Page 1 Check The Package User Manual WooW! Freedom Wi-Fi 1080p Action Camera WF1030-01 WF1030-01 | Wi-Fi 1080p Action Camera...
Page 2: Table Of Contents
Table of Contents Check The package……………………………………  2 Know the camera ………………………………….… 4 Wi-Fi Mode …………………………………………….. Shooting Video & Photo ………………………… 12 Viewing Recorded Videos and Photos …….. 16 Other Information …………………………………… 20 WF1030-01 | Wi-Fi 1080p Action Camera...
Page 3: Check The Package
 Thanks for purchasing WooW! Action camera! You are about to capture your stunning moments  WooW! Action camera  Waterproof case  Handlebar mount  Vented helmet strap mount  USB charging cable WF1030-01 | Wi-Fi 1080p Action Camera...
Page 4 • When charging, the LED will light up in Blue   Push up the battery cover lever LED in Blue when Charging Slide the battery cover to right * Make sure camera is turned off before opening battery cover WF1030-01 | Wi-Fi 1080p Action Camera...
Page 5: Know The Camera
Front Right View Shutter  Microphone LCD Display Power / Mode Select Press & hold to turn on/off Click to select mode Battery Cover Lever Infrared signal receiver Wi-Fi On/OFF Wide Angle Lens Indicator WF1030-01 | Wi-Fi 1080p Action Camera...
Page 6 Know The Camera Front Left View LCD Display Microphone  Shutter Wide Angle Lens Micro USB port (Charging & Connect to PC) Mini HDMI Output SD Memory Card Slot (Up to 32GB) 2.5mm Microphone Jack WF1030-01 | Wi-Fi 1080p Action Camera...
Page 7: Lcd Display
In camera mode, it displays the remained number of photos could be taken In video recording mode, it displays the remained recording time (H:MM). During recoding, it displays the recorded time of the video clip WF1030-01 | Wi-Fi 1080p Action Camera...
Page 8 Video Recording Mode, Full HD 1080p at 30fps Video Recording Mode, HD 720p at 30fps HILO Video Recording Mode, HD 720p at 60fps Camera Mode, 5M pixels Camera Mode, 8M pixels FPS means frame per second WF1030-01 | Wi-Fi 1080p Action Camera...
Page 9: Wi-Fi Mode
Wi-Fi Mode allows the camera to connect with user’s iPhone / iPad / Android devices • Click the button to activate camera Wi-Fi Mode • Icon will be shown on LCD • See Wi-Fi section of the user manual for setup details WF1030-01 | Wi-Fi 1080p Action Camera...
Page 10 Advanced camera setup (continuous shooting, time-lapse mode, white balance, format memory card) • View and download videos & photos from camera * Supported Wi-Fi Devices: • iPhones • iPads • Android Phones • Android Tablets WF1030-01 | Wi-Fi 1080p Action Camera...
Page 11 • The Button will flash when waiting to connect, and stay on when connected with devices • icon will be shown on LCD • On device Wi-Fi Network setting, choose “WOOW-F1030” SSID • Enter password 1234567890 and connect • After connected, open SYMAGIC app WF1030-01 | Wi-Fi 1080p Action Camera...
Page 12 Wi-Fi Mode SYMAGIX App Setting Menu Battery Level Resolution White Balance Setting Remained Recording Time Live viewfinder Playback Mode Shutter Photo / Video Mode WF1030-01 | Wi-Fi 1080p Action Camera...
Page 13 Shooting Video & Photo Insert SD Memory Card • Turn off the camera before inserting memory card • Use Micro-SD or Micro-SDHC card (at least Class 4) • For best results Class 10 memory card is recommended WF1030-01 | Wi-Fi 1080p Action Camera...
Page 14 ¼” tripod hole • You can check our website for more mounting gears www.woowcam.com The camera is waterproof ONLY when securely enclosed in waterproof case WF1030-01 | Wi-Fi 1080p Action Camera...
Page 15 Video Recording Mode, Full HD 1080p at 30fps Video Recording Mode, HD 720p at 30fps HILO Video Recording Mode, HD 720p at 60fps Camera Mode, 5M pixels Camera Mode, 8M pixels FPS means frame per second WF1030-01 | Wi-Fi 1080p Action Camera...
Page 16: Shooting Video & Photo
• You could turn off the Wi-Fi Mode anytime during recording When Wi-Fi Mode is ON, you can ONLY start recording with Wi-Fi device. However, you can stop recording by clicking shutter button on camera WF1030-01 | Wi-Fi 1080p Action Camera...
Page 17 • Click the Wi-Fi button on camera • Open SYMAGIX apps on your Wi-Fi Device (refer to Wi-Fi Section for setup details) • Click icon on the lower left corner to download and view recorded videos and photos  WF1030-01 | Wi-Fi 1080p Action Camera...
Page 18: Viewing Recorded Videos And Photos
Second drive stores camera system info (including SSID_PW.CFG which containing AP ID and password)  Wide Angle PC Webcam • While in “PCU” mode, You could change to “PCC” mode (PC Camera) by click the Shutter button WF1030-01 | Wi-Fi 1080p Action Camera...
Page 19 Playback Mode Icon File number/Total files Video file icon  • Click ON/OFF button to switch between videos and photos • Click Wi-Fi button to select the file • Click Shutter button to play/stop the file WF1030-01 | Wi-Fi 1080p Action Camera...
Page 20 Enter wifi Format Select Enter wifi Delete Select  • Click ON/OFF button to switch between options • Click Wi-Fi button to select between delete and format • Click Shutter button confirm and exit WF1030-01 | Wi-Fi 1080p Action Camera...
Page 21: Other Information
External Mic Input 2.5mm Audio Jack  Supported Wi-fi Devices iOS, Android App Approx. 160 Mins Video On 32GB Approx. Recording Time Memory At 1080p 30fps Max 66 Ft With Waterproof Case Waterproof Depth WF1030-01 | Wi-Fi 1080p Action Camera...
Page 22 Video Recording Mode, HD 720p at 30fps Best for activities that would need long recording time HILO Video Recording Mode, HD 720p at 60fps  Best for fast speed sport, e.g. racing, with best details WF1030-01 | Wi-Fi 1080p Action Camera...
Page 23 You could decide the video FPS setting by referencing to below table which shows the distance (feet) between 2 frames in various speed and FPS settings Speed (miles/hr) Video FPS Setting Distance (ft) between 2 frames  WF1030-01 | Wi-Fi 1080p Action Camera...
Page 24: Troubleshooting
Can’t Open SYMAGIX app iOS devices: Double click Home button and swipe SYMAGIX upward. Click home button once, open SYMAGIX again Android devices: open Task Manager and click “End All”. Click home button, open SYMAGIX again WF1030-01 | Wi-Fi 1080p Action Camera...
Page 25 • If “PCU” is still not shown on camera, unplug USB cable from  PC and repeat above steps with other USB port • Connect the camera with your Wi-Fi device will update the The video/picture time camera date time automatically stamp is not current WF1030-01 | Wi-Fi 1080p Action Camera...
Page 26 HDMI cable  HDMI cable? You can use any video editing software which supporting MP4 How can I edit my videos? or H.264 format, such as MS Movie Maker and Apple iMove WF1030-01 | Wi-Fi 1080p Action Camera...
Page 27 Other Information Visit us at www.woowcam.com • For more FAQ and troubleshooting information • For Warranty Statement Details • For Product Support & Customer Services  • For More Mounting Gears & Accessories WF1030-01 | Wi-Fi 1080p Action Camera...
Page 28 Check The Package Get 20% OFF All Mountings & Accessories Products Coupon Code: ilove1030 www.woowcam.com WF1030-01 | Wi-Fi 1080p Action Camera...
