Playable File Types
 The system can recognize the files or
folders on a DATA DVD, DATA CD or
Video
USB device as follows:
 up to 300 folders
File format Extensions

up to 648 files
Xvid video ".avi"
 It may take time to read files in the
MPEG4 video 1) ".mp4" or ".m4v"
following cases:
 there are too many folders or files.
Music
 the memory capacity of the USB device
File format Extensions
is very large.
MP3 (MPEG1 Audio ".mp3"
 the memory of the USB device is
Layer 3) 2)
fragmented.
WMA 3) ".wma"
Compatible USB devices
AAC 4) ".m4a"
with this system
File format Extensions Check the website below for the information
about compatible USB devices.
JPEG ".jpg" or ".jpeg"
<http://www.sony-asia.com/support>
1) Supported video and audio codecs are as
follows:
Preparing the remote
 Video codec: MPEG4 Simple Profile
(AVC is not supported.)
Insert the two supplied R6 (size AA)

Audio codec: AAC-LC (HE-AAC is not
batteries, matching the polarities as shown
supported.)
below.
2) MP3 PRO format is not supported.
3) WMA DRM, WMA Lossless and WMA
PRO formats are not supported.
4) AAC DRM and AAC Lossless formats are
not supported.
Notes
 Some files may not play depending on the
format, the encoding method or recording
condition.
 Some USB devices may not work with this
system.
 The system supports ISO 9660 Level 1/
Level 2 and Joliet for DATA CD.
 The system supports UDF (Universal Disk
Format) for DATA DVD.
 The system supports FAT12, FAT16 and
FAT32 for USB device.
5
Parts and Controls
Front panel
 
POWER button  (play) button
Press to turn on or off the system. Press to start or re-start playback (resume
 play).
EQ button

Press to select a preset sound effect.  (fast forward) button
 Press to find a point in a track, file or
Remote sensor
chapter.

 (rewind) button
TUNING + button
Press to find a point in a track, file or
Press to tune to a desired station.
chapter.

DSGX button
 TUNING button
Press to turn on or off the DSGX effect.
Press to tune to a desired station.

 USB button
Display
Press to select the USB function.
9
AUDIO Playback operation buttons
Press to select an audio signal format when
/ (previous/next)
multiple audio signals are available.
/ (fast reverse/fast forward)
/ (slow reverse/slow forward)
SUBTITLE
Press to select a subtitle language when Press to watch in slow-motion when pressed
multilingual subtitles are available. in pause mode.
ANGLE  (play)
Press to switch to other viewing camera  (pause)
angles when multi-angles are recorded on a  (stop)
DVD VIDEO.
Radio operation buttons
Number buttons
PRESET +/
Press to enter numbers for selecting a title/
TUNING +/
chapter, preset radio station, etc.
SHIFT
DVD TOP MENU
Press and hold to use the pink number
Press to open the DVD top menu.
buttons.
 DVD MENU
Press to open or close the DVD menu.
When pressed during playback of JPEG
image files, a thumbnail view (digest view) is
displayed.
MUTING
Press to mute or unmute the sound.
///
Press to move the cursor for item selection.
(enter)
Press to enter/confirm the settings.
VOLUME +/
Press to adjust the volume.
SETUP
Press to open or close the setup menu.
DISPLAY
Press to open or close the Display Menu.
13
WARNING
Licences and Trademarks
To reduce the risk of fire or electric shock, do  This system incorporates with Dolby*
Digital.
not expose this apparatus to dripping or
* Manufactured under license from Dolby
splashing, and do not place objects filled with
Laboratories.
liquids, such as vases, on the apparatus.
"Dolby" and the double-D symbol are
To reduce the risk of fire, do not cover the
trademarks of Dolby Laboratories.
ventilation opening of the apparatus with
 MPEG Layer-3 audio coding technology
newspapers, tablecloths, curtains, etc.
and patents licensed from Fraunhofer IIS
Do not place the naked flame sources such as
and Thomson.
lighted candles on the apparatus.
 Windows Media is either a registered
As the main plug is used to disconnect the
trademark or trademark of Microsoft
unit from the mains, connect the unit to an
Corporation in the United States and/or
easily accessible AC outlet. Should you notice
other countries.
an abnormality in the unit, disconnect the
 This product contains technology subject
main plug from the AC outlet immediately.
to certain intellectual property rights of
Microsoft. Use or distribution of this
Do not install the appliance in a confined
technology outside of this product is
space, such as a bookcase or built-in cabinet.
prohibited without the appropriate
Do not expose batteries or apparatus with
license(s) from Microsoft.
battery-installed to excessive heat such as
sunshine, fire or the like.
The unit is not disconnected from the mains
as long as it is connected to the AC outlet,
even if the unit itself has been turned off.
CAUTION
The use of optical instruments with this
product will increase eye hazard.
This appliance
is classified as a
CLASS 1
LASER
product. This
marking is
located on the
rear exterior.
2
GB
Hooking up the system securely

To right speaker  Speakers
Insert only the stripped portion of the cords.

To left speaker
 DC IN 12V jack

To wall outlet
You can connect a DC power source to the DC IN 12V jack.

FM lead antenna
If the AC power supply is cut off (because of a power failure,
(Extended horizontally.)
for example), the power source automatically switches to DC

power. When the AC power supply resumes, the system
AM loop antenna
returns to AC power operation.
6
 
TUNER/BAND button Disc tray
Press to select tuner function. 
VOLUME control
Press to select FM or AM reception
Turn to adjust the volume.
mode.

AUDIO IN button

TAPE button
Press to select the AUDIO IN function.
Press to select the tape function.

 (pause) button

 (next) button
Press to pause playback. To resume
Press to select a track, file or chapter.
playback, press the button again.
PRESET + button 
 (previous) button
Press to select a preset station.
Press to select a track, file or chapter.

 (stop) button
 PRESET button
Press to stop and remember the stop
Press to select a preset radio station.
point (resume point).

DVD/CD button
To re-start playback from the resume
Press to select the DVD/CD function.
point (resume play), press .

ENTER button
Press to enter/confirm the settings.

/// button
Press to move the cursor for item
selection.

OPEN/CLOSE button
Press to open or close the disc tray.

(USB) port
Used for connecting a USB device.

AUDIO IN (audio in L/R) jacks
Used for connecting an optional audio
component.
10
Playing a Disc Playing Files on a Disc/USB
Device
1
Press FUNCTION +/ repeatedly (or
press DVD/CD on the unit) to select
1
Press FUNCTION +/ repeatedly (or
the DVD/CD function.
press DVD/CD or USB on the unit) to
2
Press  OPEN/CLOSE to open the disc select the DVD/CD or USB function.
tray.  DVD/CD: For a disc.
3  USB: For a USB device.
Place a disc in the disc tray, then
2
press  OPEN/CLOSE to close the disc
Load the source.
tray.  For a disc
Place a disc in the tray by pressing 
OPEN/CLOSE to open or close the disc
tray.
 For a USB device
Connect a USB device to the
port.
With the label side up.
4
Press  to start playback.
5
Press VOLUME +/ or turn VOLUME
control on the unit to adjust the
volume.
14
 ABOUT MPEG-4 VISUAL: THIS
PRODUCT IS LICENSED UNDER THE
MPEG-4 VISUAL PATENT PORTFOLIO
LICENSE FOR THE PERSONAL AND
NONCOMMERCIAL USE OF A
CONSUMER FOR DECODING VIDEO
IN COMPLIANCE WITH THE MPEG-4
VISUAL STANDARD ("MPEG-4 VIDEO")
THAT WAS ENCODED BY A
CONSUMER ENGAGED IN A
PERSONAL AND NONCOMMERCIAL
ACTIVITY AND/OR WAS OBTAINED
FROM A VIDEO PROVIDER LICENSED
BY MPEG LA TO PROVIDE MPEG-4
VIDEO.
NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION
INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND
COMMERCIAL USES AND LICENSING
MAY BE OBTAINED FROM MPEG LA,
LLC. SEE http://www.mpegla.com/
 All other trademarks and registered
trademarks are of their respective holders.
®
In this manual, TM and marks are not
specified.
About this manual
 "DVD" may be used as a general term for a
DVD VIDEO, DVD-R, DVD-RW, DVD+R
or DVD+RW.
 In this manual, CD-R or CD-RW is
sometimes referred to as "DATA CD. "
 In this manual, DVD-R, DVD-RW,
DVD+R or DVD+RW is sometimes
referred to as "DATA DVD. "
 This manual mainly explains operations
using the remote, but the same operations
can also be performed using the buttons on
the unit having the same or similar names.
 The outer electrode of the
DC IN 12V jack is
 (minus) and the inner
one is + (plus).
 Be sure not to connect the DC IN 12V jack
to a car cigarette lighter socket.
 Power
Connect the power cord to a wall outlet.
 Cable winders
You can adjust the speaker cable length by
wrapping the cables around the cable
winders.
 Antennas
Find a location and orientation that provide
good reception when you set up the
antennas.
Keep the antennas away from the speaker
cords and the power cord to avoid picking up
noise.
Top panel

 (record) button,  (play) button,
 (rewind) button,  (fast
forward) button,  (stop/eject)
button,  (pause) button
Press to operate the tape functions.
3
Select a desired file from the
displayed file list.
Cursor position number
Cursor
(USB)
 To move the cursor:
Press  or .
 To enter a folder:
Press or  after moving the cursor
to a desired folder.
 To return to the parent folder:
Press or  after moving the cursor
to .
USB device
You can also check the current cursor
position and its number from the
following information that will appear on
the display.
[FLD] XXX:
Indicates that a folder is selected,
representing its cursor position number
(ex. "[FLD] 005").
[BACK]:
Indicates that is selected.
File format and XXX:
Indicates the file format of a currently
selected file, representing its cursor
position number (ex. "WMA 002").
Playable Discs Music discs encoded with copyright
protection technologies
This product is designed to play back discs
DVD DVD VIDEO
that conform to the Compact Disc (CD)
DVD-ROM
standard. Recently, various music discs
DVD-R*/DVD-RW*
encoded with copyright protection
DVD+R*/DVD+RW*
technologies are marketed by some record
CD CD-DA (Music CD)
companies. Please be aware that among those
CD-ROM
discs, there are some that do not conform to
CD-R*/CD-RW*
the CD standard and may not be playable by
VIDEO CD
this product.
* If discs have not been correctly finalized,
Note on DualDiscs
they will not be played back. For more
A DualDisc is a two sided disc product which
information, refer to the operating
mates DVD recorded material on one side
instructions supplied with the recording
with digital audio material on the other side.
device.
However, since the audio material side does
Discs that cannot be played not conform to the Compact Disc (CD)
 Blu-ray Discs standard, playback on this product is not
 HD DVDs guaranteed.
 DVD-RAMs
Note on playback operations of a DVD
 DVD Audio discs
Some playback operations for a DVD may be
 PHOTO CDs
intentionally restricted by software
 Super Audio CDs
producers. Since this system plays a DVD
 Data track of CD-Extras
according to the disc contents, some playback
 Audio material side on DualDiscs
features may not be available.
 DVD-R/DVD-RW/DVD+R/DVD+RW in
Note about double-layer DVDs
VR (Video Recording) mode
The playback picture and sound may be
 CPRM (Content Protection for Recordable
momentarily interrupted when the layers
Media)-compatible DVD-R/RW containing
switch.
content flagged as "Copy once. "
3
Attaching the speakers Connecting your TV
Align the grooves and slide the speaker unit Connect the video input jack of your TV to
down until it snaps into the locked position. the VIDEO OUT jack on the unit, using the
To detach the speaker, unlock the speaker supplied video cord.
unit using the unlock lever, and slide the
speaker all the way up and away from the
main unit.
When connecting a video deck
Connect the TV and the video deck using
video and audio cords (not supplied) as
shown below.
Unlock lever
TV
Video deck
Do not connect directly
If you connect a video deck between this
system and the TV, you may experience video
leakage when watching the video signal from
this system. Do not connect a video deck
between this system and TV.
7
Remote
 OPEN/CLOSE

C arrying handle
Press to open or close the disc tray.
TIME
Press to display or switch the time
information during playback.
TV INPUT
Press to switch the TV's input source between
the TV signal and other input source.
Note that only Sony TVs can be operated
using this remote.
11
Recording onto a Tape
4
Press  to start playback.
5
Press VOLUME +/ or turn VOLUME
You can record just the portion you like from
control on the unit to adjust the
a sound source, including a connected audio
volume.
component. Use a TYPE I (normal) tape for
recording.
Playing a Tape
Use buttons on the unit for tape operations.
1
Insert a recordable tape into the
Use buttons on the unit for tape operations.
cassette holder with the side you
1
Press FUNCTION +/ repeatedly (or
want to record on facing up.
press TAPE on the unit) to select the
2
Prepare the recording source.
tape function.
 For a disc
2
Insert a tape.
Place a disc in the disc tray.
Open the cassette deck holder by
To record only your favourite tracks in
pressing , and insert a tape into the
desired order, press PROGRAM and
cassette holder.
program the tracks before recording (See
3
Press  to start playback. "To play in programmed order" (page
4 18)).
Press VOLUME +/ or turn VOLUME
 For a USB device
control on the unit to adjust the
Connect a USB device to the
volume.
port.
Notes  For a radio station
Tune to a desired station.
 Make sure there is no slack in the tape to
 For an optional component
avoid damaging the tape or the tape deck.
 Make sure to press  after the tape has Connect an audio component.
been wound or rewound to the end using 3
Start recording.
the / button.
 For a disc, a USB device and an
 Do not turn off the system during
audio component
playback.
Start playback, and then press .
 For a radio station
Press .
To stop recording, press .
Tips
 Sony recommend that you press  first,
and then press  to avoid noise being
recorded when you stop recording.
 If a whistling noise occurs while recording
AM radio programs, press ISS repeatedly to
select "ISS-1" or "ISS-2. " This may reduce
such noise and improve recording quality.
15
Region code (DVD VIDEO only)
Your system has a region code printed on the
rear of the unit and will only play a DVD
VIDEO (playback only) labeled with an
identical region code or .
ALL
Note about Multi Session CD
You can play only 1st session of a
multisession disc.
4
Color System Setup
Change the color system if necessary from
[PAL], [Multi] or [NTSC] after connecting
your TV. The factory default of the color
system is [PAL].
1
Connect the power cord to a wall
outlet.
2
Press POWER on the unit to turn on
the system.
3
Press FUNCTION +/ repeatedly (or
press DVD/CD on the unit) to switch
the function to DVD/CD.
Playback starts automatically if a disc
with an auto playback function is loaded.
Press  twice to stop playback.
4
Press SETUP in stop mode.
The setup menu appears.
5
Press / repeatedly to select
[Preference Page], then press .
6
Press / repeatedly to select [TV
Type], then press .
7
Press / repeatedly to select [PAL],
[Multi] or [NTSC], then press .
8
Press SETUP to turn off the Setup
Unit Menu.
Note
The display on the TV screen may be
interrupted momentarily after changing the
color system as described above.
8
TV / (on/standby)
Press to turn on or off the TV.
Note that only Sony TVs can be operated
using this remote.
PROGRAM
Press to activate program play in the DVD/
CD function, or press to preset radio stations
in the tuner function.
REPEAT
Press to activate repeat/shuffle playback
mode.
FUNCTION +
Press to select a function in sequence.
EQ
Press to select a sound effect.
DSGX
Press to turn on or off the bass boost effect.
FUNCTION 
Press to select a function in sequence.
ZOOM
Press to zoom in or zoom out of a displayed
picture when viewing a DVD VIDEO, a
VIDEO CD, an Xvid video, an MPEG4 video
or a JPEG image. You can move the
magnified portion of the picture by pressing
///.
ISS (Interference Suppress Switch)
Press to select "ISS-1" or "ISS-2" to suppress
whistling noises when recording AM radio
programs onto a tape.
FM MODE/IF BAND
Press to select the FM reception mode
(monaural or stereo).
Press to select a preset bandwidth from
among "IFBAND-1, " "IFBAND-2, "
"IFBAND-3" or "IFBAND-4" while listening
to an AM radio program. These may help
reduce interference on some frequencies.
12
Listening to Sound from an
Optional Component
You can listen to sound from a component
connected to the AUDIO IN jacks on the unit
using an audio cord (not supplied).
1
Connect the audio output jacks of
your component and the AUDIO IN
jacks of this system using the audio
cord.
2
Press VOLUME  or turn VOLUME
(USB)
control on the unit counterclockwise
to turn down the volume.
3
Press FUNCTION +/ repeatedly (or
press AUDIO IN on the unit) to select
the AUDIO IN function.
4
Press VOLUME +/ or turn VOLUME
control on the unit to adjust the
volume.
16
Continued 
