The ice maker is not producing ice or not enough ice
Refrigerator connected to a water supply and the supply
I
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
Kink in the water source line? A kink in the line can reduce
I
water flow. Straighten the water source line.
Ice maker turned on? Make sure wire shutoff arm or switch
I
(depending on model) is in the ON position.
New installation? Wait 24 hours after ice maker installation
I
for ice production to begin. Wait 72 hours for full ice
production.
Freezer door closed completely? Firmly close the freezer
I
compartment door. If the freezer compartment door will not
close all the way, see "The doors will not close completely,"
earlier in this section.
Large amount of ice recently removed? Allow 24 hours for
I
ice maker to produce more ice.
Ice cube jammed in the ice maker ejector arm?
I
Remove ice from the ejector arm with a plastic utensil.
Water filter installed on the refrigerator? Remove filter and
I
operate ice maker. If ice volume improves, then the filter may
be clogged or incorrectly installed. Replace filter or reinstall it
correctly.
Reverse osmosis water filtration system connected to
I
your cold water supply? This can decrease water pressure.
See "Water Supply Requirements."
The ice cubes are hollow or small
NOTE: This is an indication of low water pressure.
Water shutoff valve not fully open? Turn the water shutoff
I
valve fully open.
Kink in the water source line? A kink in the line can reduce
I
water flow. Straighten the water source line.
Water filter installed on the refrigerator? Remove filter and
I
operate ice maker. If ice quality improves, then the filter may
be clogged or incorrectly installed. Replace filter or reinstall it
correctly.
Reverse osmosis water filtration system connected to
I
your cold water supply? This can decrease water pressure.
See "Water Supply Requirements."
Questions remain regarding water pressure? Call a
I
licensed, qualified plumber.
Off-taste, odor or gray color in the ice
New plumbing connections? New plumbing connections
I
can cause discolored or off-flavored ice.
Ice stored too long? Discard ice. Wash ice bin. Allow
I
24 hours for ice maker to make new ice.
Odor transfer from food? Use airtight, moisture proof
I
packaging to store food.
Are there minerals (such as sulfur) in the water? A water
I
filter may need to be installed to remove the minerals.
Water filter installed on the refrigerator? Gray or dark
I
discoloration in ice indicates that the water filtration system
needs additional flushing. Flush the water system before using
a new water filter. Replace water filter when indicated. See
"Water Filtration System."

Ice and Water

The water dispenser will not operate properly
Refrigerator connected to a water supply and the supply
I
shutoff valve turned on? Connect refrigerator to water
supply and turn water shutoff valve fully open.
Kink in the water source line? Straighten the water source
I
line.
New installation? Flush and fill the water system. See "Water
I
Dispenser."
Is the water pressure at least 35 psi (241 kPa)? The water
I
pressure to the home determines the flow from the dispenser.
See "Water Supply Requirements."
Water filter installed on the refrigerator? Remove filter and
I
operate dispenser. If water flow increases, the filter may be
clogged or incorrectly installed. Replace filter or reinstall it
correctly.
Refrigerator door closed completely? Close the door firmly.
I
If it does not close completely, see "The doors will not close
completely," earlier in this section.
Recently removed the doors? Make sure the water
I
dispenser wire/tube assembly has been properly reconnected.
See "Refrigerator Door(s) and Drawer."
Reverse osmosis water filtration system connected to
I
your cold water supply? This can decrease water pressure.
See "Water Supply Requirements."
Water is leaking from the dispenser system
NOTE: One or two drops of water after dispensing is normal.
Glass not being held under the dispenser long enough?
I
Hold the glass under the dispenser 2 to 3 seconds after
releasing the dispenser lever.
New installation? Flush the water system. See "Water
I
Dispenser."
Recently changed water filter? Flush the water system. See
I
"Water Dispenser."
Water on the floor near the base grille? Make sure the water
I
dispenser tube connections are fully tightened. See
"Refrigerator Door(s) and Drawer."
Water from the dispenser is warm
NOTE: Water from the dispenser is only chilled to 50°F (10°C).
New installation? Allow 24 hours after installation for the
I
water supply to cool completely.
Recently dispensed large amount of water? Allow 24 hours
I
for water supply to cool completely.
Water not been recently dispensed? The first glass of water
I
may not be cool. Discard the first glass of water.
Refrigerator connected to a cold water pipe? Make sure
I
the refrigerator is connected to a cold water pipe. See "Water
Supply Requirements."
