Summary of Contents for Classic Organ Works WMJ-003

Page 1 ................................13 IRMWARE PDATING APPENDIX A: DIP SWITCH CONFIGURATION TABLE ....................APPENDIX B: BI-DIRECTIONAL CABLE SCHEMATIC ....................Copyright © 2012 Classic Organ Works 2800 John Street, Unit 4 Markham, Ontario, Canada L3R 0E2 Tel.: (905) 475-1275 Fax.: (905) 475-2735 E-mail: support@midijet.com...
Page 2: Limited Warranty
In the event that Classic Organ Works determines the product requires repair because of user misuse or regular wear, it will assess a fair repair or replacement fee. The customer will have the option to pay this fee and have the unit repaired and returned, or not pay this fee and have the unit returned un-repaired.
Page 3 INTRODUCTION Welcome Thank you for purchasing the MIDIjet Pro USB Wireless MIDI System. We have designed this product with high-grade components to ensure a solid, wireless connection that will take you to a new level of performance. We invite you to visit www.midijet.com or to call us at 905-475-1263 (9:30am to 5:30pm E.S.T) with questions or comments regarding your MIDIjet Pro USB system.
Page 4: Features At A Glance
Features at a Glance Up to 500-foot range • Bi-directional MIDI traffic - new! • Detachable antennas - new! • Can use rechargable batteries - new! • Powered by either DC power supply, 2 ‘AA’ batteries or USB bus - new! •...
Page 5 Switches, Plugs and Connectors Transmitter Receiver 1) Power Selector Switch - When in the “Batt” position, the unit is powered by batteries only. When in “Adapt/ Off & USB” position, the unit is powered by the USB port or via the power adapter input. If there is no power coming from either the USB port or the adapter input, then the unit will be turned off.
Page 6 11) Battery Holder - MIDIjet Pro uses 2 x AA batteries. These batteries can be either disposable or rechargable. Regular 1.5V alkaline batteries will last more than 20 hours in the transmitter. They will not last as long in the receiver. The performance of rechargable batteries varies widely with the voltage and the capacity of the battery.
Page 7: Basic Setup And Operation
Basic Setup and Operation Transmitter and Receiver Even though these units are bi-directional, practically speaking, the black unit is the transmitter and the grey/white unit is the receiver and allows you to use regular MIDI cables. You should be able to take them out of the box, put in some AA batteries and use them, as in the example above, straight out of the box.
Page 8 Bi-directional transmission allows MIDI traffic to flow on all 16 MIDI channels in both directions Example 1 - USB to USB Example 2 - USB to MIDI I/O DAW or MIDI Control Software DAW or MIDI Control Software I/O via USB Port I/O via USB Port Bi-Directional MIDI Tra c links or syncs 16 channels each direction...
Page 9: Usb Connectivity
USB Connectivity MIDIjet Pro is plug and play on USB ports for both Windows 7+ and OS X. It will appear as “Wireless USB MIDI Transceiver” in your OS X Audio MIDI Setup utility. On Windows-based machines, the MIDIjet Pro will appear in the Sound, video and game controllers” list in the Device Manager or in your It will also appear as “Wireless USB MIDI Transceiver”...
Page 10: Best Practices For Wireless Communication
Connecting to iOS Devices It is not possible to connect a MIDIjet Pro directly to an iOS device. However, it can be connected to your iOS device through an iConnectMIDI (or equivalent) device (www.iconnectmidi.com) for MIDI in and out via the USB port or by the MIDI jack in the MIDIjet Pros.
Page 11: Tips And Tricks
Tips and Tricks The receiver sends an “All Notes Off” MIDI message if contact is lost with the transmitter. Hence it is possible to • turn off hanging (or “stuck on”) notes by turning off the transmitter. Extended Setup Extended Setup is not required for MIDIjet adapters, as they are designed to work as-is out of the box. However, in extreme situations where there is radio interference from other devices, or where there are many MIDIjet units operating in the same environment, the following instructions describe how to assign channels and bind adapter pairs together.
Page 12: Troubleshooting Checklist
Binding MIDIjet Pro Sets Every MIDIjet Pro wireless adapter contains a unique identifier. A transmitter and receiver are “bound” together when they acquire their counterpart’s unique identifier. The process of acquiring this information is called “binding”. Each pair is bound together at the factory, however, if you happen to have mismatched pairs, it is possible to bind them together. It is also possible to bind multiple transmitters to a single receiver.
Page 13: Firmware Updating
If that does not solve the problem, ensure the devices are set to the same channel. See extended setup for further details. If the units are set to the same channel and are not connecting, it is possible that the units are not •...
Page 14 Windows 1) Start the loader software 2) Make sure the dip switches are all in the down position 3) Connect the MIDIjet Pro to the computer via USB cable. 4) Only the connect light should be flashing yellow rapidly 5) Click the “Refresh Firmware” button when the software finds the MIDIjet Pro automatically 6) Wait for the “Erase/Program/Verify Completed Successfully”...
Page 15: Appendix A: Dip Switch Configuration Table
APPENDIX A: DIP SWITCH CONFIGURATION TABLE Configuration DIP switch settings and their corresponding function. Setting DIP Switch Notes Number Positions “No Binding” mode and “Firmware Update” mode Channel 1 Channel 2 Channel 3 Channel 4 Channel 5 Channel 6 Channel 7 Channel 8 Channel 9 Channel 10...
Page 16 Configuration DIP switch settings and their corresponding function (continued). Setting DIP Switch Notes Number Positions Channel 16 - USB Interface Mode (no wireless) Channel 17 Channel 18 Channel 19 Channel 20 Channel 21 Channel 22 Channel 23 Channel 24 Channel 25 Channel 26 Channel 27 Channel 28...
Page 17: Appendix B: Bi-Directional Cable Schematic
Appendix B: Bi-Directional Cable Schematic The important thing to remember when making these cables is that standard MIDI cables only use pins 4 and 5 for MIDI traffic. To make the MIDIjet Pros able to function with regular cables, pins 4 and 5 on the transmitter (black) unit, are MIDI In and on the receiver (grey/white) unit, pins 4 and 5 are MIDI out.
