A local telephone company may make changes in its communications facilities or procedure. If these changes could reasonably be expected to affect the use of the KS660 or compatibility with the network, the telephone company is required to give advanced written notice to the user, allowing the user to take appropriate steps to maintain telephone service.
3. TECHNICAL BRIEF 3.2. Dual Baseband Processor (BBP) Introduction KS660 is composed of dual Baseband Processor. (S-Gold3 & S-Gold Radio) 3.2.1. S-Gold3 Part < Fig 2. Top level block diagram of the S-GOLD3 (PMB8877) > 3.2.1.1. General Description S-GOLD3 is a GSM/EDGE single chip mixed signal Baseband IC containing all analog and digital functionality of a cellular radio.
3. TECHNICAL BRIEF 3.2.1.7. GPIO map Over a hundred allowable resources, KS660 is using as follows except dedicated to SIM and Memory. KS660 GPIO(General Purpose Input/Output) Map, describing application, I/O state, and enable level, is shown in below table Reset...
Battery supply voltage measure 3.2.2.6. GPIO map Over a hundred allowable resources, KS660 is using as follows except dedicated to SIM and Memory. KS660 GPIO(General Purpose Input/Output) Map, describing application, I/O state, and enable level, is shown in below table.
PA_MODE_2 T/PD 3.3. Power management IC KS660 is composed of dual Power Management Part. (S-Gold3 & S-Gold Radio) 3.3.1. S-Gold3 Part 3.3.1.1. General Description SM-POWER is a highly integrated Power and Battery Management IC for mobile handsets. It has been specially designed for usage with S-Gold3.
3. TECHNICAL BRIEF < Fig 4. SM-Power Circuit Diagram of KS660 > < Fig 5. SM-Power Circuit Diagram with charging part > ‘ 3.3.2. S-Gold Radio Part 3.3.2.1. General Description S-GOLDradio integrates a Power Management Unit for Lithium-Ion battery driven applications that require different power rails.
• System watchdog timer with on-chip oscillator. < Fig 7. S-GOLD Radio PMU circuit diagram > 3.4. Power ON/OFF KS660 Power State : Defined 3cases as follow ▶ Power-ON : Power key detect (SM-Power’s ON port) ▶ Power-ON-charging : Charger detect.
VIHdet (Vbat-0.8 ~ Vbat-0.3) the above-mentioned bit won’t be set. To support Remote power on function for factory mass production, applied an analog switch as following figure. As monitoring the RPWRON and Key matrix KP_OUT(2) & KP_IN (0), KS660 system recognize whether remote power on or End-key pushed <...
3.5. Dual SIM & u-SD Interface 3.5.1. Dual SIM Interface KS660 supports dual SIM mode and each SIM supports 1.8V & 2.9V plug in SIM, SIM interface scheme is shown in (Figure 8). SIM_IO, SIM_CLK, SIM_RST ports are used to communicate with BBP(S-Gold3) and the SIM power supply enabled by PMIC.
3. TECHNICAL BRIEF 3.6. Memory KS660 is composed of 3 memories. 2 MCPs(NAND+SDR) are connected each BBP(SG3 / SGR). And 1 DPRAM is used to communicate between 2 MCPs.(SG3 and SGR). ) t i ) t i < Fig 12. SGold3 Part Flash memory & SDR RAM MCP circuit diagram >...
< Fig 19. JTAG & ETM(Embedded Trace Module) interface connector > In case of KS660 mass production, the JTAG & ETM interface connector will not be mount on board. That is only for developing and software debugging purpose.( It will not be mounted on mass production PCB) 3.12.
