Page 1: Tumble Dryer
User Manual Tumble Dryer Manufactured for 60 Hz operation. See page 15 for conversion to 50 Hz. MODEL TYPE: Manufactured by Electrolux Home Products, NA 137636100A (1403) -
Page 2: Table Of Contents
Thank you for selecting our appliance We wish you lots of enjoyment with your new appliance and we hope that you will consider our brand again when purchasing household appliances. Please read this user manual carefully and keep it throughout the product life cycle as a reference document. The user manual should be passed on to any future owner of the appliance. -
Page 3: Important Safety Information
Important Safety Information In the interest of your safety and to ensure the correct use, before installing and fi rst using the appliance, read this user manual carefully, including its hints and warnings. To avoid unnecessary mistakes and accidents, it is impor- tant to ensure that all people using the appliance are thoroughly familiar with its operation and safety features. -
Page 4: Description Of The Appliance
Important Safety Information, continued • Never use the tumble dryer if the power supply cable, the • This appliance is designed for domestic use. It must not control panel, the working surface or the base are damaged be used for purposes other than those for which it was so that the inside of the tumble dryer is accessible. -
Page 5: Control Panel
Control Panel Information Henceforth, the programme selector dial, the display, the different buttons and the programme indicator light will be indicated in all the book with the relevant numbers given in this picture. This button allows you to change the drying temperature according to the fi ber content of fabrics to be dried. - Page 6 Control Panel, continued This knob allows you to change the desired dryness level of the fabrics at the end of an automatic programme. (See «Drying hints» for more details). • MAXIMUM: Select for highest dryness level. • HIGH: If load is too damp at the end of the programme, select this level for similar loads in the future.
-
Page 7: Programme Table
Programme Table Available Available Available Drying Programmes / Cycle Description / Type of Laundry Temperatures Dryness Levels Options High High Energy Saver LIGHTS/BLENDS (Programme duration approximately 23 minutes) Normal Normal Shrink Guard Cycled Heat - Cool down Wrinkle Release Select this programme to dry cottons, blends and permanent Chime press items with a no-iron fi... -
Page 8: Drying Hints
Drying Hints Before loading the laundry • Avoid drying dark clothes with light coloured fl uffy items such as towels as they could attract the fl uff. Never tumble dry the following: • The laundry must be thoroughly spun before tumble drying. Particularly delicate items such as net curtains, woollen, •... -
Page 9: Operating Sequence
Operating Sequence 3. Select the appropriate programme and settings for each load. 1. Check that the lint fi lter is See «Drying Hints» and «Dryer Programme Table» for more clean and in place. details. 4. Wake up and start the dryer. •... -
Page 10: What To Do If
What to do if... IMPORTANT! Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engi- neer. Before contacting your local Service Centre, please carry out the checks listed below. During appliance operation it is possible that few acoustic signals sound to indicate that the appliance is not working. -
Page 11: Technical Data
Technical data Electrical connection information Information on the electrical connection is given on the rating plate above the appliance door opening. Voltage [V] 230-240, single phase [50 Hz] 220-230, single phase [60 Hz] Connected load 4300 watts Maximum dry load Cotton 10.1 kg Synthetics... - Page 12 Carry the dryer’s exhaust outside via a 100 mm diameter dirt does not build up. Make sure there are no obstructing venting system ending at a fi xed ventilation grille fi tted to an items or material near the air-intake louvres provided at the exterior wall.
- Page 13 Venting, continued Exceeding the length of duct pipe or number of elbows Do not screen the exhaust ends of the vent system, or use allowed in the “MAXIMUM LENGTH” chart can cause an ac- any screws, rivets or other fasteners that extend into the duct cumulation of lint in the exhaust system.
- Page 14 Electrical connection This machine is designed to operate on a 220-240 V, single phase, 50 or 60 Hz (depending on country of fi nal destination). Check that your domestic Access cover screw electrical installation can take the maximum load required (4,5 Kw) also tak- ing into account any other appliances in use.
- Page 15 60 Hz to 50 Hz dryer conversion 50 Hz to 60 Hz dryer conversion This dryer was delivered from the manufacturer as a 60 Hz To get the maximum effi ciency from this dryer when operat- appliance. To get the maximum effi ciency from this dryer when ing on 60 cycle alternating current, the motor pulley must be operating on 50 cycle alternating current, the motor pulley positioned with the smooth end away from the motor.
- Page 16 Removing Back Sheet Panel To remove the back sheet panel and gain access to the dryer 1. Disconnect unit from power supply. motor pulley: 2. Remove terminal access cover and disconnect power cord from terminals if already installed. WARNING! 3. Remove all screws (1-20) holding back sheet to rear of cabinet and lay back sheet aside.
- Page 17 General Installation 1. Connect the exhaust duct to the outside exhaust system. Use of a 100 cm clamp is recommended to connect the dryer to the exhaust vent system. Use metal foil tape to seal all other joints. 2. Carefully slide the dryer to its fi nal position. Adjust one or more of the legs until the dryer is resting solidly on all four legs.
-
Page 18: Reversing Door Swing
Reversing door swing Your dryer is designed so the door swing may be reversed at any time without additional parts. Conversion is accomplished by transferring hinges and door strike to the opposite sides of the cabinet. Tools needed: • Be sure you have adequate swing area before WARNING! reversing door. - Page 19 5. Install four long screws securing hinge to door assembly 9. Install new striker (included in literature bag) into hole in the new location, take note to place each hinge in square plug was previously installed in. (Figure below) correct orientation. (Figure below) IMPORTANT: The plate with the stamped “D”...
-
Page 20: Environmental Concerns
Environmental concerns Packaging materials Ecological tips • Keep the lint screen clean and exhaust the dryer correctly. The materials marked with the symbol are recyclable. This means that they can be recycled by disposing of them • Sort laundry properly and select proper temperature and properly in appropriate collection containers.
