Astro Pneumatic PR14 User Manual

• Includes the following nosepieces: 1/4" (6.4mm), 3/16" (4.8mm),
5/32" (4mm), 1/8" (3.2mm), 3/32" (2.4mm)
• Performs well at any angle
• Gets into hard-to-reach areas
• The ¼" Nose piece is located on the end of the outer cylinder (PR14-02).
The 3/16", 5/32", 1/8" are threaded into the bottom Air Cylinder lid
(PR14-24).The 3/32" will be found inside a plastic bag with
other related parts.
• Provides quick, quiet and comfortable operation preventing user fatigue
SPECIFICATIONS:
Rivet Capacity: 1/4"
Overall Length: 10-7/8" (280mm)
Net Weight: 3-1/2lbs. (1.6kg)
Stroke: 15mm
Motor: 1/2hp
Air Inlet Thread NPT: 1/4"
Air Hose I.D. Size: 3/8" (10mm)
Avg. Air Consumption: 2.320 Liter/Stroke
Air Pressure: 90-120psi
PR14
Page 1
AIR RIVETER - 3/32", 1/8",
5/32", 3/16" AND 1/4" CAPACITY
www.astrotools.com

1 YEAR LIMITED WARRANTY

•Astro Pneumatic Tool Co. warrants our products to the original user against
defective material or workmanship for a period of 1 year (except where noted on our
price schedule) from the date of 1st use. Astro reserves the right to determine
whether the product failed because of defective material, workmanship or other
causes and to charge back for missing parts. Astro Pneumatic Tool Co., at its
discretion, will repair products covered under this warranty free of charge. The
distributor should direct the original user to return the product (with the exceptions
listed below) with the distributor's name, address, adequate proof of date of
purchase or a copy of warranty card, and a short note explaining the problem.
Failures caused by accident, alteration, or misuse are not covered by this
warranty.
•Astro Pneumatic Tool Co. or its authorized service representatives must perform all
warranty repairs. Any repair to the product by unauthorized service representatives
voids this warranty. The rights under this warranty are limited to the original user and
may not be transferred to subsequent owners.
•This warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability and fitness for a particular purpose. Some states do
not allow the exclusion of limitations of incidental or consequential damages so the
above limitations may not apply to you. All claims must be sent to:
Astro Pneumatic Tool Company
372 Old US Highway 52 South
Mt. Airy, NC 27030
PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING
1-800-221-9705 FOR INSTRUCTIONS
Unpacking
When unpacking, check the parts diagram and part number listing
on page 5 to make sure all parts are included. If any parts are
missing or damage, please call your distributor.
AIR RIVETER - 3/32", 1/8", 5/32", 3/16" AND 1/4" CAPACITY
