Summary of Contents for Ascendtech VT1000
- Page 1 VT1000 USER MANUAL Vehicle Tracker User Manual V5.2 VT1000...
-
Page 2: Table Of Contents
VT1000 USER MANUAL Preface Thank you for purchasing our products. This deliberately edited manual is to introduce the tracker with the complete technical data and the instructions showing how to operate the device smoothly and correctly. Make sure to read this manual carefully before using this product. -
Page 3: Ⅱ Attentions
VT1000 USER MANUAL Attention 1. Make sure to read this manual carefully before using this product. 2. Please insert the SIM card before installing, and make sure the SIM card has no password, otherwise the tracker will not work normally. -
Page 4: Ⅴ Set Up
VT1000 USER MANUAL 5. Movement Alert: Send SMS to the unit to start the movement alert function. When the vehicle is moving, the unit will send the movement alert to all authorized numbers. 6. Overspeed Alert: Send SMS to the unit to start the movement alert function. When the vehicle is overspeed, the unit will send the overspeed alert to all authorized numbers. - Page 5 VT1000 USER MANUAL SMS “Supplyoil123456” to the tracker. "Supplyoil" as instruction, "123456" as the password. 7. Control Circuit Send SMS “stopelec+password” to control circuit. For example send SMS: “stopelec123456”. "stopoil" as instructions, "123456" as the password. To supply the circuit again, send SMS “supplyelec+password”...
- Page 6 VT1000 USER MANUAL This function will be out of effect after the unit moves outside the district. 13 . Restart the tracker. Send SMS “reboot+password” to the tracker. For example“reboot123456”.The tracker will be restarted. It will reply “system will reboot...”.
-
Page 7: Ⅵ Installation Diagram
VT1000 USER MANUAL Example:apn123456 cmnet 2.Send SMS “user+space+apn user name+space+apn password” Example: user telecom abc1234 “user” is command, “telecom” is APN user name, “abc1234” is APN password. After send SMS, tracker will reply “Set GPRS User and Password ok . ” . - Page 8 VT1000 USER MANUAL ◆GPS Vehicle Tracker Installation GPS tracker should be installed by technical professional of local service centre. Without permission, the user cann’t repair and move the tracker randomly. If users do, any unfortunated damage should be compensated by himself.
- Page 9 VT1000 USER MANUAL Picture b. Door sensor Connect and state diagram (Door closed/Open) Temperature 7.Purple Wire ( Connection temperature sensor 8.Brown Wire/Black Gray Wire Connection fuel sensor. Fuel sensor Installation Guide： Connect Fuel sensor with GPS Tracker. Connect External Power DC12V Or 24V .Turn on GPS Tracker.
- Page 10 VT1000 USER MANUAL The GPS Tracker will reply:Set R value ok. Reference Picture...
- Page 11 VT1000 USER MANUAL...
-
Page 12: Track By 900D Web Based Tracking Software
VT1000 USER MANUAL Track by 900D web based tracking software Enable GPRS Set APN Send the SMS to the tracker as following format Command Remark Set APN: Case 1 (No apn user name and apn password) Command format: apn+password+space+apn name... - Page 13 Case 1: Command format: accon+time interval For example: accon : Command code Accon007 In this example: VT1000 will send location every 7 seconds when car moving(ACC ON). Upload data in preset time when ACC OFF Command Remark Command format: accoff+time interval...
- Page 14 Very Important Note: Please do not omit the minus if there's a minus before the terminal ID. Click "Submit", and then you add the GPS tracker VT1000 successfully on the software 900D. Wait few seconds, and you will see the GPS Tracker online icon on software...
-
Page 15: Ⅹ Specs
VT1000 USER MANUAL Put a check mark on the device, and right click, you will see the menu as below picture. Now you can track online. Attention: For 900D GPS Software, "Monitor" and "Number Plate" must be checked till the font becomes blue, then the GPS tracker will update location automatically on map.Like below picture:... -
Page 16: Command Set
VT1000 USER MANUAL Work Voltage DC 9V－30V Battery Chargeable changeable 3.7V / 1.2Ah Li-ion battery Standby work current < 30mA Storage Temp. -40°C to +85°C Operation Temp. -20°C to +70°C Humidity 5%--95% non-condensing ◆ Command Set Function Reply Admin123456 13612345678... - Page 17 VT1000 USER MANUAL Restart Reboot123456 System will reboot tracker Enquiry position GPS info position Telephone123456 Set telephone ok Set auto track mode Web123456 Set web ok Set ip and ip58.64.205.22port7000 set IP address and PORT ok port Set APN Apn123456 cmnet...
