Summary of Contents for Fisher-Price P5757
- Page 1 P5757 IMPORTANT! KEEP INSTRUCTIONS FOR FUTURE REFERENCE. www.fi sher-price.com.au...
-
Page 2: Consumer Information
Consumer Information Care • The restraint system, frame, trays and tray toy may be wiped clean using a mild cleaning solution and a damp cloth. WARNING • The food tray is also top rack dishwasher safe (or use bottom rack - without using the drying cycle). •... - Page 3 Assembled Parts CAUTION This package contains small parts in its unassembled state. Adult assembly is required. Seat Back Seat Bottom 2 Frames Hinge Rod Back Base Front Base 2 Seat Bottom Tubes Footrest Food Tray Base Tray Note: Tighten or loosen all screws with a Phillips screwdriver. Do not over-tighten the screws. #8 x 1,9 cm Screws –...
- Page 4 IMPORTANT! Before assembly and each use, inspect this product for damaged hardware, loose joints, missing parts or sharp edges. DO NOT use if any parts are missing or broken. Contact Fisher-Price ® for replacement parts and instructions if needed. Never substitute parts.
- Page 5 Assembly Insert Screws Here Hinge Hinge Rod • Insert two #10 x 2,2 cm black screws through the footrest and • Turn the seat assembly face down. into the seat bottom. Tighten the screws. This may require • Insert the hinge rod through the hinge on the seat back and seat extra force.
- Page 6 Assembly Frame Leg Seat Height Adjusters Position 4 Frame Decorated Side Frame Back Legs Press Lever • While pressing the levers on the seat height adjusters, lift them to position 4 on the frame front legs, as shown. Seat Assembly Base Screw Retainers Sockets...
- Page 7 Assembly Seat Height Adjuster Screw Retainers Base Seat Bottom Tube Ends • Fit the frame front legs onto the remaining base. • Fit a screw retainer over a hole in the front leg. • Insert a #10 x 2,2 cm black screw through the screw retainer and front leg.
- Page 8 Assembly Slot Elastic Loops Hole Hole Crotch Belt FRONT VIEW • Insert the crotch belt through the slot in the pad. Make sure the Tabs crotch belt is not twisted. Elastic Loops BACK AND BOTTOM VIEW • Lift the bottom of the pad. Insert the two elastic loops on the pad through the holes in the seat bottom.
- Page 9 Assembly Upper Shoulder Belt Slots Shoulder Portion Shoulder Portion Lower Shoulder Belt Slots Lower Shoulder Belt Slots • Fold the top of the pad down. • Remove the shoulder portion of the waist/shoulder belts by feeding them through the slots in the seat back. •...
- Page 10 Secure Child WARNING Prevent serious injury or death from falls or sliding out: Always use the restraint system for the upright and reclined positions of the seat. Adjust restraint to fit your child snugly. The tray is not designed to hold the child in the chair.
- Page 11 Secure Child Hold Adjuster Shoulder Portion Pull Down Strap Slide Adjuster Down TIGHTEN LOOSEN To tighten the shoulder belts: Hold the adjuster and pull the front • From the front of the high chair, pull the shoulder portion of shoulder strap down. the waist/shoulder belts out and then fit them back through the To loosen the shoulder belts: Slide the adjuster down.
- Page 12 Using the Trays WARNING Prevent serious injury or death from falls or sliding out: Always use the restraint system for the upright and reclined positions of the seat. Adjust restraint to fit your child snugly. The tray is not designed to hold the child in the chair.
- Page 13 Using the Trays Food Tray Base Tray • While pushing the release bar on the front of the base tray, • Fit the food tray into the base tray, as shown. pull the tray base towards you and remove. Hint: Before use, thoroughly wash all parts (the trays) that may contact food.
-
Page 14: Adjusting The Seat
Adjusting the Seat Hint: Adjust the seat height to any of seven positions! WARNING Prevent serious injury or death from falls or sliding out: • Always use the restraint system for the upright and reclined positions of the seat. Adjust restraint to fit your child snugly. The tray is not designed to hold the child in the chair. -
Page 15: Brake Use
Storage Brake Use WARNING Pull Frame Release Latch Prevent serious injury or death from falls or sliding out: • Position the high chair away from steps, hot surfaces, electrical cords and other items that may cause injury to the child. •... - Page 16 AUSTRALIA: Mattel Australia Pty. Ltd., 658 Church Street, Locked Bag #870, Richmond, Victoria 3121 Australia. Consumer Advisory Service 1300 135 312. NEW ZEALAND: 16-18 William Pickering Drive, Albany 1331, Auckland. Fisher Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. ©2008 Mattel, Inc.
