Important Information
For your Venting dryer to operate efficiently, you must follow the regular maintenance schedule shown below:
Fluff Filter...
! You MUST clean the fluff filter after EVERY drying
cycle.
STEP 1.
Open the door of your
dryer.
STEP 4.
Refit the filter.
- Make sure the arrows
are facing you.
! Failure to clean the filter after EVERY drying cycle will affect the drying performance of your machine.
-
It will take longer to dry and as a result will use more electricity during drying.
! You MUST clean fluff build up around the filter housing and the vent tube periodically, EVERY two or three months:
-
Check the vent tube and any permanent venting fixture to make sure that there has been no accumulation
of fluff or lint, and remove it.
-
Remove lint that collects around the filter and the outlet vents.
STEP 2.
Pull out the filter (using
the two finger grips).
STEP 5.
Make sure the filter is
pushed fully home.
- NEVER run the dryer
without the filter in position.
STEP 3.
Clean any fluff deposits
from the filter mesh.
GB
1
Advertisement
Table of Contents
Related Manuals for Indesit IS60V
Summary of Contents for Indesit IS60V
-
Page 1: Important Information
Important Information For your Venting dryer to operate efficiently, you must follow the regular maintenance schedule shown below: Fluff Filter... ! You MUST clean the fluff filter after EVERY drying cycle. STEP 1. STEP 2. STEP 3. Open the door of your Pull out the filter (using Clean any fluff deposits dryer. -
Page 2: Table Of Contents
The front The back Control panel Start and programmes, 6 Choosing a programme Laundry, 7-8 Sorting your laundry IS60V Wash care labels Special clothing items Drying times Warnings and Suggestions, 9 General safety Disposal Saving energy and respecting the environment... -
Page 3: Installation
Installation Where to put your dryer Permanent venting In conjunction with the vent tube we recommend Place your dryer at a distance from gas ranges, using a Wall/Window Vent Kit, available at a retail stoves, heaters, or cook tops because flames can location or the nearest Spare Parts Dealer. -
Page 4: Electrical Connection
Installation Open window venting Changing the plug The end of the tube should be directed The wires in the power cord are coloured in accordance downwards, to prevent with the following: warm moist air from Green and Yellow (Earth) wire to terminal condensing in the room or marked ‘E’, symbol or coloured green and... -
Page 5: Dryer Description
Dryer Description The front The back Rating plate Air Intake Vent Control Panel Drum Model & Serial Vent Tube fitted here numbers Filter Caution: Hot! Control panel START Indicator Button HEAT TIMER Drying Guide Button Knob The START button begins drying a selected The Drying Guide allows you to consult a user friendly programme (see Start and Programmes). -
Page 6: Start And Programmes
Start and Programmes Choosing a programme 6. Press the START button to begin. During the drying programme, you can check on 1. Plug the dryer into the electrical socket. your laundry and take out items that are dry while others continue drying. When you close 2. -
Page 7: Laundry
Laundry Sorting your laundry Wash Care Labels Check symbols on clothing labels to make sure Look at the labels on your garments, especially when that the articles can be tumble dried. tumble drying for the first time. The following symbols Sort laundry by fabric type. -
Page 8: Special Clothing Items
Laundry Special clothing items Times are approximate and can vary depending upon: Blankets and Bedspreads: acrylic items (Acilan, Courtelle, Orion, Dralon) must be dried with special Amount of water retained in clothes after spin care on LOW heat setting. Avoid drying for a long cycle: towels and delicates retain a lot of water. -
Page 9: Warnings And Suggestions
Warnings and Suggestions ! The appliance has been designed and built Do not tumble dry large, very bulky items. according to international safety standards. Do not tumble dry acrylic fibres at high temperatures. These warnings are given for safety reasons and must Complete each programme with its Cool Tumble Phase. -
Page 10: Maintenance And Care
Maintenance and Care Switching off the electricity Check the drum after each cycle Unplug your dryer when not using it, when cleaning it Turn the drum manually in order to remove small items and during all maintenance operations. (handkerchiefs) that could have been left behind. Cleaning the drum Clean the filter after each cycle ! Do not use abrasives, steel wool or stainless steel... -
Page 11: Troubleshooting
Troubleshooting One day your dryer seems not to be working. Before you call your Service Centre (see Service), go through the following troubleshooting suggestions: Possible causes / Solution: Problem: The plug is not plugged into the socket, or not making contact. The dryer won’t start. -
Page 12: Service
Service 1 9 5 0 4 2 5 7 6 . 0 5 W 08/2006 - SIMLEX . Four Ashes, Wolverhampton Before calling the Service Centre: Spare Parts Use the troubleshooting guide to see if you can This dryer is a complex machine. Repairing it yourself or solve the problem yourself (see Troubleshooting).
