- Page 1 8000 Series User Manual Flexible Linear Lighting System The versatile indoor and outdoor water resistant lighting solution.
- Page 2 C8K-18-CW / C8K-18-WW : 120 V, 0.5 A ; Output : 24V, 0.75A C8K-30-CW / C8K-30-WW : 120 V, 0.5 A ; Output : 24V, 1.25A C8K-60-CW / C8K-60-WW : 120V, 1.0 A ; Output : 24V, 2.5A GROUNDING INSTRUCTIONS •...
- Page 3 Do not coil the strip into a tight circle with a diameter less than 8 inches (20cm) or bend it in half as it may damage the LEDs embedded in the strip. • Do not subject the flexible CabLED strip to continuous flexing. cabled.optiled.com...
- Page 4 SAVE THESE INSTRUCTIONS CabLED is a registered trademark. All the information in this document is Copyrighted © 2011, OPTILED Lighting International Limited, All rights reserved. cabled.optiled.com...
-
Page 5: Table Of Contents
6.2 Use One of the Following Five Methods to Mount CabLED™ ....32-36 Step 7: Mount Power Supply Step 8: Connect to Power Troubleshooting cabled.optiled.com... -
Page 6: Introduction
After identifying the correct region, determine the length of CabLED strip needed to select the correct power supply for each installation. If you are unsure of the correct voltage, contact a qualified electrician. A choice of five mounting solutions are available. Mounting cabled.optiled.com... -
Page 7: Possible Applications
Cable on the other. A longer Jumper Cable is hidden in the cabinet above the stove. The following chart lists the components used for this scenario. Components End Cap Jumper Cable (There are two lengths used here) PS-Link Connector Power Supply U-Connector cabled.optiled.com... -
Page 8: Patios
This scenario turns your patio into the perfect entertainment area. The power supply is mounted well above the ground so it cannot be submerged in water. The following chart lists the components used for this scenario. Components End Cap L-Connector PS-Link Connector Power Supply T-Connector X-Connector cabled.optiled.com... -
Page 9: Indoor Staris
Inline Dimmer to adjust the light level to keep your stairway softly lit. The Jumper Cables are hidden behind the steps. The following chart lists the components used for this scenario. Components End Cap Jumper Cable Inline Dimmer PS-Link Connector Power Supply cabled.optiled.com... -
Page 10: Outdoor Stairs
Outdoor Stairs In this scenario, the power supply is mounted well above the ground so it cannot be submerged in water. The following chart lists the components used for this scenario. Components End Cap Jumper Cable PS-Link Connector Power Supply cabled.optiled.com... -
Page 11: Walkways
The power supply is mounted well above the ground so it cannot be submerged in water. The following chart lists the components used for this scenario. Components End Cap Jumper Cable PS-Link Connector Power Supply cabled.optiled.com... -
Page 12: Design Guidelines
Mounting Use one of the five mounting solutions. Tips Use the Trouble Shooting section when you have problems or contact our Customer Service Department. Tools Needed Pencil Scissors Screw Drivers Note Pad Power Drill Tape Measure Safety Goggles Pliers cabled.optiled.com... -
Page 13: Cabled™ Component Layout
Overview for additional information. Optional Accessories Inline ON/OFF Power Dimmer Switch Supply AC Outlet C onnectors End C ap I-C onnector J umper C able L-C onnector PS-Link C onnect 4 Way P y ower Splitter T-C onnector U-C onnector X-C onnector cabled.optiled.com... -
Page 14: Cabled™ Component Overview
14.7 feet (4.5m) 30 Watt 24V Power Supply Provides power for CabLED strip 5429103017 measuring up to 24.6 feet (7.5m) 60 Watt 24V Power Supply Provides power for CabLED strip 5430106017 measuring up to 49.2 feet (15m) cabled.optiled.com... -
Page 15: Connectors
Connects CabLED strip to power supply. T-Connector Connects three CabLED strips in a flexible T shape. 6401401705 U-Connector Connects two CabLED strips parallel to each other for twice the brightness or a balance of warm and 6401400305 cool colors. cabled.optiled.com... - Page 16 Connects two CabLED strips with a 40 inch (101cm) flexible cable. 6401402705 IMPORTANT: The connectors consist of two parts, a top and bottom, which are partially assembled at the factory. DO NOT push the connectors together before you are ready to install. cabled.optiled.com...
-
Page 17: Mounting Options
Garden Stake Use for outdoor ground installations. Holds the CabLED above ground so it will not be submerged 6401403005 in water and adjusts to direct the angle of light from 0 to 135 degrees. May be used with Channeling. cabled.optiled.com... -
Page 18: Diy Systems
System 15 WW This kit includes 49.2 feet (15m) Warm White CabLED strip, a 60W power supply, PS-Link C8K-60-WW Connector, End Cap and 50 Channel Brackets. Accessories Four IP65 rated accessories are available to enhance your system for either indoor or outdoor use. The RF Light/Motion Sensor and RF Remote Dimmer require at least one RF Receiver to function. -
Page 19: Step 1: Plan Installation
Now you should have a few things listed on your note pad. Such as what color you have decided to use, and the accessories you will use. It's time to map out the installation to determine everything else you will need. cabled.optiled.com... -
Page 20: Measure And Mark The Area
30 Watt 24V Power Supply 49.2 feet (15m) 60 Watt 24V Power Supply NOTE: The power supplies are available with different plugs for various regions worldwide. When determining the correct model number for your installation, check the region as well as the strength. cabled.optiled.com... -
Page 21: Mounting Options
When mounting along paths, use the Garden Stake and adjust light at an angle. Use with Channeling for additional support. Angled Up Angled Out Angled Down (45 degrees) (90 degrees) (135 degrees) CabLED CabLED CabLED Mounting Options: Garden Stake with or without Channelling cabled.optiled.com... -
Page 22: Step 3: Begin Installation
LED side of the strip. When you are measuring for your installation, if the total length in inches is not a multiple of 7, then adjust the plan of your layout to use the nearest cut line marked on the strip. cabled.optiled.com... -
Page 23: Step 4: Install Connectors
4.2 Install End Cap The End Cap protects the side of the CabLED strip not attached to a connector. Slide End Cap onto LED strip that will have no connector. The End Cap protects the strip. cabled.optiled.com... -
Page 24: Install I-Connector
Make sure both sides of the bottom half of the connector snap into the top half. Gently pull the CabLED strips to make sure you have installed it properly. cabled.optiled.com... -
Page 25: Install Jumper Cable
Make sure both sides of the bottom half of the connector snap into the top half. Gently pull the CabLED strips to make sure you have installed it properly. cabled.optiled.com... -
Page 26: Install L-Connector
Make sure both sides of the bottom half of the connector snap into the top half. Gently pull the CabLED strips to make sure you have installed them properly. cabled.optiled.com... -
Page 27: Install T-Connector
Make sure both sides of the bottom half of the connector snap into the top half. Gently pull the CabLED strips to make sure you have installed them properly. cabled.optiled.com... -
Page 28: Install U-Connector
Make sure both sides of the bottom half of the connector snap into the top half. Gently pull the CabLED strips to make sure you have installed them properly. cabled.optiled.com... -
Page 29: Install X-Connector
Make sure both sides of the bottom half of the connector snap into the top half. Gently pull the CabLED strips to make sure you have installed them properly. cabled.optiled.com... -
Page 30: Install 4 Way Power Splitter
IMPORTANT: There is only one way to connect the PS-Link Connector to the power supply. Make certain the icons match before connecting. Connect the power supply to the PS-Link Connector BEFORE plugging the power supply into the AC outlet. cabled.optiled.com... -
Page 31: Step 5: Install Accessories 5.1 Install Inline Dimmer
IMPORTANT: Disconnect Inline Dimmer fro mer fro m power supply b ower supply b ower supply efore mounting. Mount near power supply and o the ground so there is no chance of it being submerged in water. cabled.optiled.com... -
Page 32: Step 6: Mount Cabled
Angle Channelling, and then push down to and hold Angle Channeling against surface. snap strip into place. Secure with screw every 12 to 16 inches (31- 41cm). Or apply double sided tape on the bottom of the Angle Channeling. snap slide into into bottom cabled.optiled.com... - Page 33 CabLED is recommended.) Double sided tape Apply double sided tape on the bottom snap slide of the first Angle Channeling. Tape Angle into into Channeling onto the cove surface according to the desired direction of the light. bottom Double sided tape cabled.optiled.com...
- Page 34 Install Edge Bracket Screw Edge Brackets partially into surface. Adjust placement if necessary when Start from PS-Link Connector. Slide CabLED tightening screws. between bracket and surface making sure it lies flat and the bracket doesn't cover the LEDs. cabled.optiled.com...
- Page 35 Position so strip lays flat and LEDs are NOT covered when strip is installed. Reposition stake if necessary. IMPORTANT: Use Garden Stakes where CabLED will be installed on the ground outside. Install so CabLED or connectors will NOT be submerged in water. cabled.optiled.com...
- Page 36 Angle marked on outside stand Adjust Channeling if LEDs are blocked by the stand. IMPORTANT: Use Garden Stakes where CabLED will be installed on the ground outside. Install so CabLED or connectors will NOT be submerged in water. cabled.optiled.com...
-
Page 37: Step 7: Mount Power Supply
Step 8: Connect to Power Matching the icons, connect the PS-Link Connector to the power supply. Plug the power supply into the AC outlet. IMPORTANT: Connect the power supply to the PS-Link Connector BEFORE plugging the power supply into the AC outlet. cabled.optiled.com... -
Page 38: Troubleshooting
Use a flat screw driver to gently widen the sides of the top connector and push the bottom connector apart. NOTE: This may not fix the connector and you will need to use a new connector. • Contact our Customer Service Department to purchase additional connectors. cabled.optiled.com... - Page 39 Email: info@optiled.com Website: www.optiled.com Patented Worldwide...
