INSTALLATION & OPERATION
MANUAL
25‐SSP01 / 55‐SHSSP01 /
55‐TRSSP01
25‐SSP01S / 55‐SHSSP01S /
55‐TRSSP01S
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL‐BURNING
APPLIANCE. KEEP CHILDREN, FURNITURE, AND ALL COMBUSTIBLES AWAY FROM ANY HEATING APPLIANCE.
FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN
DEATH. FOR YOUR SAFETY AND PROTECTION, FOLLOW THE INSTALLATION INSTRUCTIONS OUTLINED IN
THIS MANUAL. CONTACT YOUR LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND
INSTALLATION INSPECTION REQUIREMENTS (INCLUDING PERMITS) IN YOUR AREA.
THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. CONSULT THE
OWNER'S MANUAL FOR FURTHER INFORMATION. IT IS AGAINST FEDERAL REGULATIONS TO OPERATE THIS
WOOD HEATER IN A MANNER INCONSISTENT WITH THE OPERATING INSTRUCTIONS IN THE OWNER'S
MANUAL.
8
CAUTION
SAFETY NOTICE
SAVE THESE INSTRUCTIONS
Manufactured By:
England's Stove Works, Inc.
PO Box 206
Monroe, VA 24574
08/2015
Advertisement
Table of Contents
Related Manuals for England's Stove Works Smartstove 25?SSP01
Summary of Contents for England's Stove Works Smartstove 25?SSP01
- Page 1 8 INSTALLATION & OPERATION Manufactured By: MANUAL England’s Stove Works, Inc. PO Box 206 25‐SSP01 / 55‐SHSSP01 / Monroe, VA 24574 55‐TRSSP01 08/2015 25‐SSP01S / 55‐SHSSP01S / 55‐TRSSP01S CAUTION PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL‐BURNING APPLIANCE. KEEP CHILDREN, FURNITURE, AND ALL COMBUSTIBLES AWAY FROM ANY HEATING APPLIANCE. SAFETY NOTICE FAILURE TO FOLLOW THESE INSTRUCTIONS CAN RESULT IN PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH. FOR YOUR SAFETY AND PROTECTION, FOLLOW THE INSTALLATION INSTRUCTIONS OUTLINED IN THIS MANUAL. CONTACT YOUR LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION INSPECTION REQUIREMENTS (INCLUDING PERMITS) IN YOUR AREA. THIS WOOD HEATER NEEDS PERIODIC INSPECTION AND REPAIR FOR PROPER OPERATION. CONSULT THE ...
-
Page 2: Maintenance
IMPORTANT: IF YOU HAVE A PROBLEM WITH THIS UNIT, DO NOT RETURN IT TO THE DEALER. CONTACT TECHNICAL SUPPORT @ 1‐800‐245‐6489 Tamper Warning: This wood heater has a manufacturer‐set minimum low burn rate that must not be altered. It is against federal regulations to alter this setting or otherwise operate this wood heater in a manner inconsistent with operating instructions in this manual. Mobile Home Use: This freestanding pellet unit is approved for mobile home or doublewide installation with the outside combustion air hook‐up See the “Installation” section of this manual for details pertaining to mobile home installations. Mobile home installation must be in accordance with the Manufactured Home and Safety Standard (HUD), CFR 3280, Part 24. WARNING: USE OF OUTSIDE COMBUSTION AIR IS MANDATORY WITH THIS UNIT. DO NOT OPERATE WITH THE HOPPER OPEN; LID MUST BE SHUT AND TIGHTLY LATCHED DURING OPERATION. DO NOT OVER‐FIRE YOUR UNIT. Note: England’s Stove Works does not recommend using a pellet stove as your only source of heat. Retain for your files Model Number Date of Purchase ... -
Page 3: Table Of Contents
TABLE OF CONTENTS Yearly Introduction Important Notes....27 Introduction ........ 4 Exhaust Blower....28 Specifications Convection Blower...28 Heating Specifications ....... 5 Hopper Fines.....29 Dimensions ........ 5 Checking Gaskets....29 EPA Compliance ......... 5 Troubleshooting Guide Installation Troubleshooting......30‐31 Installation Overview.... 6 Clearances to Combustibles..7 Replacing Components Venting Introduction.... 8 ... -
Page 4: Introduction
INTRODUCTION Thank you for purchasing this fine product from England’s Stove Works! England’s Stove Works was started, and is still owned by, a family that believes strongly in a “Do It Yourself” spirit; that’s one reason you found this product at your favorite “Do It Yourself” store. We intentionally design and build our stoves so that any homeowner can maintain their stove with basic tools, and we’re always more than happy to help you do the job as easily and as inexpensively as possible. However, while remaining simple, our stoves are designed to perform extremely efficiently, helping deliver more heat from less fuel. Please look at the extensive Help section on our website and call our Technical Support Department at (800) 245‐6489 if you need any help with your stove. We are nearly always able to “walk you through” any installation issues, repairs, problems or other questions that you may have. Wishing you years of efficient, quality and “comfy” heating, Everyone at England’s Stove Works Please Note: While information obtained from our web site and through our Technical Support line is always free of charge, there will be a service charge incurred with any “on‐site” repairs or maintenance that we may arrange. This manual encompasses all versions of the 25‐SSP01, including the 55‐SHSSP01 and the 55‐TRSSP01. However, for simplicity of description, the stove will be referred to by the generic 25‐SSP01 designation. ... -
Page 5: Specifications
SPECIFICATIONS Heating Specifications Approximate Pellet Burn Rate**……………………………………………0.73 to 2.48 kg/hr Maximum Burn Time**………………………………………………………………………..72 hours Approximate Square Footage Heated***…….………………………….up to 2,200 sq. ft. Hopper Capacity………………………………………………………………………….…..120 pounds Dimensions EPA and Safety Compliance Specifications EPA Compliance Status ……......... Certified to comply with 2020 particulate emission standards using pellet fuel. U.S. Test Standard: US EPA 40 CFR Part 60, Subpart 60.536 Particulate Emissions …………………………………………………………………… .56 grams/hr CO Emissions ……………………………………………………………………………. 85.30 grams/hr Efficiency……………………………………………………………………………………… 71.8% (HHV) Tested To UL 1482‐00, ASTM E 1509, ULC/ORD‐C1482‐M1990 & ULC S627‐00 Notes for this unit: Product may vary slightly from diagram. Clearances are the minimum for this unit and may need to be increased in the rear to have proper vent clearances. Follow all venting manufacturer clearances and local codes. *‐ As tested per ASTM 2779‐10 ** ‐ Heat output, burn rate and maximum burn time are heavily dependent on the type of pellets burned in the stove; as such, these numbers may vary. *** ‐ The maximum heating capacity of this unit can vary greatly based on climate, construction style, insulation and a myriad of other factors. Use this information in conjunction with a BTU loss calculation for your home to determine if this unit will be sufficient for your needs. 5 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR ... -
Page 6: Installation
INSTALLATION Installation Overview When choosing a location for your new stove, there are a multitude of factors that should be taken into account before beginning the installation. 1. Traffic Patterns – To help prevent accidents, the stove should be placed in a location where it is out of the way of normal travel through the home. 2. Heat Flow and Efficiency – When deciding on a location for the stove, consider the way heat moves throughout your home. Install the stove where you need the heat; basement installations often do not allow sufficient heat to flow to the upper floors and a top floor installation will not allow any heat to reach the floors below. Always consider that heat rises and will take the path of least resistance while it is still hot. 3. Exhaust Location – Outside walls are generally the best place to install a stove, since they allow easy exhaust and intake air installation (using our Dura Vent AC‐3000 Kit, AC‐ 33000 if Canada). If there is not a feasible way to install the stove on an outside wall, there are methods for venting the stove up through the roof, but they tend to be more costly because they involve the use of more pellet vent pipe and can often make outside air installation more difficult. 4. Wall Construction – Locating the stove so that the exhaust system can pass between studs will simplify the installation and eliminate the need to reframe any sections of the wall to accommodate the wall thimble. Warning Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any ... -
Page 7: Clearances To Combustibles
INSTALLATION Clearances to Combustibles Unit to Side Unit to Rear Unit to Corner Wall (A) Wall (B) (C) 10 in. 0 in. 3 in. 254 mm 0 mm 76.2 mm CAUTION Unit can be very HOT while in operation. Keep children away. Supervise children in the same room as this appliance. Alert children and adults to the hazards of high temperatures. ... -
Page 8: Venting Introduction
INSTALLATION Venting Introduction This pellet stove operates on a negative draft system, which pulls combustion air through the burn pot and pushes the exhaust air through the vent pipe and out of the building. This unit must be installed in accordance with the following detailed descriptions of venting techniques; not installing the stove in accordance with the details listed here can result in poor stove performance, property damage, bodily injury or death. England’s Stove Works is not responsible for any damage incurred due to a poor or unsafe installation. If questions arise pertaining to the safe installation of the stove, our Technical Support line (800‐245‐6489) is available. Contact your local code official to be certain your installation meets local and national fire codes and if you’re uncertain about how to safely install the stove, we strongly recommend contacting a local NFI certified installer to perform the installation. Venting Guidelines ALWAYS install vent pipe in strict adherence with the instructions and clearances included with your venting system. DO NOT connect this pellet stove to a chimney flue which also serves another appliance. DO NOT install a flue pipe damper or any other restrictive device in the exhaust venting system of this unit. USE an approved wall thimble when passing through a wall and a ceiling support/fire stop when passing through a ceiling. ONLY use 3.0” or 4.0” Type L or Type PL pipe approved for pellet stove venting; DO NOT use galvanized or B‐Vent pipe. SEAL each joint of pellet vent with high temperature silicone (Part # AC‐RTV3) to prevent smoke spillage into the home. AVOID excessive horizontal runs and elbows, as both will reduce the draft of the venting system and will result in poor stove performance. INCLUDE as much vertical pipe as possible to prevent smoke from the unit from entering your home in the event of a power outage. ... -
Page 9: Additional Venting Information
INSTALLATION Additional Venting Information Do not mix and match components from different pipe manufacturers when assembling your venting system (i.e. Do NOT use venting pipe from one manufacturer and a thimble from another). We require a minimum vertical rise of 36 in. (3 ft.) of pipe to create natural draft in the system. This helps evacuate smoke from the stove in the event of a power failure or combustion blower failure. Venting systems 15.0 ft. or shorter may be composed entirely of 3.0 in. pellet pipe; to reduce frictional losses, venting systems longer than 15.0 ft. should be composed of 4.0 in. pellet pipe. Do not terminate the venting system directly beneath any combustible structure such as a porch or deck. Follow NFPA 211 rules listed below for venting system termination location relative to windows and other openings in the dwelling. o NFPA 211 (2006 ed.) Section 10.4 Termination: 10.4.5 (1) The exit terminal of a mechanical draft system other than direct vent appliances (sealed combustion system appliances) shall be located in accordance with the following: (a) Not less than 3 ft. (.91 m) above any forced air inlet located within 10 ft. (3.0m). (b) Not less than 4 ft. (1.2 m) below, 4 ft. (1.2 m) horizontally from or 1 ft. (305 mm) above any door, window or gravity air inlet into any building. (c) Not less than 2 ft. (0.61 m) from an adjacent building and not less than 7 ft. (2.1 m) above grade when located adjacent to public walkways. Distance between the termination opening and grade should be a minimum of 2 ft. (24 in.) contingent on the grade surface below the termination. When determining the termination height above grade, consider snow drift lines and combustibles such as grass or leaf accumulation. In areas where significant snowfall is possible, the termination height must be sufficiently high to keep the termination free of snow accumulation. ... -
Page 10: Through The Wall
For high altitude installations INSTALLATION (above 4,000 ft.), the vent pipe should be increased from 3‐inch Approved Venting Method 1: Through the Wall (3”) to four‐inch (4”). Generally the simplest installation method, venting through the wall using our AC‐3000 kit, AC‐33000 if Canada (or similar venting system) is also the preferred venting method. It minimizes horizontal pipe, allows the stove to be installed close to the wall and keeps the clean‐out tee on the outside of the house, for ease of cleaning. When installing any venting system, Type L or Type PL pipe must be used and all clearances to combustibles (listed by the pipe manufacturer) must be strictly adhered to. Use the pipe manufacturer’s approved thimble for passing through a combustible wall, and maintain at least the minimum clearances to combustibles. Use an appliance collar where the pellet vent connects to the exhaust output of the pellet stove and attach the appliance collar to the exhaust blower output using three sheet metal screws. Secure the pellet vent to the outside of the house using a wall strap just below the 90 degree elbow. Seal each pipe connection joint with high temperature RTV Silicone, to ensure the system is leak free (Check with the specific venting system manufacturer’s instructions before doing so). If the pellet vent pipe being used is not a “Twist Lock” system, three (3) sheet metal screws are required at each pipe joint. Connect the pellet stove to outside combustion air using the kit included with your stove or using an alternative method, as described in the “Outside Air” section, on page 15. This installation type can be modified for basement (Basement installations should always be ... -
Page 11: Through The Ceiling
For high altitude installations INSTALLATION (above 4,000 ft.), the vent pipe should be increased from 3‐inch Approved Venting Method 2: Through the Ceiling (3”) to four‐inch (4”). Venting through the ceiling/roof may be the only feasible venting option in some cases and is a factory recommended installation. When installing any venting system, Type L or Type PL pipe must be used and all clearances to combustibles listed by the pipe manufacturer must be strictly adhered to. Use the pipe manufacturer’s approved ceiling support for passing through a combustible ceiling, as well as the required fire stops, radiation shields, flashing and storm collar. Be certain to follow the manufacturer’s required height of termination above the roof line, and maintain at least the minimum clearances to combustibles. Use an appliance collar where the pellet vent connects to the exhaust output of the pellet stove and attach the appliance collar to the exhaust blower output using three sheet metal screws. Seal each pipe connection joint with high temperature RTV Silicone, to ensure the system is leak free (Check with the specific pipe manufacturer’s instructions before doing so). If the pellet vent pipe being used is not a “Twist Lock” system, three (3) sheet metal screws are required at each pipe joint. Connect the pellet stove to outside combustion air using the kit included with your stove or using an alternative method, as described in the “Outside Air” section, on page 15. This venting method can also be modified so that the venting system runs horizontally through the wall from the stove, then transitions to vertical and terminates above the roofline. When using ... -
Page 12: Existing Chimney
For high altitude installations INSTALLATION (above 4,000 ft.), the vent pipe should be increased from 3‐inch Approved Venting Method 3: Existing Chimney System (3”) to four‐inch (4”). Using an existing masonry or factory built chimney for venting is the only other acceptable method for venting this pellet unit. Use Type L or Type PL venting pipe until entering the existing chimney. Use the appropriately sized adapter when transitioning from the pellet vent pipe to the masonry or factory built thimble and be certain that the adapter is sealed tightly to both the pellet venting system and the existing chimney. Before using an existing chimney, be certain it is in good condition (A chimney sweep inspection is highly recommended). Also, make sure the chimney meets the minimum standards listed in NFPA 211 (A chimney professional can confirm this upon inspection). If connecting this stove to a factory built chimney, it may ONLY be a 6” flue, UL103 HT venting system (ULC S629 if Canada). Connection to any other factory built chimney may result in a poorly operating or dangerous stove installation. When connecting to an existing masonry chimney, the cross‐sectional area of the flue must be considered. A chimney with a flue larger than 6” round (28.27 sq. in.) may require relining with an approved pellet stove chimney lining system. Use an appliance collar where the pellet vent connects to the exhaust output of the pellet stove and attach the appliance collar to the exhaust blower output using three sheet metal screws. Seal each pipe connection joint with high temperature RTV Silicone, to ensure the system is leak free (Check with the specific pipe manufacturer’s instructions before doing so). If the pellet vent pipe being used is not a “Twist Lock” system, three (3) sheet metal screws are required at each pipe joint. ... -
Page 13: Mobile Home Installation
INSTALLATION For high altitude installations (above 4,000 ft.), the vent pipe should be increased from 3‐inch Mobile Home Installation (3”) to four‐inch (4”). The England’s Stove Works, Inc. outside air kit MUST be used for installation of this unit in a mobile home. Please see the “Outside Air” section on page 15 for more information regarding outside air connections. The outside air inlet must be kept clear of leaves, ice and other debris. Keeping the outside air inlet free of restriction is crucial to preventing air starvation and smoke spillage. The pellet stove MUST be secured to the floor of the mobile home using lag bolts and the holes provided in the bottom of the base for this purpose. Outdoor‐aired space heaters must be attached to the structure. The pellet stove MUST be grounded with #8 solid copper grounding wire (or equivalent), terminated at each end with an NEC approved grounded device. Carefully follow all clearances listed in the appropriate section of this manual AND follow the venting manufacturer’s minimum clearance requirements. Similarly, be certain the venting system used is approved for mobile home use. Installation must be in accordance with Manufacturers Home & Safety Standard (HUD) CFR 3280, Part 24 as well as any applicable local codes. Use silicone to create an effective vapor barrier at the location where the chimney or outside air ducting passes through to the exterior of the structure. Chimney Cap/Spark Arrestor Roof Flashing and Storm Collar ... -
Page 14: Vent Termination Clearances
VENT TERMINATION CLEARANCES A) Min. 4‐ft clearance below or beside any door or window that opens. B) Min. 1‐ft clearance above any door or window that opens. C) Min. 2‐ft clearance from any adjacent building. D) Min. 7‐ft clearance from any grade when adjacent to public walkways. E) Min. 2‐ft clearance above any grass, plants, or other combustible materials. F) Min. 3‐ft clearance from a forced air intake of any appliance. G) Min. 2‐ft clearance below eaves or overhang. H) Min. 1‐ft clearance horizontally from combustible wall. I) Vents installed with mechanical exhausters shall terminate not less than 12 in. (305mm) above the highest point where they pass through the roof surface. Notes on termination of Pellet Vent Pipe from NFPA 211 (2006 ed.) Section 10.4 Termination: 10.4.5 (See also “INSTALLATION” section of manual AND additional notes above): Not less than three (3) feet above any forced air inlet located within ten (10) feet. Not less than four (4) feet below, four (4) feet horizontally from, or one (1) foot above any door, window or gravity air inlet into any building. Not less than two (2) feet from an adjacent building, and not less than seven (7) feet above grade where located adjacent to public walkways. The exhaust exit shall be arranged so that the flue gases are not directed so that it will affect people, overheat combustible structures, or enter buildings. Forced draft systems and all parts of induced draft systems under positive pressure during operation shall be installed gastight or to prevent leakage of combustion products into a building. 14 Through‐the‐wall vents shall not terminate over public walkways, or where condensate or vapor could create hazards IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND or a nuisance. REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR Be sure to follow local codes and all manufacturer’s instructions (including exhaust pipe). USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. Consult a professional installer and/or call Technical Support if you have any questions. ... -
Page 15: Outside Air Hookup
OUTSIDE AIR HOOK‐UP The use of outside combustion air is mandatory on this pellet stove. The outside air connection pipe protrudes from the lower rear center of the stove; use the included outside air kit to attach your stove to outside combustion air. Instructions and all the parts needed to make the outside air connection to your pellet stove are included with the outside air kit. If it is not feasible to use the included outside air hookup kit in your stove installation, other materials may be used, provided the following rules are followed: The pipe used for outside air hookup must be metal, with a minimum thickness of .0209 in. (25 gauge mild steel) or greater and an inside diameter of approximately 2.0 in. All pipe joints and connections should be sealed with pipe clamps or other mechanical means, to insure a leak free outside air connection. Long runs of pipe and excessive elbows for outside air should be avoided. Due to frictional resistance in pipe, any excessive outside air piping can result in poor stove performance. A screen or other protection device must be fitted over the outside air termination point to prevent rain, debris and nuisance animals from entering the piping system. Increase the outside air pipe size to 3.0 in. diameter pipe if the outside air connection is more than 6 ft. in length, more than two (2) elbows are used or if the stove is installed in a basement. The outside air connection system should be inspected at least annually to be certain it is free from blockage. Caution NEVER draw outside combustion air from: 1. Wall, floor or ceiling cavity. 2. Enclosed space such as an attic, garage or crawl space. 15 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND ... -
Page 16: Floor Protection
FLOOR PROTECTION This pellet stove requires a non‐combustible floor protector if the stove is to be installed on a combustible floor. If the floor the stove is to be installed on is already non‐combustible (i.e. a concrete floor in a basement) and has an R value equal to or higher than .2, no floor protection is needed (although a decorative floor protector can still be used for aesthetic reasons). Prefabricated floor protectors which are UL listed (ULC if Canada) or equivalent can be purchased or a floor protector can be built from standard materials: two sheets of .5” thick cement board covered with ceramic tile would be a suitable floor protector which meets the .2 R‐value requirement. When using any floor protector, consider that this stove is not only heavy but will induce heating and cooling cycles on the floor protector which can damage tile and loosen mortar and grout joints. A hearth rug is NOT an approved substitute for a proper hearth pad. For the US: The floor protector must extend at least 6 in. (152.4 mm) from the front & sides and 4 in. (101.6 mm) from the rear. For Canada: The floor protector must extend at least 18.0 in. (457.2 mm) from the front of the unit, 8.0 in. (203.2 mm) from the sides of the unit and 4.0 in. (101.6 mm) from the rear. In Canada, it is required that the non‐combustible floor protector is underneath and extends 2 in. (50.8 mm.) on either side of any horizontal venting runs AND/OR is directly underneath any vertical venting pipe. ... -
Page 17: Daily Operation
DAILY OPERATION Getting Started Check to see that the hopper is clean and free from foreign materials. Be sure to connect this unit to a working outlet; we recommend using a surge protector to help protect the electronic components from damage. BEFORE your first fire, dry run your unit (no pellet fuel in the hopper) for twenty minutes; pressing the “ON” button with the unit plugged in will initiate the dry run. Once the “ON” button is pressed, you should immediately hear the exhaust blower start and operate continuously. A default set temperature will appear in the window of the control board. After about three to five minutes, look for the red glow of the igniter in the igniter port of the burn pot to be certain it is operating normally. Hold the hopper lid switch (See “Illustrated Parts Diagram” pg. 45) down with your finger and check to see that the auger is turning. Release the hopper lid switch and be certain that the auger stops turning. DO NOT PUT YOUR FINGERS IN THE HOPPER OR NEAR THE ROTATING AUGER. After about twenty minutes, the control board should display “FS” in the two display windows (More information on Error Codes can be found in the Error Code section of this manual). At this point, the dry run is complete and your pellet heating appliance is ready for normal operation. Lighting a Fire In order for this stove to operate, the hopper must first be filled with pellet fuel. Lift the hopper lid using the flush‐ mount handle and pour the pellet fuel directly into the hopper. We recommend using only pellets manufactured by PFI Certified facilities, since pellets bearing the PFI stamp of approval will be low in ash and moisture, high in BTU’s, and uniform in size and quality. This pellet stove will perform equally well using softwood and hardwood pellets, and although the ash may differ slightly in appearance or texture, both types of pellets will burn cleanly and efficiently in this stove. This pellet stove is equipped with an automatic pellet ignition system; the only user input required to light the stove is a simple press of the “On” button. After pressing the “On” button, the most recent setting will appear in the window of the control board. This indicates the stove has entered the start‐up sequence and is operating normally. ... -
Page 18: Daily Operation Notes
Operation Daily Notes Only high quality, Premium Grade ¼” (.25 in.) diameter wood pellets should be used in this stove. Using low grade wood pellets with high ash content OR wood pellets with a high moisture content can cause the burn pot to fill with ash at a more rapid pace and can cause intervals between periodic maintenance to become significantly shorter. Please read the “Maintenance” section of this manual thoroughly to understand how fuel selection affects stove operation, maintenance and cleaning. Variation in the flame height is normal; not all wood pellet fuel is uniform in size, which can affect the way pellets are fed into the burn pot. Although the flame height may increase and decrease during operation, there is no loss of efficiency. Always store wood pellet fuel in a dry location; storing wood pellet fuel in a dry location ensures the fuel will remain pelletized and low in moisture content. Also, be certain that all wood pellet fuel is stored at a safe distance from the pellet heater; storing fuel in close proximity to the stove can result in a fire. This pellet burning room heater is equipped with a specially designed burn pot which comes preinstalled from the factory. This burn pot elevates the burning pellets and delivers air at the precisely‐required locations. Pellets must only be burned in the factory burn pot; no modifications should be made to this burn pot and no additional grates or other fire elevators should be used. CAUTION NEVER USE GASOLINE, GASOLINE‐TYPE LANTERN FUEL, KEROSENE, CHARCOAL LIGHTER FLUID, OR SIMILAR LIQUIDS TO START OR “FRESHEN UP” A FIRE IN THIS HEATER. KEEP ALL SUCH LIQUIDS WELL AWAY FROM THE HEATER WHILE IN USE. ADDITIONALLY, NEVER APPLY FIRE‐STARTER TO ANY HOT SURFACE OR EMBERS IN THE STOVE. DO NOT USE CHEMICALS OR FLUIDS TO START THE FIRE. DO NOT BURN FLAMMABLE FLUIDS SUCH AS GASOLINE, NAPHTHA OR ENGINE OIL. DO NOT BURN GARBAGE; LAWN CLIPPINGS OR YARD WASTE; MATERIALS CONTAINING RUBBER, INCLUDING TIRES; MATERIALS CONTAINING PLASTIC; WASTE PETROLEUM PRODUCTS, PAINT OR PAINT THINNERS, OR ASPHALT PRODUCTS; MATERIALS CONTAINING ASBESTOS; CONSTRUCTION OR DEMOLITION DEBRIS; RAILROAD TIES OR PRESSURE‐TREATED WOOD; MANURE OR ANIMAL REMAINS; PAPER PRODUCTS, CARDBOARD, PLYWOOD OR PARTICLEBOARD. THE PROHIBITION AGAINST BURNING THESE MATERIALS DOES NOT PROHIBIT THE USE OF FIRESTARTERS MADE FROM PAPER, CARDBOARD, SAWDUST, WAX AND SIMILAR SUBSTANCES FOR THE PURPOSE OF STARTING A FIRE IN AN AFFECTED WOOD HEATER. BURNING THESE MATERIALS MAY RESULT IN RELEASE OF TOXIC FUMES OR RENDER THE HEATER INEFFECTIVE AND CAUSE SMOKE. 18 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND ... -
Page 19: Control Board Settings
CONTROL BOARD SETTINGS Manual/Automatic Mode Automatic Mode Your stove will arrive from the factory programmed in automatic mode. First, make sure the thermocouple wire is resting on the floor in a safe location where it can’t be damaged or stepped on. The thermocouple wire is where the control board will read the room temperature. In this mode, after pressing the ON button, you select the desired room temperature (ranging from 60 to 90 degrees F) by pressing the Up or Down arrows, and the stove will operate the auger feed and blower speed according to the temperature you have selected. When the desired temperature is reached, the stove will go into the shutdown mode. The stove will remain off after going through the shutdown cycle until the room temperature drops below the desired setting. Once the temperature drops below the desired setting, the stove will go through startup and run until temperature has been reached again. We recommend running this mode in very well‐insulated areas in the home, or in milder climate regions. It is not recommended to run this mode in less‐insulated areas of the home, or in extremely cold climate regions. Running the stove in this mode in those environments causes strain on the igniter and could lead to frequent replacement, as the unit will run cycles more often than is optimal. ... -
Page 20: Maintenance
Setting Stove in Automatic Mode o To set the stove back into automatic mode, press the down arrow and the up arrow button simultaneously. This will toggle the stove to Automatic Mode. o While in Automatic Mode, the stove board will display the Set Temperature. o The control board on this stove allows the user to adjust the heat output and convection blower speed, turn the unit on and off, and test components for function (more on diagnostic mode later). CAUTION This unit is meant to operate only with door closed. Smoke spillage and an inefficient, lazy burn will result from attempting to operate the stove with the door open. In addition, using fuel other than wood pellets can create an unsafe situation and can also generate excess carbon monoxide. Carbon monoxide is an odorless, colorless gas which can be deadly. Be sure to burn only wood pellets. The use of a carbon monoxide detector is strongly recommended . 20 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ... -
Page 21: Error Codes
ERROR CODES Error codes are alphanumeric codes that will appear in the Heat Range and Blower Speed window of the Control Board if the unit experiences an abnormal condition. Error codes are the control board’s way of telling the user that something isn’t operating correctly within the stove, and that the unit should be carefully inspected before reigniting. See the “Trouble‐Shooting Guide,” page 32, for additional information on error codes. FS When this code is displayed in the control board window it indicates a failure to start. Although the stove may have ignited the pellets, the control board did not register a high enough temperature to determine the fire was lit. If a fire was ignited, wait for the unit to cool, clean the burn pot and restart the unit. OT This error code indicates the preset maximum allowable exhaust temperature was exceeded. Commonly referred to as “Over‐Temp.,” the OT code means something in the stove is causing the exhaust gas to be hotter than expected. If an error code continues to display, if the error code seems unexplainable, or if you have any other questions about error codes and what they mean, please contact Technical Support at (800) 245‐6489. Hopper Lid Safety Switch ‐ This unit is also equipped with a hopper lid safety switch (Part # AC‐ HLSB) which is directly connected to the auger motor. In the event the hopper lid is left open while the stove is in operation, the hopper lid switch will prevent the auger from turning. This is to prevent byproducts of combustion from entering the home through the open hopper lid and also ... -
Page 22: Power Failure
POWER FAILURE If the power to the unit is interrupted for approximately three minutes or less, the unit will resume operation when power is restored according to the following table: Unit’s State Before Power Loss State When Power Returns ON Warmup Warmup Warmup Shut‐Down Shut‐Down OFF OFF If the power is interrupted for more than (approximately) three minutes, the unit will be “OFF” when power returns. IMPORTANT – Do NOT open the hopper lid or the door to the unit during power outage. Open the closest outside door and a window to reduce the chance of any combustion byproducts entering the home from the stove. Wait for the power to be restored and then press the “ON” button to restart the unit, if necessary. Smoke Detectors England’s Stove Works, Inc. highly recommends the use of smoke detectors in every room of the house. However, locating a smoke detector directly above this unit can result in ... -
Page 23: Important Notes
*Failure to properly clean your stove can cause poor performance and possibly a burn back!* DAILY MAINTENANCE Disposal of Ashes – Ashes should be placed in a metal container with a tight fitting lid. The closed container of ashes should be placed on a noncombustible floor or on the ground, well away from all combustible materials, pending final disposal. If the ashes are disposed of by burial in soil or otherwise locally dispersed, they should be retained in the closed container until all cinders have been thoroughly cooled. Important Notes As with any maintenance concerning this unit, be sure the unit is “OFF” and has completed the Shut‐Down cycle BEFORE beginning. Be aware that metal parts in the firebox can remain HOT long after the fire has gone out and EVEN after the Shut‐Down cycle is complete. Always use extreme caution when handling potentially hot stove parts, even if you think they should be cold. Ashes should only be removed when the stove has been shutdown and has been allowed to cool thoroughly. Hot embers can remain under ashes long after the fire has gone out, so always be extra careful when handling any ashes from this (or any) stove. Different pellets will generate varying amounts of ash and burn pot deposits. Carefully monitor the ash build up in the stove when first operating the unit, as well as whenever a different brand of pellets is burned. While the amount of ashes generated by this unit is not excessive compared to a traditional log‐burning woodstove, keeping the unit clean and free of ash is ESSENTIAL for peak performance and maximum efficiency. Ash build‐up hampers airflow, reduces efficiency, and can cause a smoke back. England’s Stove Works® is not responsible for any damages incurred due to a poorly maintained and/or dirty stove. This pellet stove is a highly efficient machine and, as such, requires sufficient maintenance to keep it operating at its peak. -
Page 24: Cleaning The Burn Pot
Because of the open design of the firebox, the majority of the ash will be on either side of the cradle. Open the door of the stove and use an old paint brush or putty knife to move ash from around the burn pot and into the open areas beside the cradle. Using the cleaning tool provided, remove any deposits left in the burn pot, being careful to remove them from the burn pot and not allow them to filter down into the cradle area. Excessive ash build‐up in the cradle can cause poor stove performance (See “Cleaning the Burn pot,” below). WARNING: Use caution when using the cleaning tool, as it has a sharp point and may have some sharp edges (as with any metal tool). As we recommend with any maintenance, use gloves, safety glasses and any necessary safety apparel when handling the cleaning tool. Cleaning the Burn Pot Along with removing ashes from the stove, cleaning the burn pot is the other essential part of daily maintenance that will keep the stove operating at its peak. Pellets contain varying amounts of impurities and fusible material that will accumulate in the burn pot over time. Some pellets will contain much higher amounts of these fusible impurities, therefore extra vigilance may be required to maintain a clean burn pot. Allowing impurities to build up in the burn pot can restrict the air flow to the fire, resulting in a dirty, inefficient burn and can shorten the life of the burn pot. Always allow the stove to finish the shut‐down cycle and cool completely before performing any maintenance inside the firebox. Open the front door and remove the burn pot by lifting it straight up and out of the cradle. WARNING – The burn pot can remain HOT long after the fire has gone out, so wear protective gloves whenever handling a potentially hot burn pot. Once the burn pot is out of the stove, use the cleaning tool to remove any deposits from the inside of the burn pot. Be certain all air holes are clear and unrestricted by fusible ash matter; the cleaning tool provided is designed to fit these holes and will be useful in removing stubborn deposits from these holes. Remove any ash material from the bottom of the cradle and brush any ash from the top of the cradle into the sides of the firebox. Keeping the top of cradle free of ash is crucial in allowing the burn pot to seat properly in the cradle. Insert the burn pot back into the cradle using the reverse of the procedure detailed above. ... -
Page 25: Baffle Removal
MONTHLY MAINTENANCE Baffle Removal As with any maintenance concerning this unit, be sure the unit is “OFF,” has completed the Shut‐Down cycle, and is completely cool BEFORE beginning. Be aware that metal parts in the firebox can remain HOT long after the fire has gone out and EVEN after the Shut‐Down cycle is complete. Always use extreme caution when handling potentially hot stove parts, even if you think they should be cold. Bi‐weekly maintenance should include the steps listed in this section AS WELL AS the steps listed in the “Daily Maintenance” section. The real wall firebox baffles are a hanging design, which allows them to be easily removed for cleaning. Remove all ash accumulation behind the baffles. The use of a utility vacuum is highly recommended because it will prevent fly‐ash from falling through the exhaust holes and into the exhaust chamber. Remove the exhaust chamber clean‐out port cover (lower left), using a 5/16” socket wrench. BEFORE vacuuming the chamber out, observe the type and quantity of ash build‐up. The ash deposited in the exhaust chamber should be light, fluffy, grey or white in color, and should be no higher than half way up the clean‐out port. After removing all the fly‐ash from behind the baffle, reinsert the baffles into the stove, using the reverse of the process detailed above. Using a utility type vacuum cleaner, vacuum the fly ash out of the exhaust chamber. A short piece of hose can be attached to the end of the utility vacuum line and can be useful in reaching the ash. A specially designed ash vacuum and pellet stove cleaning kit is available from the England’s Stove Works website; please see: store.heatredefined.com Important Notes ... -
Page 26: Venting Pipe
Monthly maintenance should include the steps listed in this section AS WELL AS the steps listed in the “Daily Maintenance” and “Bi‐weekly Maintenance” section. Intervals between monthly cleanings will depend on the duration that the stove is burning on a daily basis. A stove which is operated continuously will need more frequent monthly cleanings than a stove which is used periodically as supplemental heat. A good rule of thumb for monthly maintenance is that it should be done each time an entire ton of pellets is burned OR once per month, whichever comes first. If excess ash accumulation is found in the exhaust chamber or venting system during monthly maintenance, the interval between cleanings should be reduced to eliminate the possibility of poor stove performance due to ash accumulation. A specially designed ash vacuum and pellet stove cleaning kit is available from the England’s Stove Works website; please see: store.heatredefined.com Venting Pipe Cleaning Low spots and direction changes in the venting system (such as tees and elbows) are areas for potential fly‐ash and creosote accumulation. INSPECT these areas diligently to keep the venting system in safe operating condition. Depending on the specific type of venting system your stove is connected to, it may be possible to remove the clean‐out tee cover and simply run a pipe brush up the pipe to remove any fly‐ ash accumulation. Brushes specifically made for cleaning pellet pipe are available at the retailer where you bought this stove, as well as at most hearth product dealers. Horizontal runs of pipe, such as from the exhaust connection on the stove to the vertical transition, will accumulate fly ash and should be inspected carefully and brushed clean. Check the termination cap to be certain it is not clogged or restricted by any fly‐ash accumulation. After thoroughly cleaning the venting system, reseal any disassembled seams with high temperature silicone (Part # AC‐RTV3) if applicable to your venting system. ... -
Page 27: Important Notes
YEARLY MAINTENANCE Important Notes As with any maintenance concerning this unit, be sure the unit is “OFF,” has completed the Shut‐Down cycle, and is completely cool BEFORE beginning. Be aware that metal parts in the firebox can remain HOT long after the fire has gone out and EVEN after the Shut‐Down cycle is complete. Always use extreme caution when handling potentially hot stove parts, even if you think they should be cold. Yearly (or end of season) maintenance should include the steps listed in this section AS WELL AS the steps listed in the “Daily Maintenance” and “Monthly Maintenance” sections of this manual. Yearly maintenance should be performed at the end of the burning season. Leaving ash and other build‐up in the stove during the non‐heating months can lead to premature metal degradation in the stove and venting system. Using extra attention to detail and being certain to be very thorough in the end of season cleaning will help increase the operating life of the stove and venting system. SOOT AND FLY ASH: FORMATION AND NEED FOR REMOVAL The products of combustion will contain small particles of fly ash. The fly ash will collect in the exhaust venting system and restrict the flow of the flue gases. Incomplete combustion, such as that which occurs during startup, shutdown or incorrect operation of the room heater will lead to some soot formation which will collect in the exhaust venting system. The exhaust venting system should be inspected at least once every year to determine if cleaning is necessary. ... -
Page 28: Exhaust Blower
YEARLY MAINTENANCE Exhaust Blower Cleaning Although the exhaust blower and blower housing were designed to minimize ash build‐up, some fly‐ash will still accumulate there throughout the burning season. The amount and type of ash will depend on the type of pellets and venting system, but generally this accumulation will be mild. If, when cleaning the exhaust blower, a large accumulation of fly‐ash is found, cleaning the exhaust blower and housing should be performed monthly or bimonthly to prevent this excess buildup. Instructions Before beginning the exhaust blower cleaning procedure, be certain the unit is unplugged and thoroughly cooled down. Remove the panel to the left (if facing the stove). See page 44 for panel removal instructions. Once the panel is off, the exhaust blower will be clearly visible. Disconnect the venting system from the exhaust blower just enough that you will be able to remove the exhaust blower from the stove (the rear panel will also need to be removed). Unplug the two wires which connect the stove wiring harness to the exhaust blower, using the quick connect plugs. Loosen the five (5) ” self‐drilling screws which hold the exhaust blower to the exhaust blower tube. Lift the exhaust blower up and out of the stove. The gasket which seals the exhaust blower to the exhaust blower tube is fragile, so take extra care when removing the blower. Even when being careful, though, it is easy to tear this fragile gasket, and since an airtight seal is crucial here, it is best to replace this gasket (Part # ‐ PU‐CBG) every time the exhaust blower is removed. With the exhaust blower removed, use a utility vacuum to remove any ash accumulation in the exhaust blower tube. Use a soft paint brush and carefully remove any ash accumulation from the inside of the exhaust blower, and from the exhaust blower fan blade. Inspect the exhaust blower motor for dust accumulation and carefully remove it, ensuring that all air cooling holes into the motor are open and free of dust deposits. Install the blower in the reverse order as described above. Remember to check the condition of the exhaust blower gasket. ... -
Page 29: Hopper Fines
YEARLY MAINTENANCE Cleaning Pellet Fines from the Hopper and Auger Depending on the type and quality of pellets burned in the stove, some accumulation of pellet fines and dust is possible in the hopper. The lowest part of the auger, near the back of the stove, is where most fines will accumulate. With the stove off, unplugged, completely cool and with the hopper empty, use a utility vacuum to remove the fines from the auger tube. If the fines cannot be removed from the top of the hopper: Remove the back panel, using a ” socket to remove the screws. Locate the auger motor assembly at the middle rear of the stove, and once it is found, find the two set screws on either side of the cast iron mounting collar. Using a ” allen wrench, loosen the set screw on either side of the auger mounting collar. With a utility vacuum in hand, let the auger assembly slide out of the auger tube just enough so that the vacuum can be used to remove any fines from this area. Reinstall the auger assembly and tighten the two set screws; reinstall the back panel, being certain to tighten the retaining screws on the rear of the stove. Cleaning Pellet Fines Inside Auger Tube Remove the auger cover plate (located above the auger at the bottom of the hopper) by removing the (8) 5/16” screws that hold it in place. Using a utility vacuum remove any excess dust or fines that have collected in the auger tube around the auger. Re‐install auger cover plate in reverse method. Checking Gaskets An airtight seal at the door opening is crucial to proper stove performance. Any air leaks in this area can not only cause a dirty, inefficient burn but can also pose a serious safety threat. Because of this, the door gasket should always be maintained in good condition, and replaced annually or sooner if necessary. Gasket tightness can be checked using the “dollar‐bill” method: Place a dollar bill between the gasket and the stove body (at the location where the gasket meets the stove). Close the door tightly and attempt to pull the dollar bill out. If the dollar bill slides in and out easily, the gasket needs to be replaced. This test should be repeated around the entire gasket perimeter, as gaskets will sometimes seal tightly on one side, but will be worn and seal poorly ... -
Page 30: Troubleshooting Guide
Trouble‐Shooting Guide WARNING: To avoid ELECTRICAL SHOCK always disconnect the unit from the power source BEFORE attempting any repair. If this guide does not correct the problem, call your local dealer or Technical Support at 1‐800‐245‐6489. Problem Cause Solution Auger not turning 1. Bad auger motor. 1. Replace auger motor. 2. Foreign matter jamming auger. 2. Remove pellets and object. 3. Vacuum sensor. 3. Check exhaust blower. Smoke smell or dust in house 1. Improper exhaust connection. 1. Check exhaust connections for leaks, especially the exhaust blower connect. Seal leaks with silicone, aluminum tape or a hose clamp. Room blower not operating 1. Loose thermal sensor. 1. Tighten connection on sensor. 2. Blower speed set higher than heat range, 2. Lower blower speed. causing stove to cool and blower to cycle. 3. Loose connection. 3. Check control board connection. Exhaust blower not operating 1. Loose connection. 1. Check control board connection. 2. Bad blower. 2. Replace blower. 3. Bad vacuum sensor. 3. Replace vacuum sensor. ... - Page 31 Unit Shuts Down in 15‐20 1. Loose thermal sensor. 1. Check both sides of thermal sensor minutes with an "FS" code on connection (exhaust blower and control board. (Failed Start) control board). 2. Control board settings. 2. Start stove on minimum Heat Range 5 to ensure a good fire is started. 3. Failure to light pellets. 3. Check igniter for buildup or failure. "OT" Code on Control Board 1. Convection (Room Air) blower failure. 1. Check convection blower for proper (OverTemp) function, replace if necessary. 2. Partially blocked flue. 2. Check flue for obstructions. 3. Using fuel other than premium wood 3. Use ONLY premium wood pellets in pellets. this stove. Notes: 1. Whenever instructed to check/replace the vacuum sensor, also check for loose or cracked vacuum hose. Also, be certain the vacuum measurement port in the firebox is kept clean (clean with a pipe cleaner or brush, do not use a vacuum to clean). ...
-
Page 32: Replacing Components
REPLACING COMPONENTS Auger Motor Before beginning any component replacement, be certain the unit is unplugged and thoroughly cooled down. Also, make sure the hopper is empty before attempting to remove or replace the auger motor assembly. Remove the back panel of the unit, using a ” wrench. Before loosening any auger motor bolts, detach the wiring harness from the auger motor. Locate the auger motor assembly at the rear of the stove, and begin by loosening the (2) ” allen set screws on either side of the cast iron auger motor coupler. Slide the auger assembly out of the tube. Remove the (4) screws which hold the cast iron auger motor coupler to the auger motor, using a ” wrench. Slide the cast iron auger motor coupler and the steel spacer plate off of the auger motor. Loosen the ” allen set screw which holds the steel auger coupler to the auger motor output shaft, and remove the steel auger coupler, as well as the rubber vibration dampener. Reinstall the parts in reverse order on the new auger motor, being careful not to over‐tighten the bolts which hold the cast iron auger coupler to the auger motor. 32 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ... -
Page 33: Convection Blower
REPLACING COMPONENTS Convection Blower Before beginning any component replacement, be certain the unit is unplugged and thoroughly cooled down. Remove the rear panel (using a ” wrench) and locate the convection blower. Detach the convection blower from the wiring harness before going any further. Loosen and remove the (4) ” screws which hold the blower assembly to the stove; remove the blower assembly from the stove. Installation of the new blower is performed in reverse of removal; remember to reconnect the new blower to the wiring harness. (When installing the new blower, place the blower motor opening pointing UP, towards the top of the stove.) 33 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ... -
Page 34: Combustion Blower
REPLACING COMPONENTS Combustion Blower Before beginning any component replacement, be certain the unit is unplugged and thoroughly cooled down. Remove the left side panel and locate the combustion blower. Disconnect the venting system from the exhaust blower, and disconnect the exhaust blower from the stove wiring harness. To remove the venting pipe, removal of the rear panel (using a ” wrench) may be necessary. Remove all (5) screws which hold the exhaust blower to the exhaust blower tube. Once the screws have been removed, the blower can be lifted up and out of the stove. Reinstallation is the exact opposite of the steps above; however, be certain to check the condition of the exhaust blower gasket and replace if necessary. ... -
Page 35: Vacuum Switch
REPLACING COMPONENTS Vacuum Switch Before beginning any component replacement, be certain the unit is unplugged and thoroughly cooled down. Remove the right side panel (see p. 44 for panel instructions). Locate the vacuum switch as shown in the diagram below. Disconnect the stove wiring harness and vacuum hose from the vacuum switch, taking note of where connections were made. Remove the (2) screws which hold the vacuum switch to the vacuum switch bracket, using a Phillips screw driver. Installation is the reverse of removal; be absolutely certain the wires and vacuum hose are connected as they previously were (and according to the wiring diagram in this manual). 35 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ... -
Page 36: Igniter
REPLACING COMPONENTS Igniter Before beginning any component replacement, be certain the unit is unplugged and thoroughly cooled down. Remove the rear panel of the unit, using a ” wrench. Locate the igniter as shown in the diagram below. Disconnect the igniter wiring from the control board and use a ” wrench to remove the igniter retaining screw. Loosen the Allen set screw ( ” Allen wrench) and remove the old igniter cartridge. Install the new igniter in the igniter tube, retighten the set screw and reinstall the assembly into the stove (reconnect the wiring). Igniter Reinstall the rear panel. ... -
Page 37: Gaskets
REPLACING COMPONENTS IMPROPER GASKET MAINTENANCE, INCLUDING FAILURE TO REPLACE GASKETS, CAN CAUSE AIR LEAKS RESULTING IN SMOKE‐BACKS. Gaskets 1. Door This unit comes with a ¾” rope gasket in the channel around the door opening that should be replaced at least once every year. To replace the door gasket (Part # AC‐ DGKHD), the old gasket must first be removed entirely — prior to adding the new adhesive, you may have to scrape the old cement from the channel. Once the cement and gasket have been added, the door should be closed and latched for twenty‐four hours to allow the cement to harden. See next page for more info. 2. Window If you are replacing the window gasket (Part # AC‐GGK), the new gasket will already have adhesive on one side. Remove the paper on the adhesive side and place the gasket around the outside edge of the glass, centered over the edge. Fold the gasket edges over on the glass, forming a “U” shape. Combustion Blower The Combustion Blower Gasket (Part # PU‐CBG) should be inspected whenever you remove or clean the Combustion Blower, and replaced if necessary. 4. Combustion Blower Motor The combustion blower motor gasket (Part # PU‐CMG) generally does not need replacement, as it is not normally removed from the unit. However, if the exhaust blower is cleaned by removing the motor, rather than the entire blower assembly, this gasket must be inspected and replaced as necessary. ... -
Page 38: Glass
REPLACING COMPONENTS Glass This unit has one ceramic glass panel (Part # AC‐G60) in the door; self adhesive window gasket is included with replacement windows purchased directly from England’s Stove Works. Never replace ceramic glass with tempered or any other type of glass and never operate this unit with cracked or broken glass. Surface scratches are acceptable and normal, but if this glass becomes cracked in any area, the unit should be shut down and the glass replaced with this high‐temperature ceramic glass. Ceramic Glass Specifications Glass Size: 13 in. (330.20 mm) x 12.5 in. (317.50 mm) Glass Type: 5mm Ceramic Glass (Keralite Pyroceram) Glass Manufacturer: Eurokera Glass Precautions Never replace ceramic glass with tempered or any other type of glass. Never operate this unit with cracked or broken glass. Do not slam the door or strike the glass with any objects. Glass Cleaning 1. Be certain the stove and the glass are completely cool. 2. The build‐up on the glass will generally be light and water is normally sufficient to remove the deposits. If stubborn soot persists, use a cleaner made specifically for this purpose. Do not scrape the glass or use abrasive cleaners. 3. Rinse the glass with clean water and dry the glass before resuming normal operation. Glass Replacement (includes Door Gasket replacement instructions) Remove the door from the stove and rest it face‐down on a firm work surface. Remove the door gasket using a pair of pliers to pull it out of the channel. Using a ... -
Page 39: Control Board
REPLACING COMPONENTS Control Board *BEFORE REPLACING THE CONTROL BOARD BE SURE THE UNIT IS COOLED COMPLETELY AND UNPLUGGED.* The Control Board (Part # 25‐SSCB) is a digital read‐out board. To replace the control board, first unplug the power cord from the wall outlet. Remove the front face of the control board by pulling it forward. Once the board is apart, use a pair of needle nose pliers to disconnect the wiring harness, room sensor, heat sensor, hopper lid and vacuum switch connectors. When connecting the new board, reconnect the components mentioned above and snap the front face of the control panel back into place. Reconnect power when ready to use the unit. Recommended Heat Ranges (For Manual Mode): Low Burn: Heat Range setting: 1 Room Air Blower setting: 1 Medium Low: Heat Range setting: 2 – 3 Room Air Blower setting: * Medium High: Heat Range setting: 4 – 8 Room Air Blower setting: * High Burn: Heat Range setting: 9 Room Air Blower setting: 9 ... -
Page 40: Wiring Diagram
Vac Switch/ Hopper Lid Switch WIRING DIAGRAM Caution – Shock Hazard Press the “Off” button and let the appliance completely cool BEFORE unplugging the appliance and beginning any maintenance or component replacement. Risk of shock if appliance is not unplugged before service. 40 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND ... -
Page 41: Hopper Lid Hinges
HOPPER LID HINGES The hopper lid is attached to the top of the stove by two removable hinges. To remove the hopper lid hinges: Remove the (4) screws that hold each hinge in place, using a ” socket. Re‐Install hinges in the reverse method. HOPPER LID HANDLE The hopper lid handle snaps into place in the opening in the hopper lid. To remove the hopper lid handle: Lift the hopper lid up (in the open position). Press up on the bottom of the handle and it will pop out of place. To install new handle, insert at the top of the hopper lid and press down until handle snaps into place. ... -
Page 42: Panels
SIDE PANELS The side panels are designed to hang onto the sides of the stove and can easily be removed to perform regular cleaning (and any maintenance that may need to be done in the back of the stove). To remove side panels: Loosen (DO NOT REMOVE) the (2) 5/16” screws that hold the side panel to rear of the stove. Grasp the panel and lift straight up until the tabs are removed from the side tracks and pull the panel towards you. Re‐install the side panels using the reverse of this method. FINISH This new unit has been painted with High‐Temperature paint that should retain its original look for years. If the unit should get wet and rust spots appear, the spots can be sanded with fine steel wool and repainted. It is crucial that only High‐Temperature Spray Paint is used (Part# AC‐MBSP), as others may not adhere to the surface or withstand the high temperatures. Similarly, some brands of paint will not adhere to different brands of paint, so we highly recommend using our proprietary High‐Temperature Spray Paint. 42 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ... -
Page 43: Illustrated Parts Detail Exploded Parts Diagram
ILLUSTRATED PARTS DIAGRAM 43 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ... - Page 44 REPLACEMENT PARTS LIST Part No Description From Diagram BM‐1288 Room Air Blower Not Shown CU‐047042 2.4 RPM Auger motor CW Rotation 29 PU‐076002B Combustion Exhaust Blower(Neg) Not Shown AC‐DGKHD ¾” HD Door Gasket 23 PU‐HLSB Hopper Lid Safety Switch 7 CU‐VS .05 Vacuum Switch 15 25‐SSCB Control Board Not Shown 25‐SSWH Control Board Wiring Harness Not Shown AC‐HP Hinge Pin 1 AC‐MBSP Stove Paint Not Shown AC‐SH1 3/8” Brass Spring Handle Not Shown AC‐SHN2 3/8” Nickel Spring Handle Not Shown CA‐AC ...
- Page 45 PU‐BMTL Long Baffle Mounting Track 13 PU‐SSDVD DVD Not Shown MU‐SSP01 Manual Not shown PU‐SSEXCP Exhaust Cover Plate 4 PU‐RABMP Room Air Blower Mounting Plate Not Shown CU‐RG Rubber Vibration Dampener 28 PU‐RSP Right Side Panel 9 PU‐LSP Left Side Panel 8 PU‐SSHL Hopper Lid 19 PU‐MBS Middle Baffle Spacer 3 PU‐SSRP Rear Panel Not Shown AC‐CT Cleaning Tool Not shown AC‐CMB Control Board Mounting Box Not Shown AC‐CHSEP Cartridge Heater Sleeve Not shown ...
-
Page 46: Warranty Serial Tag Sample
46 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ... -
Page 47: Warranty Details
LIMITED FIVE (5) YEAR WARRANTY From the date of purchase to the original owner. Model Numbers 25‐SSP01 / 55‐SHSSP01 / 55‐TRSSP01 25‐SSP01S / 55‐SHSSP01S /55‐TRSSP01S The manufacturer extends the following warranties: Five Year Period: 1. Carbon steel and welded seams in the firebox are covered for five (5) years against splitting. 2. The steel door and hinges are covered for five (5) years against cracking. One Year Period: 1. Component parts such as the hopper, auger, burn‐pot, auger shaft and fasteners are covered for one (1) year against cracking, breakage and welded seam separation. 2. Electrical components, accessory items, glass and the painted surface of the stove are covered for one (1) year from the date of purchase. Conditions and Exclusions 1. Damage resulting from over‐firing will void your warranty. 2. This warranty does not apply if damage occurs because of an accident, improper handling, improper installation, improper operation, abuse or unauthorized repair made or attempted to be made. 3. The manufacturer is not liable for indirect, incidental, or consequential damages in connection with the product including any cost or expense, providing substitute equipment or service during periods of malfunction or non‐use.* 4. All liability for any consequential damage for breach of any written or implied warranty is disclaimed and excluded. 5. This unit is EPA certified using high quality, Premium Grade pellet fuel. Warranty is void if the unit is used to burn materials for which the unit is not certified by the EPA. Warranty is void if unit is not used according to the owner’s manual. 47 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR ... - Page 48 *Some states do not allow the exclusion of limitations of incidental or consequential damages, so the above may not apply to you Procedure Purchaser must give notice of claim of defect within the warranty period and pay transportation to and from a service center designated by the manufacturer. The dealer from which the unit was purchased or the factory, at our option, will perform the warranty service. Other Rights This warranty gives you specific legal rights; you may also have other rights, which may vary from state to state. England’s Stove Works, Inc. P.O. Box 206 Monroe, VA 24574 (800) 245‐6489 To submit a Warranty Claim, call (800) 245‐6489 to speak with our Technical Support department. You may also file a Warranty Claim at www.heatredefined.com/support/warranty‐claim‐request/ For parts, warranty replacement procedures may be found at our parts store site: store.heatredefined.com 48 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ...
-
Page 49: Important Notice
Important Notice This registration information MUST be on file for this warranty to be valid. Please send this information within thirty (30) days from the original date of purchase. Use any of these three easy ways to send your warranty information in! Mailing Address England’s Stove Works, Inc. Technical support Department P.O. Box 206 Monroe, Virginia 24574 Please Note: This warranty is null and void if the attached warranty registration AND a copy of the sales receipt is not returned within thirty (30) days from the date of purchase. Warranty is not transferable. Fax Number (434) 929‐4810 – Twenty‐four hours a day Online Registration Visit our warranty registration website at: http://www.heatredefined.com/support/warranty‐registrations/ 49 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ... - Page 50 50 IMPORTANT! READ AND FOLLOW ALL INSTALLATION AND MAINTENANCE INSTRUCTIONS, INCLUDING CLEANING THE UNIT AS SPECIFIED, AND REPLACING GASKETS ANNUALLY, AND PARTS AS NEEDED. ENGLAND’S STOVE WORKS IS NOT RESPONSIBLE FOR ANY DAMAGE OR INJURY INCURRED DUE TO NEGLECT, OR DUE TO UNSAFE INSTALLATION OR USAGE OF THIS PRODUCT. CALL TECHNICAL SUPPORT WITH ANY QUESTIONS. ...
-
Page 51: Warranty Reg. Form
WARRANTY REGISTRATION for England’s Stove Works® Purchaser Information I. Purchased By (Name) _________________________________________ II. Address ____________________________________________________ III. City _______________________State________Zip Code ____________ IV. Telephone Number ___________________________________________ V. Email Address _______________________________________________ Dealer Information VI. Purchased From _____________________________________________ VII. Address ___________________________________________________ VIII. City_______________________ State________ Zip Code __________ Unit Information IX. Model Number_____________________ Purchase Date _____________ X. Purchase Price _____________________ XI. Serial Number_____________________ Mfg. Date _________________ Purchase Questions How did you first hear about our product? (Please check one) Word of Mouth ____ Burn Trailer Demonstration____ Internet____ Other: ________________________________________________________ Where did you receive information about our product? Via Telephone____ Dealer (Name of dealer) ___________ Internet____ Other: ________________________________________________________ ...
