1 Warning Caution: • Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder- ing iron, please be careful not to heat too long.
4 Disassembly and Assembly Instructions 4.1. Disassembly Instructions 1. Remove Shaft Cover from Main Body by Slotted screw- 4. Remove Pivot spring by gripping and pulling it out from driver(Minus driver). the Main body. 2. Remove Torx screws at Shaft position by Phillips screw- driver(Plus driver).
Page 6
7. Remove Lock Button and Lock Button Spring. 10. Take off Press Plate. 8. Remove Iron Plate of Heater B from Hook. 11. Remove 2 Screws of the Housing side by Phillips screw- driver(Plus driver). 9. Remove Slide Plate and Slide Spring. 12.
Page 7
13. Remove Housing A from Housing B in Grip Case as fol- 14. Take off Iron Plate and Circuit assembly b/k from Hous- lowing the drawing. ing B.
Page 8
4.2. Assembly and Disassembly Points 1. Shaft Cover fixing point. 2. Housing B Assembly Point.
Page 9
4.3. Lead wire of Iron Plate(Heater A, Heater B) and Circuit arrangement points. 1. Lead wire of Iron Plate(Heater A assembly b/k) and Circuit assembly b/k arrangement follows as below. 2. Lead wire of Iron Plate(Heater B assembly b/k) arrangement follows as below. 3.
7 Exploded View and Replacement Parts List Model No. : EH-HW11 Exploded View for EH-HW11...
Page 12
Model No. : EH-HW11 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks EH-HW11 EHHW11HSABW HOUSING A ASSEMBLY BLOCK EHHW11FSW FLOATING SPRING 4 *1 EHHW11HABW HEATER A ASSEMBLY BLOCK EHHW11PKW PACKING (INCLUDE 1 INSULATION TUBE,CONNECTOR COV EHHW11CCAW...
Page 13
Model No. : EH-HW32 Exploded View for EH-HW32...
Page 14
Model No. : EH-HW32 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks EH-HW32 EHHW32HSABW HOUSING A ASSEMBLY BLOCK EHHW32FSW FLOATING SPRING 4 *1 EHHW32HABW HEATER A ASSEMBLY BLOCK EHHW32PKW PACKING (INCLUDE 1 INSULATION TUBE, CONNECTOR CO EHHW32CCAW CIRCUIT ASSEMBLY BLOCK VER BLOCK)
