Specifications:

Size: 3.25" x 2.50" x 1.40" (8.26 cm x 6.35 cm x 3.56 cm)
Weight: 3.5 ounce (99.2 gram) (less battery)
Operational Range:
Range Accuracy: +/- 1 yard/meter (+/- 2 yards/meters for very dark or very bright targets)
Range Resolution: 0.5 yard/meter
Readout: Easy to see, adjustable, internal red LED display
Units of Measure: User selectable in either yards, or meters with or without VAC™
Viewfinder: Monocular viewing port with red LED aiming sight,
+/- 0.1 degrees (1.5 mrad); Multi-Coated Lenses
Battery: Single CR-2 Lithium Battery. Operates for approximately 1000 individual readings
Operational Temp: -18° to 40°C, 0°-104°F
Relative Humidity: 5-95% non-condensing
Laser Type: Infrared Class 1, eye safe 905nm Laser.
Micro™ I = 4-100 yards (91.5 meters)
(Up to 600 yards for highly reflective targets)
Micro™ II = 4-400 yards (366 meters)
(Up to 800 yards for highly reflective targets)
