Page 1: User Manual
DVD-3200 User Manual Please read this User Manual carefully to ensure proper use of this product and keep this manual for further reference. -
Page 2: Table Of Contents
Content Introduction Safety Precautions Important Safety Instructions Caution Features Front Panel and Rear Panel Illustration Remote Control Connections Connecting to a TV set Connecting to an AV Receiver with 5.1 Channel Analog Audio Input Connecting to an AV Receiver with Digital Audio Input Basic Playback Basic Operation Advanced Features... -
Page 3: Introduction
Safety Precautions CAUTION: CAUTION THE UNIT EMPLOYS A LASER SYSTEM. TO EN- SURE THE PROPER USE OF THE UNIT, READ RISK OF ELECTRIC SHOCK THIS MANUAL CAREFULLY AND KEEP IT FOR DO NOT OPEN FUTURE REFERENCE. IF THE UNIT REQUIRES SERVICING, CONTACT THE LIGHTNING FLASH WITH ARRO- THE SELLER OR SEE "TROUBLESHOOTING". -
Page 4: Specifications
Specifications Power requirements: 90-240V~50/60Hz Power consumption: 15W Video standard: NTSC/PAL/AUTO Unit Weight: 2.1 KG Video out Video out: 1.0V(p-p)/75 , sync, negative polarity, RCA pin Jack x 1 S-video output connector(separate Y C signal output connector): Y output: 1.0V(p-p)/ 75 , sync, negative polarity C output: 0.286 V(p-p)/75 Audio out 2.1channel out: 1.85V(rms)/10k , RCA pin Jack(L,R) x 1... -
Page 5: Important Safety Instructions
Important Safety Instructions 15. Outdoor Antenna Grounding 20. Servicing If an outside antenna or cable system is connected to Do not attempt to service this product yourself as the product, be sure the antenna or cable system is opening or removing covers may expose you to grounded so as to provide some protection against dangerous voltage or other hazards. -
Page 6: Troubleshooting
Troubleshooting If you have any questions, please consult the troubleshooting guide below. NO PICTURE OR SOUND "BAD DISC" DISPLAYED Ensure the power button is on. Ensure the disc is not warped, damaged or deformed. Ensure the power outlet is operational. Ensure the disc is not badly stained or damaged. -
Page 7: Features
Features Full compatibility with DVD, CD, Kodak Picture CD, CD-R and CD-RW (finalized) Multiple playback modes: Program, Search, 10-Second Review Dynamic spectrum display Coaxial and optical digital audio output S-video, composite video and component (Y, Pb, Pr) video outputs Disc formats supported by this player: Dolby Digital KODAK picture CDs DVD video... -
Page 8: Remote Control Operation
Remote Control Operation ANGLE During DVD playback Press ANGLE to view scenes from different camera angles. Press ANGLE repeatedly to change from one camera angle to another. Note: This function is disc specific. LANGUAGE During DVD playback Press LANGUAGE repeatedly to select from up to 8 audio languages/formats. -
Page 9: Remote Control
Remote Control STANDBY OPEN/CLOSE STANDBY PROG DISPLAY PROG SUBTITLE SUBTITLE LANGUAGE LANGUAGE ANGLE TIME ANGLE SETUP REPEAT ENTER SETUP VOL- VOL+ LEFT RETURN MODE ZOOM ENTER STEP MUTE RESUME VOL- SLOW TITLE MENU DOWN PREV NEXT RETURN PAUSE STOP PLAY ZOOM STEP SLOW... -
Page 10: Connections
Remote Control Operation SLOW Press slow repeatedly to slow motion playback at variable speeds. STEP Press STEP during playback to pause playback. Press STEP repeatedly to play frame. Press play to resume normal playback. REPEAT Select to press REPEAT to select Repeat Title, Repeat chapter, Repeat off During DVD playback. -
Page 11: Connecting To An Av Amplifier With 5.1 Channel Analog Audio Input
Connecting to an AV Amplifier with 5.1 Channel Analog Audio Input Coaxial Optical YELLOW WHITE VIDEO V I D E O Amplifier INPUT SELECTOR POWER BYPASS PRO LOGIC 3 STEREO MODE TEST CHANNEL KARAOKE MUTE DOWN BASS TREBLE MIC VOL EXCITE DVD IN FRONT-R... -
Page 12: Connecting To An Av Amplifier With Digital Audio Input
Remote Control Operation PLAY Press PLAY from stop mode to start playback. Press PLAY during playback to replay the last 10 seconds. This function is not available if the elapsed time of current track is less than 10 seconds. Note: MP3 discs and some DVD discs do not have a 10 second review feature. PAUSE Press PAUSE during playback to pause playback. -
Page 13: Basic Operation
Basic Operation Preparation before playing: 1. Connect the DVD player to your TV and amplifier. 2. Turn on the TV. Set the TV to the AV input connected to the DVD player. 4. Turn down the volume on your amplifier, and then power it on. Set the amplifier to the AV input connected to the DVD player. -
Page 14: Modes And Features Setup
Remote Control Operation TIME During playback, press TIME, and the [Track Search] menu will display as follows: Others Search Time -:--:-- Track Notes: Search Time -:--:-- Title / Chapter - - / - - Use the number keys to input the desired Time, Title or Chapter, then press ENTER to confirm. Press TIME again , the [Disc Search] menu will display as follows: Disc Search Time... - Page 15 Modes and Features Setup Language Setup Select [Subtitle], and press ENTER or to display the [Subtitle] submenu: Language Video Audio MoreAud Rating OSD Menu English Subtitle English English Audio English DVD Menu English A. Press ENTER to confirm B. Press SETUP to exit the Setup Menu Select [Audio],and press ENTER or to display the [Audio] submenu: Language...
- Page 16 Remote Control Operation STANDBY During playback, press STANDBY to stop the player and return to standby mode. While the player is in standby, press STANDBY or any key on the front panel to resume normal operation. OPEN/CLOSE To open the disc tray, press OPEN/CLOSE. To close the disc tray, press OPEN/CLOSE again.
-
Page 17: Rating Setup
Modes and Features Setup Select [Video Output], and press ENTER or to display Language the [Video Out] submenu: A . Press ENTER to confirm TV shape B. Press SETUP to exit the Setup Menu TV system Note: The Composite video and Video Output S-video output is always available.
