80137 Digital DVD Recorder and Player User’s Manual © 2004 Medion®. All rights reserved.
-
Page 2: Important Safety Instructions
ELECTRIC SHOCK, DO NOT REMOVE COVER. NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. This symbol alerts the user that there are important operating and maintenance instructions in the literature regarding this unit. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 3: Important Safety Instructions
FOLLOW INSTRUCTIONS AND HEED ALL WARNINGS on the DVD video recorder and in this manual. Installation 1. The power supply of this DVD recorder is AC100~240V, 50/60Hz, please don’t use incorrect power outlets. If you are unsure of the power supply voltage, please ask your local electricity company. -
Page 4: Operation/Cleaning
11. Emergency If the following occurs, unplug the unit and contact Customer Care immediately: • If liquid or metal drops into the unit. • If an abnormal playback status appears. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 5: Service
When installing an outside antenna system, extreme care should be taken to avoid touching such power lines or circuits because contact with them could be fatal. MD 80137 Digital DVD Recorder and Player User’s Manual This is a class-1 laser product. -
Page 6: Grounding The Antenna System
Put the discs in the original box to prevent bending or other damage to the disc. • Don’t put the discs in areas with high temperature, high humidity or in direct sunlight. • Please read any instructions on the disc label carefully. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 7: Table Of Contents
Display Window ....19 Remote Control ....20 Remote Control Buttons ..21 MD 80137 Digital DVD Recorder and Player User’s Manual contents Basic Playback Functions . - Page 8 Glossary ....51 Warranty ....52 MD 80137 Digital DVD Recorder and Player User’s Manual...
-
Page 9: Thank You
DVD recorder that will bring you convenient, dependable service and enjoyment for years to come. This manual is provided to help you set up your DVD recorder and take advantage of its many features. Keep this manual in a safe place for future reference. Record your serial number here, for use in event of loss or theft. -
Page 10: Compatibility
• Copy protection If you attempt to copy a DVD disc with CSS protection code, the anti-copy protection function of your DVD recorder will be started to prevent illegal copying. • Notice One federal court has held that unauthorized recording of copyrighted TV programs is an infringement of U.S. -
Page 11: Panels And Connections
(Y/CB/CR) or progressive scan (Y/PB/PR) device. 7. AUDIO OUT:analog audio output. 8. DIGITAL:Digital audio signal output connector for use with a Digital Audio Receiver/ Audio DA Converter. MD 80137 Digital DVD Recorder and Player User’s Manual panels and connections Front... -
Page 12: Basic (Composite) Connection
Please unplug all devices from the power outlet before making or changing connections. This chart shows the basic connections necessary for using your DVD recorder with a TV. Other types of connections are shown on the following pages. Before you get started, we recommend that you assess all of the equipment that you would like to connect and review the following pages closely. - Page 13 TV, although it will pass through the broadcast or cable signal provided by that connection. You must make a separate audio and video connection in order to watch DVDs played on your DVD recorder on your TV. MD 80137 Digital DVD Recorder and Player User’s Manual...
-
Page 14: Other Tv Connections
AV cable but NOT the yellow portion. This will play stereo sound through your TV (if your TV is capable of producing stereo sound). You can also follow the instructions on the following pages to connect your DVD recorder to an AV amplifier/receiver to send sound to external speakers. -
Page 15: S-Video
Connect one end of the S-Video cable to the S-Video out connection on the back of the DVD recorder, and connect the other end to the S-Video in jack on your TV. Component Video Connect the component cable (green, blue, and red connectors) to the COMPONENT VIDEO OUT on the rear panel of the DVD recorder and the corresponding component video in connections on your television. -
Page 16: Av Amplifier/Receiver Connection
OPTICAL DIGITAL OUT on the DVD recorder and OPTICAL DIGITAL IN on the AV Amplifier or TV. For a coaxial connection, connect a coaxial digital audio cable to COAXIAL DIGITAL OUT on the DVD recorder and COAXIAL DIGITAL IN on the AV Amplifier or TV. Optical and coaxial digital audio cables sold separately. -
Page 17: Connect To Other Video Inputs
DVD player to the AUDIO/VIDEO INPUT of the DVD recorder. Do not connect your DVD recorder to a VCR and then connect the VCR to the TV. This will produce a very poor signal for your DVD recordings. Your DVD recorder should be connected directly to the TV for best results. -
Page 18: Tips
TV with another antenna cable, you will be able to watch TV without turning on your DVD recorder. 4. Attaching your DVD recorder to a VCR and then attaching the VCR to the TV will produce very poor quality video and recordings. The DVD recorder should be attached directly to the TV. -
Page 19: Control Buttons And Display
8. Start scheduled recording 9. Title in repeat play 10. Repeat 1 or all 11. A-B Repeat 12. Display the disc type: DVD, VCD, MP3 13. Play in progress 14. Pause MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 20: Remote Control
Please make sure the +/- terminals are placed correctly, following the instructions printed in the battery compartment. Point the remote control at the remote receiver on the DVD recorder. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 21: Remote Control Buttons
25. CLEAR Delete the wrong number entered. 26. SETUP Customize DVD Recorder setting in Setup Menu (please refer to page 29) 27. TITLE Enter the title menu on DVD disc. (Please refer to page 27) 28. MENU/PBC Some DVDs have submenus. This button allows access to these submenus. - Page 22 If you find the remote distance is reduced, please change both batteries at the same time. If the DVD recorder won’t be operated for an extended period, remove the batteries from the remote control. Otherwise the remote control may be damaged.
-
Page 23: Basic Playback Functions
Preparation: See pages 11–17 for connection diagrams. Connect the DVD Recorder to the TV, turn on the TV power, and select the proper input on your TV (e.g., “AV”). If connecting to an audio system, please turn the audio system on and make sure that it is connected correctly. -
Page 24: Start Playback
PREV to skip to the next or previous section on a CD. to open the disc tray. Chapter 2 Chapter 1 VCD PBC MENU Song 1 Song 2 Song 3 MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 25: Pause/Step
STOP again to stop playback completely. Playing STOP If you are finished using the DVD recorder, take out the disc and press turn the unit off. MD 80137 Digital DVD Recorder and Player User’s Manual basic playback functions... -
Page 26: Disc Playback Osd (On Screen Display)
- this depends on the design of the disc. Angle: This allows you to select the camera angle. Angles available depend on the disc. Not all discs have multiple angles. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 27: Vcd/Audio Cd Playback Osd
3. Press DISPLAY again to exit the OSD display. PBC On/Off: Some VCDs have complex PBC menus. This menu allows you to turn the PBC functionality on or off. Your DVD recorder is easiest to control with the PBC function set to “Off”. -
Page 28: Advanced Playback Functions
4. Press A-B again to set the end point.and the playback between your defined points begins. 5. Press the A-B button a third time to resume normal playback. No OSD is shown. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 29: Program Playlists
1. Move cursor to “Play List” icon and press ENTER key to switch to play list mode 2. Under play list mode, move cursor to “Del All” icon and press ENTER key to delete current play list. MD 80137 Digital DVD Recorder and Player User’s Manual key, a file list menu will appear:... -
Page 30: Mp3 And Cd Playback
Some subtitle languages can be only be selected from the DVD menu and can not be changed with the SUB-TITLE button. Subtitle availability depends on the design of the DVD. key, a file list menu will appear. keys, press PLAY MD 80137 Digital DVD Recorder and Player User’s Manual key to play... -
Page 31: Change Audio Language
> x4 > x8 > normal. 3. An inset screen in the upper left corner shows the entire viewable area. 2. While zoomed, use the viewable area. MD 80137 Digital DVD Recorder and Player User’s Manual and NEXT to change pages in the menu. -
Page 32: Bookmark Memory
PAL is the color format for Europe and other areas. If you select PAL, North American movies and television programs will appear incorrectly on your screen. Please see the glossary on page 51 for more information. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 33: General Setup
2. Set Time determines the system time. The correct time can be entered manually or automatically. 3. Factory Reset will restore the DVD recorder setting to the original factory setting. MD 80137 Digital DVD Recorder and Player User’s Manual general setup to enter into the first buttons to make a selection. -
Page 34: Video
* PCM: Recorder can output PCM data and play the same audio format as on CDs. Additionally, 2-channel analog audio will output from the amplifier’s audio output jacks. * Bitstream: Recorder outputs raw data of DTS® soundtracks MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 35: Security
3. Country Code – This is a two-letter code which represents the country you are in. This setting affects the rating of this DVD recorder.Please refer to the end of the manual if you do not know your country code. -
Page 36: Record
6. Finalize DVD (DVD+R only) – Make a DVD+R disc compatible with regular DVD video players. Only a DVD+R disc will require this operation. Please note a finalized disc cannot be recorded with new or revised content. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 37: Preparing Discs For Recording
You may not be able to record to a DVD+RW disc that already contains recordings from another DVD recorder or PC. If you are able to add a new recording to a disc from another DVD recorder, your recorder will rewrite the DVD menu. If the disc contains data from a personal computer, this data will be erased by your DVD recorder. -
Page 38: Scheduled Disc Recording
Scheduling a Recording You can schedule up to 8 different programs with your DVD recorder. 1. Make sure that the correct time and date are set on your DVD recorder. 2. Place an initialized DVD+R or DVD+RW disc in the DVD recorder. -
Page 39: Stop An In-Process Scheduled Recording
3. Press CLEAR on your remote control. 4. Confirm that you would like to cancel this recording by using the select the green arrow to perform the operation or the red X to cancel. MD 80137 Digital DVD Recorder and Player User’s Manual scheduled disc recording to stop recording and go to DVD mode, or 60 min. -
Page 40: Troubleshooting Scheduled Recordings
9. There is no signal from the selected input source (it may be connected incorrectly or turned off). The DVD recorder will not be able to tell if a disc is damaged. Even if the recording seems to be working, you may not be able to play back the disc if it has been scratched, smeared, or otherwise damaged. -
Page 41: Manual Disc Recording
4. Press SOURCE to select the input source that you want to record. Press SOURCE multiple times to cycle through the options: CVBS1 > CVBS2 > S-VIDEO01 > S-Video02 > CHANNEL 5. Press RECORD on the remote control or the front panel of the DVD recorder to start recording. 6. Press STOP to stop recording. -
Page 42: Recording From External Devices
1. Please confirm the external device is properly connected to the DVD recorder. See the connection diagrams beginning on page 11 for more information. 2. Place an initialized DVD+R or DVD+RW disc in the DVD recorder (see p. 37). 3. Press MONITOR on the remote to switch to external input mode. -
Page 43: Editing Discs
, move cursor to “Cancel”, then press ENTER key to abort inputting. “Delete” and “BS” work in different ways, using delete to erase letter(s) from the beginning, and BS (backspace) to erase letters from the tail. MD 80137 Digital DVD Recorder and Player User’s Manual editing discs... -
Page 44: Erase Title (Dvd+Rw Only)
EDIT on remote control to show edit menu, choose “Remove Chapter”, and you can remove current chapter mark of a title. If DVD+R has not been finalized, Insert/Remove Chapter Mark step can be made. MD 80137 Digital DVD Recorder and Player User’s Manual... -
Page 45: Hide Chapter
3. The screen displays the status of the finalization and the remaining time required. The time required for this function depends on the disc type, length of the recorded content and the quantity of the titles. MD 80137 Digital DVD Recorder and Player User’s Manual editing discs... -
Page 46: Troubleshooting
Reload disk - the label side should face (“no disc” is shown upward. on screen). Dirty disc. Clean disc surface. Deformed disc. Replace disc. Condensation in Turn power on for 1-2 hours before unit. using the unit. MD 80137 Digital DVD Recorder and Player User’s Manual... - Page 47 DVD+R or DVD+RW discs. Other DVD player can not calibrate because disc has too little data. MD 80137 Digital DVD Recorder and Player User’s Manual troubleshooting Solution Replace disc. Playback with DVD format. Press PLAY to resume normal playback.
- Page 48 VCR. Some discs may have None. sections which prohibit skip or scan operations by users. Disc has not been See page 45 for instructions on making made compatible. a disc compatible. MD 80137 Digital DVD Recorder and Player User’s Manual...
- Page 49 Video appears on DVD recorder is in screen, but flickers, PAL mode. fades or is distorted MD 80137 Digital DVD Recorder and Player User’s Manual troubleshooting Solution Prepare and load a recordable disc. None. Replace with a disc that is the correct format (see page 37).
-
Page 50: Additional Information
Information recorded on a DVD disc. If the region number described on the DVD disc does not correspond to the region number of this DVD recorder, this DVD recorder will not play the disc. The OSD message “WRONG REGION” will show on the TV screen. This recorder will play DVD discs made for “ALL”... -
Page 51: Glossary
MPEG: MPEG is a type of compression for video. There are different types of MPEG. MD 80137 Digital DVD Recorder and Player User’s Manual additional information MPEG 1 is generally used for VCDs. MPEG 2 is used for DVDs and digital TV, and is higher quality than MPEG 1. -
Page 52: Warranty
STATEMENT ARE YOUR SOLE AND EXCLUSIVE REMEDIES. EXCEPT AS INDICATED ABOVE, IN NO EVENT WILL MEDION OR ITS SUPPLIERS BE LIABLE FOR LOSS OF DATA OR FOR INDIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL (INCLUDING LOST PROFIT OR DATA), OR OTHER DAMAGE, WHETHER BASED IN CONTRACT, TORT, OR OTHERWISE. - Page 53 APPLICABLE TO THE SALE OF THIS PRODUCT TO YOU. Please note the following: Be sure to keep your purchase receipt in a safe place. MEDION, at its option, may require a copy of the receipt to validate the warranty period effective date (i.e. date of purchase).
