RFID READER
RFID-IDR-232N
USER'S MANUAL
V1.2
September 2010
Information contained in this publication regarding device applications and the like is intended through suggestion only and may
be superseded by updates. It is your responsibility to ensure that your application meets with your specifications. No
representation or warranty is given and no liability is assumed by Cytron Technologies Incorporated with respect to the accuracy
or use of such information, or infringement of patents or other intellectual property rights arising from such use or otherwise. Use
of Cytron Technologies's products as critical components in life support systems is not authorized except with express written
approval by Cytron Technologies. No licenses are conveyed, implicitly or otherwise, under any intellectual property rights.
Advertisement
Summary of Contents for Cytron RFID-IDR-232N
- Page 1 It is your responsibility to ensure that your application meets with your specifications. No representation or warranty is given and no liability is assumed by Cytron Technologies Incorporated with respect to the accuracy or use of such information, or infringement of patents or other intellectual property rights arising from such use or otherwise. Use of Cytron Technologies’s products as critical components in life support systems is not authorized except with express written...
-
Page 2: Table Of Contents
ROBOT . HEAD to TOE Product User’s Manual – RFID-IDR-232N Index 1. Introduction and Overview 2. Packing List 3. Power Supply 4. Using RFID-IDR-232N 5. Pin Configuration 6. RFID-IDR-232N Protocol 7. Warranty Created by Cytron Technologies Sdn. Bhd. – All Right Reserved... -
Page 3: Introduction And Overview
ROBOT . HEAD to TOE Product User’s Manual – RFID-IDR-232N 1. INTRODUCTION AND OVERVIEW RFID-IDR-232N is plug and use RFID reader. It has been designed with capabilities and features • Low cost solution for reading passive RFID transponder tags. •... -
Page 4: Packing List
Please check the parts and components according to the packing list. If there are any parts missing, please contact us at sales@cytron.com.my immediately. 1. 1 x RFID-IDR-232N with: • Female RS232 cable with USB and RJ11 Created by Cytron Technologies Sdn. Bhd. – All Right Reserved... -
Page 5: Power Supply
RS232 cable (serial port with female DB9) • Connect the USB to the USB port of PC or laptop. After providing power to RFID-IDR-232N, the LED will light ON with the RED color and buzzer will beep. Created by Cytron Technologies Sdn. Bhd. – All Right Reserved... -
Page 6: Using Rfid-Idr-232N
Product User’s Manual – RFID-IDR-232N 4. USING RFID-IDR-232N The hardware connection must be setup before RFID-IDR-232N can be used. Connect RJ11 cable connector into RFID Reader as shown in figure. The communication line has to be connected to serial port of PC. - Page 7 Stop bits = 1 v) Flow control = None Now, RFID-IDR-232N is ready to read address of a 125 KHz passive tag. Move the tag slowly towards RFID-IDR-232N (top), at approximately 2cm from the casing, the buzzer will sound, LED will turn to green when the tag move slowly towards RFID-IDR- 232N and HyperTerminal will show the tag’s ID in ASCII.
- Page 8 Figure above show the protocol of the RFID Reader. The extra byte of data at the first and the last of tag ID’s. If the protocol users have is different from the protocol above, please contact us at sales@cytron.com.my immediately. Created by Cytron Technologies Sdn. Bhd. – All Right Reserved...
-
Page 9: Pin Configuration
Product User’s Manual – RFID-IDR-232N 5. PIN CONFIGURATION If RFID-IDR-232N is require on embedded system where no PC is available, hardware modification and interface is necessary. USB will provide 5V and ground to RFID-IDR-232N, while female DB9 is communication line to PC. Below show the pin configuration of USB, RJ11 and DB9 of RFID-IDR-232. - Page 10 ROBOT . HEAD to TOE Product User’s Manual – RFID-IDR-232N PIN No Function RJ11 female socket Configuration RJ11 male pin Configuration Created by Cytron Technologies Sdn. Bhd. – All Right Reserved...
-
Page 11: Rfid-Idr-232N Protocol
(depending on microcontroller type) can be used to write program. RFID-IDR-232N will read the ID from RFID tag if the tag is near enough to RFID Reader. The ID is normally 10 digit of number. RFID-IDR-232N will automatically send this ID with 1 byte of Start of heading (0x01), followed by 10 byte of ASCII character (ID) and 1 byte of Start of text (0x02). -
Page 12: Warranty
Warranty does not cover freight cost for both ways. Prepared by Cytron Technologies Sdn. Bhd. 19, Jalan Kebudayaan 1A, Taman Universiti, 81300 Skudai, Johor, Malaysia. Tel: +607-521 3178 Fax: +607-521 1861 URL: www.cytron.com.my Email: support@cytron.com.my sales@cytron.com.my Created by Cytron Technologies Sdn. Bhd. – All Right Reserved...
