- Page 1 PowerSure Personal XT 450, 700, 1250 VA 230V ANUAL English / Deutsch / Français / Italiano / Español...
-
Page 2: Important Safety Instructions
Also provided is a Liebert special interconnection cable for connection to DB9 connector on the rear of the UPS for use with Liebert's SiteNet MultiLink® software (see user manual for details) DO NOT USE FOR OTHER APPLICATIONS. - Page 3 Your UPS provides conditioned power to connected equipment. Maximum load must not exceed that shown on UPS rating label. If uncertain, consult your distributor or Liebert. Placing magnetic storage media on top of the UPS may result in data corruption.
-
Page 4: Introduction & System Description
INTRODUCTION & SYSTEM DESCRIPTION Congratulations on your choice of the Liebert PowerSure Personal XT Uninterruptible Power System (UPS). It provides conditioned power to microcomputers and other sensitive electronic equipment. MAJOR COMPONENTS PowerSure On/Off Status-LED Fault-LED Output Receptacles OUTPUT FRONT BACK... -
Page 5: General Installation
GENERAL INSTALLATION PowerSure PowerSure Remove from Box Check for Damage PowerSure 110 mm 0° -40°C OUTPUT Remove Plug from Units and replace in UPS PowerSure OUTPUT Plug Units(s) into UPS Press ON Button... -
Page 6: Normal Mode Operation
NORMAL MODE OPERATION Inspect the packaging carton and its contents for damage. Please inform the trasport agency immediately should you find signs of damage. Please keep the packaging in a safe for future use. Plug the UPS into a wall outlet (see figure 1). Let the UPS charge the battery for at least 2 hours. - Page 7 LED & ALARMS The front panel LEDs and audio beeps indicate the UPS status. Switch and LEDs Symbol Function On/off Turn the UPS system an and off. 1. Steady: Input power is acceptable; the UPS is in normal mode (online) Status-LED 2.
-
Page 8: Troubleshooting
TROUBLESHOOTING If the UPS fails to operate properly, turn off the unit and repeat the steps in the installation section of this manual. If the problem persists, refer to the chart below: PROBLEM POSSIBLE CAUSE REMEDY No indication, no Check building wall outlet and mains cable by beep even UPS is No input voltage connecting another device with cable to this wall... -
Page 9: Maintenance
You can use MultiLink™ Software to allow your UPS to communicate to your computer via your DB-9 communications port. A MultiLink Software CD is included in the box, or you can download it from our web site at www.liebert.com. The PowerSure™ Personal XT UPS contains a standard DB-9 receptacle located on the rear of the UPS unit. - Page 10 230V SPECIFICATIONS ELECTRICAL SPECIFICATION Model Number PSPXT450-230 PSPXT700-230 PSPXT1250-230 INPUT Voltage 230 VAC (197 - 262 VAC) Frequency 50 Hz ± 4Hz; 60 Hz ± 4Hz Amperage (maximum) 2.6 A 4.0 A 7.0 A 12 φ 2W, Ground Phase OUTPUT Power rating 450 VA - 270 W 700 VA - 420 W...
-
Page 11: Limited Warranty
The responsibility for risk assessment and management in applications where the malfunction or failure of the UPS could be reasonably expected to give rise to a risk of human life shall be the sole responsibility of the purchaser. Liebert accepts no liability for consequential harm in such applications. -
Page 12: Technical Support
Worldwide FAX tech support +614-841-5471 The Company Behind The Products With more than 1.000.000 installations around While every precaution has been taken to the globe, Liebert is the world leader in ensure accuracy and completeness of this computer protection systems.
